7.6 Status Bar,
Display Field
Error status
Output status
Pressure X status
Pressure Y status
Gas flow status
Temperature status
20202092 04/19
continued
Status Description
OK
C
WARNING (flashes orange)
ERROR (flashes red)
If there is an error or warning, click on the ERROR/
WARNING button in the status bar to bring up the error/
warning tray
Outputs: well group output state in order from 1 to 8.
D
Shows an empty circle if well group is off, or a filled
circle with color according to X or Y pressure color.
X: pressure in kPa
E
Y: pressure in kPa
F
Gas: Off or flow source and flow rate
G
Options for flow source:
A (or text from settings if it exists)
B (or text from settings if it exists)
Options for flow rate:
Slow
Fast
Temp: temperature of manifold
H
If no manifold connected "--"
27 of 60
I for details (only in the main application).
