7 Pump functions
7.2.8.1 Objects 0x2600 - 0x2606 / 0x2608: Power limitation
<Power_Maximum>
If this maximum power value is reached, the flow demand is reduced.
PumpController
Index Subindex
0x2600 0
<Power_ProportionalGain>
The proportional gain of the power limitation controller.
PumpController
Index Subindex
0x2601 0
<Power_PT1Gain>
The gain of the PT1 element.
PumpController
Index Subindex
0x2602 0
<Power_PT1TimeConstant>
The time constant of the PT1 element in seconds.
PumpController
Index Subindex
0x2603 0
<Power_PT1Shift>
The <Power_PT1Shift> defines the threshold above which the power deviation is passed through.
PumpController
Index Subindex
0x2604 0
<Power_DifferentialGain>
The differentiator gain of the power limitation controller.
PumpController
Index Subindex
0x2605 0
© Moog GmbH
Name Data type
Power_Maximum INT16
Name Data type
Power_ FLOAT32
ProportionalGain
Name Data type
Power_PT1Gain FLOAT32
Name Data type
Power_ FLOAT32
PT1TimeConstant
Name Data type
Power_PT1Shift INT16
Name Data type
Power_DifferentialGain FLOAT32
USER MANUAL Firmware RKP-D (B99224-DV007-CE400; Version 1.1, 09/08)
Persis-
Access tence Value range
rw Y 0...16384
Persis-
Access tence Value range
rw Y 0...+inf
Persis-
Access tence Value range
rw Y 0...+inf
Persis-
Access tence Value range
rw Y 0...+inf
Persis-
Access tence Value range
rw Y 0...32767
Persis-
Access tence Value range
rw Y 0...+inf
Controller
Default
DSV
Default
DSV
Default
DSV
Default
DSV
Default
DSV
Default
DSV
