9

Maintenance and Cleaning

Y
WARNING
Perform only the maintenance procedures
described in this manual and observe the
relevant safety precautions. Failure to
do so may cause property damage or
personal injury.
Maintenance or repair procedures not
described in this manual should be
performed only by a qualified service
engineer. Tampering with or alterations to
the CellASIC ONIX2 Microfluidic System,
®
Manifolds and/or other components may
void the warranty. Refer to the Technical
Assistance section for information on
contacting Technical Service.

9.1 Running a System Self Check

A system self check should be run periodically to confirm ideal operation of the
ONIX2 System.
1. Before you begin:
● Connect the ONIX2 System to the computer via USB
● Turn on the power switch (rear panel)
● Establish connection with the software
● If you have premixed gas sources, make sure they are connected and
gas valves are open
2. Click System and Manifold Self Check in the Tools menu to open the System
and Manifold Self Check dialogue.
3. Click Run Self Check.
4. Follow the prompts on the screen.
5. When prompted, follow directions to seal
manifold to Self Check Plate.
6. The self check takes several minutes to
complete. All checks should state PASS.
If any say FAIL, please send results file to
Technical Service (detailed results are saved
to the folder indicated; the link can be clicked
to access the folder). WARNINGS indicate
an issue that needs further investigation.
For example, if the results state WARNING
Unable to fully check gas environment,
gas input not detected, confirm that gas
inputs are connected. If they are and the
warning is still present contact Technical
Service.
20202092 04/19
Y
ATTENTION
Ne réaliser que les opérations de maintenance
décrites dans ce manuel et prendre les précautions
de sécurité adéquates. Le non-respect de ces
exigences peut provoquer des dommages
matériels ou des blessures corporelles.
Les procédures de maintenance ou de réparation
non décrites dans ce manuel ne doivent être
effectuées que par un technicien qualifié.
Altérer ou modifier le Système de microfluidique
CellASIC ONIX2, le Manifold et/ou d'autres
®
composants est susceptible d'annuler la garantie.
Se reporter à la section "Technical Assistance"
pour de plus amples informations sur la façon de
contacter notre Service technique.
Figure 40. Example System
and Manifold self check result
with a gas input warning
50 of 60
CellASIC ONIX2 Microfluidic System
®
