7.4 Protocol Editor Tab,
Step
Pause
( in Figure 15)
D
7.4.2 Insert a New Step
Click on Perfusion, Gas Set, Temperature Set, or Pause buttons on the left
( , ,
A B
inserted after the most recently selected step.
7.4.3 Delete a Set of Steps
To delete one or more steps, click on the step or use the shift and control keys while
clicking to select multiple steps. Click Delete Selected Step(s) or press the delete
key to delete the selected steps.
7.4.4 Copy/Cut and Paste a Set of Steps
To copy one or more steps, click on the step or use the shift and control keys
to click on multiple steps. Then right click on one of the selected steps and click
Copy. To paste, select one step, right click on the step, and then click Paste. The
copied steps will be inserted immediately following the selected step. The keyboard
shortcuts Ctrl-c for copy, Ctrl-x for cut, and Ctrl-v for paste can also be used.
20202092 04/19
continued
Description
When the procedure executor
encounters a Pause step, it
halts execution and notifies
the user, giving them the
option to resume or abort
the run. If Duration is
set to zero, the pause will
continue indefinitely and can
be manually resumed at any
time. Otherwise, the protocol
will automatically resume
after the specified time
completes.
If the Keep well groups
open during pause box
is checked, the previously
existing perfusion state will
continue during the pause. If
the box is not checked, flow
is stopped (i.e., well groups
are closed) during the pause.
In this case, the user is free
to unseal and reseal the plate
while in the paused state.
Temperature and gas flow
continue in either case.
, or in Figure 15) to create a new step of that type. The step will be
C D
Step Editor Pane
