Comtech EF Data HPOD Installation And Operation Manual page 85

Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Auxiliary AUX= 1 byte
Mute Enable
value of 0,1
BUC Mute BCM= 1 byte
State
value of 0,1
Low Forward FPT= 5 bytes,
Power numerical
Threshold
Low Forward FPA= 1 byte
Power Mask
value of 0,1
Clear All CAA= None
Stored
Alarms
Serial-Based Remote Product Management
Description of Arguments
Command or Query.
Enable or disable the auxiliary mute mode, in the form x, where:
0 = Disabled
1 = Enabled
Example:(AUX Mute Enabled): AUX=1'cr'
Note: When enabled, Pin H of the J6 COMM 1 connector must
be grounded to UN-MUTE unit. Otherwise, unit will be muted,
and if a mute query is given (MUT?) the response will be MUT=2
to indicate a hardware-controlled mute is present.
Command or Query.
Mute the unit, in the form x, where:
0 = BUC Muted
1 = BUC Not Muted
Example: BCM=1'cr' would allow the BUC to transmit
Note: Only active if the optional BUC is installed.
Command or Query.
Sets or returns the threshold for the low forward power fault in the
form xxx.x:
NOTES:
1) If the forward power drops below the specified value, a fault may
be indicated based on FPA setting.
Example: <0001/FPT=030.0'cr'
Command or Query.
Sets or returns the low forward power mask in the form x, where:
0= FAULT
1=MASK
Example: <1/FPA=1'cr'
Command only.
Clears all Stored Events:
Example:
<1/CAA='cr'
>0001/CAA='cr''lf'
Note: This command takes no arguments.
HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier
5–12
Query
Response to Response to
(Instruction &
Command
Qualifier)
AUX= AUX? AUX=x
AUX?
AUX* (See
Description of
Arguments)
BCM= BCM? BCM=x
BCM?
BCM* (See
Description of
Arguments)
FPT= FPT? FPT=xxx.x
FPT?
FPT*
FPA= FPA? FPT=x
FPA?
FPA* (See
Description of
Arguments)
CAA= N/A N/A
MN/HPOD.IOM
Revision 9
Query
