Raption 150 Compact Service Manual
3 — C I R C U I T B R E A K E R
1
2
3
4
5
6
Notes:
- Depending on the model, the components can vary.
- In order to find more details about the cable installation, please, refer to the Installation
Manual.
15
7
overvoltage fuse
(F102.1 / F102.2 /
3- Miniature circuit
breaker 2P 16A
5- Metal plate with
multi-range cable
grommets in pyra-
7- Surge protection
devices 4P Type 2
1- Temporary
2- Molded Case
terminal 80A Circuit Breaker
F102.3)
4- Rotary handle for
(Q101.2)
6- Connection
terminal block
mid shape
(F102.4)
(Q101.1)
MCCB
