...2 OPERATION
...2.6 Process View
Totalizer Reset
Ch 1.1 Level
Ch 1.2 Pressure
Ch 1.3 In Flow
Ch 1.4 Out Flow
Ch 1.5 Temp
Ch 1.6 Alarm 1
Alarm Acknowledge
Ch 1.1 Level
Ch 1.2 Pressure
Ch 1.3 In Flow
Ch 1.4 Out Flow
Ch 1.5 Temp
Ch 1.6 Alarm 1
All
AutoView Scroll
22
Reset the totalizer value to the totalizer preset value.
Channel totalizers that have not been enabled in the Configuration level are greyed-out.
To acknowledge a particular alarm, use the
press the
key.
Note. Active unacknowledged alarms in the current process group are identified by a
flashing red Alarm Event icon in the bottom left hand corner of the associated channel
indicator. Active acknowledged alarms are identified by a continuous red Alarm Event icon
in the bottom left hand corner of the indicator – see Fig. 2.7, page 20.
To acknowledge all active alarms in the current process group simultaneously, select 'All'
and press the
key.
Note. If an alarm in
the other
continues to be displayed in the status bar. If an active alarm in
unacknowledged, the icon is surrounded by a red flashing border.
If neither alarm on a particular channel is configured, the short channel tag is shown
greyed-out in the menu.
Select 'AutoView Scroll' to display the chart for each configured process group in turn for
40 seconds. The AutoView Scroll icon (
screen when AutoView Scroll is active. Press any key to cancel AutoView Scroll.
and
keys to highlight it in the menu and
process group is active, the Global Alarm status icon (
) is displayed in the status bar at the top of the
)
process group is
the other
