...4 CONFIGURATION
...4.6.4 Alarm Configuration
84
Select an alarm Enable source. When the 'Enable source' is
active, the alarm is enabled. When the source is inactive the
alarm is disabled. If set to 'None' the alarm is always
enabled.
Note. For
Delayed
Process
Fig. 4.15.
Set to 'On' to record all changes in the alarm state in the
Alarm Event log – see Section 2.7.
Assign the alarm to one or more of 12 groups.
The alarm states assigned to each group are 'ORed'
together to create an internal digital signal that may be
assigned to relays, digital outputs or internal digital controls.
alarm
operation,
see
