5 Device control

5.3.5 Object 0x6041: Status word

The bit-coded status word indicates the current device status.
Device
Index Subindex
0x6041 0
Values description
Bit
0
1
2
3
4
5...7
8
9
10
11
12
13
14
15
Bits 0, 1, 2, 3 - Disabled, Hold, Device Mode Active, Ready
These bits indicate the status of the state machine.
Description of the device states and the associated bit values:
Chapter "5.2 State machine", page 24
Bit 4 - Local control
This bit is activated during local control.
Chapter "5.3.4 Object 0x604F: Local", page 28
Bit 8 - Pressure controller effective
This bit indicates whether the pressure controller is active in the p/Q control type.
Bit = 0 : pressure controller disabled
Bit = 1 : pressure controller enabled
This bit is active, if, and only if, the p/Q control type is active.
Bit 9 - Ramp running
If this bit is activated, one of the active Ramp functions has not yet reached its end value.
Position demand value generator:
Chapter "7.1.2.5 Ramp", page 59
Pressure demand value generator:
Chapter "7.1.3.5 Ramp", page 70
