7.3 Plate Layout Tab

This tab gives you the option to enter experiment information and notes. The
information is recorded in the experiment file and included in generated reports.
When a new experiment is created based on a previous experiment, all of the
information entered on this tab (except the plate barcode number) is copied into the
new experiment file.
Figure 13. Plate Layout tab
You may enter information into the fields provided. Tab and Shift*Tab move
horizontally through the fields, while Enter and Shift*Enter move vertically.
Plate Barcode
Well text fields for A1 to D8
Text Description
Clear All Values
20202092 04/19
A
C
B
A
B
D
Record the barcode number of your
plate here
Record the media and cell solutions
C
loaded into each well here
Describe your experiment in this field
Click button to clear all text fields on
this tab
18 of 60
D
