8.4 Using the Mini-view

8.4.1 Begin Experiment
8.4.2 Open Plate Mini-view
20202092 04/19
1. Launch application.
2. Click New Experiment on opening screen.
3. In the Select Plate Type dialogue, select the desired plate type
(e.g., M04S-03 - Plate for Mammalian Cells) and click OK.
1. On the Manual Mode tab (see 8.2.2), click the Mini-View button icon
to open the plate mini-view. The plate mini-view is a small control window
which can float on top of other windows and is intended to be used in
parallel with your microscopy software.
2. Click Always on Top
applications.
B
Figure 36. Mini-view on top
to make mini-view float above other
A
46 of 60
A
CellASIC ONIX2 Microfluidic System
®
