Moog CURLIN 8000 Quick Start Manual

CURLIN 8000 PUMP
FRONT VIEW
1
2
3
7
1. On/Off button
2. Soft keys (3)
3. Numeric keypad
4. Infusion status indicator lights (see
below for additional information)
5. Pause button
6. Up and Down arrow buttons
7. OK <Enter> button
8. Help button
9. Bolus button
(for patient use only)
STATUS INDICATOR LIGHTS
The three infusion status indicator lights are located to the right of the screen
and provide visual confirmation of the status of the infusion:
• Green: The pump is running at the programmed rate
• Yellow: The pump is paused
• Red: Infusion is stopped due to an alarm or infusion is complete with no keep vein open (KVO) programmed
Yellow Green:
• and
Green Red:
• and Infusion is complete and KVO is running
Yellow Red:
• and Infusion is complete, KVO is programmed, and infusion is paused due to an alarm
These instructions are not a substitute for the CURLIN
8000 User Manual or Patient Information Guides.
Please refer to the CURLIN 8000 User Manual or individual Patient
Information Guides for a full list of Warnings, Cautions, and more detailed
instructions. Scan the QR code to view available user manuals and guides.
BACK VIEW
4
5
6
8
9
10. Moog Clinical Support
phone number
11. Pump serial number (the
large and bolded number
shown on the bottom line)
12. Battery compartment door
13. Battery compartment door
lock (slide right to unlock,
slide left to lock)
Delay start with no KVO programmed, infusion will start automatically at scheduled time
11
10
12
13
Quick Start Guide
SIDE VIEW
14. Bolus / data port
15. Power port
16. External AC power
indicator light
14
15
16
