Raption 150 Compact Service Manual
RCBOs
D
There are three RCBOs in the Raption protecting the Auxiliary branches.
From the left to the right:
•
Service Schuko
•
Auxiliary Power supply distribution 230V AC
•
Ventilation / Heater
33
Q110.1
Q109.1
Q109.2
