5.2 Mounting – Figs. 5.3 and 5.4
Dimensions in mm (in.)
144.0 (5.67)
1
Cut a hole in the panel – see Fig. 5.3.
2
Insert the instrument
Gasket
7.0
(0.27)
144.0
(5.67)
3 (0.12)
34 (1.34)
Fig. 5.3 Mounting Dimensions
Fig. 5.4 Fitting the Instrument
155.0 (6.1) 40 (1.57)
29 (1.14)
Gasket
3
Fit the panel clamps
4
Tighten the panel clamp securely by hand (See Note).
Note. This is critical in order to ensure
proper compression of the panel seal
and achieve the NEMA 4X hosedown
rating.
5 INSTALLATION...
AC Power Supply
Earth (Ground) Stud
+1.0
138
–0.0
Panel Cut-out
+0.04
(5.43 )
–0.0
138
30
(1.2)
(5.43
AC Power Supply
Earth (Ground) Stud
+1.0
–0.0
+0.04
)
–0.0
97
