C
Components Overview
Inside the Charge Point it is possible to differentiate four main parts. In the upper part
there are the electronic boards, the electrical protections and the electrical actuators.
In the medium low part there are located the power modules. Next to them on the left,
there is the power input supply section.
The last important part in the Charge Point are both doors.
Electronic boards,
etc
Power modules
Power supply section
09
Left door
Right door
