...2 OPERATION
...2.4 Bargraph Views (Horizontal and Vertical)
Configuration
Setup
Operator Messages
1 - 6
7 - 12
Start of batch
13 - 18
End of batch
19 - 24
Standby mode active
<user defined>
Cleaning in progress
No message
No message
Max/Min Reset
Ch 1.1 Level
Ch 1.2 Pressure
Ch 1.3 In Flow
Ch 1.4 Out Flow
Ch 1.5 Temp
Ch 1.6 Alarm 1
All
Alarm Acknowledge
Ch 1.1 Level
Ch 1.2 Pressure
Ch 1.3 In Flow
Ch 1.4 Out Flow
Ch 1.5 Temp
Ch 1.6 Alarm 1
All
AutoView Scroll
16
Select the Configuration level – see Section 4.
Select the Setup level – see Section 3.
Add one of 24 predefined Operator Messages (see Section 4.4.5) or one User-Defined
Message to the alarm event log. If '<user defined>' is selected, a data entry keyboard
appears to enable the message to be entered – see Fig. 4.5, page 49. The selected or
user-defined message is displayed briefly on-screen.
Reset the Maximum and Minimum value markers on one or all channels to the current
value.
Notes.
• These Maximum and Minimum values are for display purposes only. They are not saved
or archived and are not connected to the Totalizer Maximum and Minimum Values
displayed in the Process View.
• These Maximum and Minimum values are reset whenever the current configuration has
been changed or is re-saved.
To acknowledge a particular alarm, use the
press the key.
Note. Active unacknowledged alarms in the current process group are identified by a
flashing red Alarm Event icon in the bottom left hand corner of the associated channel
indicator. Active acknowledged alarms are identified by a continuous red Alarm Event icon
in the bottom left hand corner of the indicator – see Fig. 2.5, page 15.
To acknowledge all active alarms in the current process group simultaneously, select 'All'
and press the key.
Note. If an alarm in
the other
continues to be displayed in the status bar. If an active alarm in
unacknowledged, the icon is surrounded by a red flashing border.
If neither alarm on a particular channel is configured, the short channel tag is shown
greyed-out in the menu.
Select 'AutoView Scroll' to display the chart for each configured process group in turn for
40 seconds. The AutoView Scroll icon (
screen when AutoView Scroll is active. Press any key to cancel AutoView Scroll.
and keys to highlight it in the menu and
process group is active, the Global Alarm status icon (
) is displayed in the status bar at the top of the
)
process group is
the other
