7 Pump functions
<AccelerationTime>
This parameter defines the output signal's maximum rate of change. The acceleration time corresponds to the
time that the signal needs for a change of 0 to 100 % as shown in the figure above.
The acceleration time can be specified in seconds with the gradation 1 s, 100 ms, 10 ms, 1 ms.
7.1.2.5.2 Ramp type 2 - two-quadrant ramp
This function limits the input signal's rate of change to an acceleration time and a deceleration time.
Activated with ramp type (0x6330) = 2.
Chapter "7.1.2.5 Ramp", page 59
Description of the acceleration time parameter:
Chapter "7.1.2.5.1 Ramp type 1 - one-quadrant ramp", page 60
+ 100 %
- 100 %
+ 100 %
- 100 %
ValvePositionControl_DemandValueGenerator_Ramp
Index
Subindex
0x6334
1
0x6334
2
0x6334
3
Chapter "1.6.2 Definition of unit and prefix", page 5
© Moog GmbH
input
output
<AccelerationTime>
Figure 20: Ramp type 2
Name
DecelerationTime
Unit
DecelerationTime_Prefix
USER MANUAL Firmware RKP-D (B99224-DV007-CE400; Version 1.1, 09/08)
<DecelerationTime>
Data type
Access
UINT16
rw
UINT8
ro
INT8
rw
Demand Value Generator
t
t
Persis-
Value
tence
range
Default
Y
UINT16
0
N
UINT8
3
Y
-4...0
-3
61
