Quick Start Guide
DiluCult
™
Safety Notes
• Only qualified personnel should use and maintain
the DiluCult instrument.
™
• Always use DiluCult
™
grounding plug.
• Do not exceed the authorized weight on the
weighing platform:
- DiluCult instrument: 3,000 g
™
- DiluCult 2 instrument: 5,000 g
™
• Read the DiluCult and DiluCult
™
before use.
Setting up the Instrument
1. Place the instrument on a flat, stable surface, away
from any source of excessive heat and close to an
properly grounded power supply outlet
2. For the DiluCult instrument only, install the fixed
™
arm at the back of the instrument using the Allen
wrench and 2 screws provided with the arm.
3. Clip the bag holder into the two holes in the base of
the instrument. For DiluCult
magnetized nozzle protection.
4. Install the distribution assembly:
• Place the tube weight at the bottom of the bottle
and screw the GL45 cap on the top.
• Install the tubing into the pump. The direction of
flow is indicated by the arrows on the housing.
• Close the pump, keeping the tubing stretched and
making sure the tubing is not pinched.
• Place the tubing in the tubing holder.
& DiluCult
instrument with a
2 User Guide
™
2 only, also clip on the
™
2
3
2
™
a b c
1
DiluCult
™
DiluCult 2
™
Nozzle
protector
