6 Signal routing and scaling
6.1.1.2 Objects: 0x3208 / 0x320C Analog input 1
AnalogInput1
Index Subindex
0x3208 0
0x320C 0
<InputType>
Type of the setpoint input:
Other types are not to be selected.
<ActualValue>
In case of <DeviceMode> (0x6042) = 2, this is the actual value for the pressure command. Otherwise the an-
alog value can be assigned to any interface.
Chapter "6.2.1.7 Object 0x6042: Device mode", page 45
Chapter "6.3.3 Interface assignment", page 48
© Moog GmbH
Name
InputType
ActualValue
<InputType>
1
3
5
11
Table 29: <InputType> values analog input 1
USER MANUAL Firmware RKP-D (B99224-DV007-CE400; Version 1.1, 09/08)
Data type Access
INT8 rw
INT16 ro
Type of analog input
±10 V potential-free
±10 mA potential-free
4...20 mA potential-free 0...100 %
4...20 mA potential-free ± 100 %
Physical pump interfaces
Persis-
tence Value range
Y INT8
N INT16
Default
1
None
35
