7.4 Protocol Editor Tab

The Protocol Editor allows the creation and editing of an experiment protocol. A
protocol is comprised of a sequence of environment control and/or perfusion steps.
Steps can be added and altered as desired. When the experiment protocol is ready,
it can be executed using the Run tab. To modify the parameters of a step, select the
step in the protocol and use the step editor pane on the right side
A
B
C
D
Figure 15. Protocol Editor tab
Protocol Editor provides options to:
● Insert a new step anywhere in the sequence
● Modify parameters of any step
● Delete a set of steps
● Copy a set of steps and insert the copied steps at
a specific point of the sequence
● Create loops of steps
● Insert plate-setup sequences
After an experiment run has started, the protocol can only be viewed and no longer
modified. To modify the protocol again, you will need to create a new experiment
file based on the currently open one.
20202092 04/19
20 of 60
.
E
E
