6 Signal routing and scaling
6.2.1.6 Object 0x6394: Pressure hold setpoint
This parameter defines the pressure hold setpoint that is transferred via the bus in the control modes:
• Control pressure closed loop
• Control pressure open loop
• p/Q closed loop
It corresponds to the position setpoint in the device states 'HOLD' and 'FAULT_HOLD'.
ValvePressureControl_DemandValueGenerator
Index
Subindex
0x6394
1
0x6394
2
0x6394
3
Chapter "1.6.2 Definition of unit and prefix", page 5
Whether this parameter will affect the control is influenced by the following:
• Device mode
Chapter "6.2.1.7 Object 0x6042: Device mode", page 45
• Control mode
Chapter "7.2.1.1 Object 0x6043: Control mode", page 76
• Device status
Chapter "5.3.5 Object 0x6041: Status word", page 29
© Moog GmbH
Name
Data type
HoldSetPoint
INT16
Unit
UINT8
Prefix
INT8
USER MANUAL Firmware RKP-D (B99224-DV007-CE400; Version 1.1, 09/08)
Persis-
Value
Access
tence
range
rw
Y
INT16
ro
N
UINT8
ro
N
INT8
Command value path
Default
0
0
0
44
