1 B — E L E C T R O N I C B OA R D S , E L E C T R I C A L P R O T E C T I O N S , E L E C T R I C A L
AC T UAT O R S - I N N E R L A Y E R C O M P O N E N T O V E R V I E W -
7 7
1
2
3
4
5
6
1- Three-phase MID
energy meter (P105.1)
5- Contactor for
power modules
(K105.1 / K106.1)
9- Precharge fuse 2A
(F301.1)
13- Permanent
overvoltage fuse 25A
(F101.1)
17- UPS (G150.3)
Note: Depending on the model, the components can vary.
7 8 7 9
2- RCD protection class
B (QD103.1)
6- Miniature circuit
breaker 3P 50A class C
(Q120.1/Q121.1/Q121.2/
Q122.1/Q123.1/Q123.2)
10- Miniature circuit
breaker 2P 20A class C
(Q101.3)
14- Power relay
(K103.2 / K204.1)
7 8 7 7
3- RCD protection
class B (T105.1 /
T106.1)
7- Current transformer
(T140.1 / T140.2)
11- RCD 1P+N 25A
30mA class AC
(Q101.4)
15- RCBO 1P 10A class
A (Q109.1 / Q110.2)
7 10
7 11
7 12
7 13
7 14
7 15
7 16
7 17
4- Three-phase MID
energy meter (P106.1)
8- CCS fuse 500A/
CHA fuse 250A (F140.1
/ F140.2)
12- EMI filter (L101.2)
16- 24Vdc Power
Supply (G150.1)
