4.8 Functions
4.8.1 Custom Linearizers
94
Functions
Fig. 4.17 Functions Configuration
Press the
to open the Adjust custom linearizer' window.
Use the
modified.
Press the
to open the digipad to change the position of that point.
Press
custom linearizer' window.
Press
Each linearizer has 20 breakpoints. Both X and Y values are
set as percentages.
Custom linearizers can be applied to any analog input by
selecting them as the linearizer type for that input – see
Section 4.6.2.
key adjacent to the linearizer to be adjusted
and
keys to highlight the point to be
key adjacent to the X% point or the Y% point
to close the digipad and return to the 'Adjust
to close the 'Adjust custom linearizer' window.
