...2.3 Chart View
Configuration
Set Up
Sign Chart
Historical Review
Select the Configuration Level – see Section 4.
Select the Setup Level – see Section 3.
Note. Available only if 'Security system' is set to 'Advanced' – see Section 4.4.4.
Sign the chart electronically – see Section 2.3.1.
Select Historical Review to view previously recorded data stored in the instrument's
onboard memory.
Note. Use the and
data.
Process Group 1
Level Pressure
Digital
2.08
Indicators
metres
0
12:00:00
11:59:00
11:58:00
11:57:00
keys to move backwards and forwards through the recorded
Historical Invalid data – e.g.
Review Active recording disabled
In Flow Out Flow Temp
4 204.9 198.9 - - - -
bar l/hr l/hr
11:58:23 Duty/Standby Pumps Switched
11:57:30 High Level
2 OPERATION...
28/03/00
Values displayed
11:59:30
indicate the process
Alarm 1
status at the cursor
On
position
°C
10
Cursor
