7.2.2.1 Stroke ring control monitoring

7.2.2.1.1 Deviation monitoring
ValvePositionControl_ControlMonitoring
Index Subindex
0x6350 1
0x6350 2
0x6350 3
0x6351 0
0x6352 1
0x6352 2
0x6352 3
0x6354 1
0x6354 2
0x6354 3
0x6355 1
0x6355 2
0x6355 3
Chapter "1.6.2 Definition of unit and prefix", page 5
<ControlDeviation>
The value of this parameter corresponds to the difference between the position demand value (0x6310) and
the position actual value (0x6301).
Chapter "7.1.2.1 Object 0x6310: Demand value", page 56
Chapter "6.3.1.1 Object 0x6301: Actual position value", page 46
<Type>
This parameter is used to select the control monitoring type or to turn off the control monitoring.
Values description
<DelayTime>
The delay time defines the minimal duration of a control deviation after which a fault will be displayed.
<UpperThreshold>
This parameter defines the upper threshold of the control deviation's tolerance band.
<LowerThreshold>
This parameter defines the upper threshold of the control deviation's tolerance band.
The <LowerThreshold> value cannot be greater than the <UpperThreshold> value.
