Comtech EF Data HPOD Installation And Operation Manual page 84

Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Overdrive OVR= 1 byte,
Protection
value of 0, 1
Mode
Overdrive OVU= 4 bytes,
Trigger Level numerical
Overdrive ODF= 1 byte,
Protection
value of 0, 1
Mode Mask
Set Backup SBO= 7 bytes,
Offset numerical
Serial-Based Remote Product Management
Description of Arguments
Command or Query.
Sets or returns the overdrive mode in the form x, where:
0=Disabled (DEFAULT)
1=Enabled
Example: <1/OVR=1'cr'
Command or Query.
Sets or returns the overdrive trigger level in the form xx.x, where:
xx.x=P1dB rated to (P1dB rated - 10.00, in dB)
Default value: P1dB rated value.
Example: <0001/OVU=42.5{CR}
NOTES:
Maximum value can be 10.0. However, current customer
attenautation (ATT) setting will factor into how large OVU value
can be used. For example: if ATT is 12.00 and ATT max range is
20.0, then maximum value OVU can set to is 8.0.
Command or Query.
Sets or returns the overdrive mode mask in the form x, where:
0= FAULT
1=ALARM
Example: <1/ODF=1'cr'
NOTES: In Fault mode, if an overdrive fault is triggered, the
amplifier will be muted, and a summary fault activated. In Alarm
mode, only a log is recorded.
Command or Query.
Set or query the adjusted attenuation level, in 0.25 dB
increments, in a 1:2 redundant system so power is equal
between the online and offline units when a switchover occurs. In
the form #,xx.xx where:
# = 1 or 2
xx.xx = level, in 0.25 dB increments
Examples: SBO=1,02.00'cr' or SBO=2,02.50'cr'
5–11
HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier
Query
Response to
(Instruction &
Command
Qualifier)
OVR= OVR?
OVR?
OVR*
OVU= OVU?
OVU?
OVU*
ODF= ODF?
ODF?
ODF*
SBO= SBO?
SBO?
SBO*
Revision 9
Response to
Query
OVR=x
(See
Description of
Arguments)
OVU=xx.x
(See
Description of
Arguments)
ODF=x
(See
Description of
Arguments)
SBO=#,xx.xx
(See
Description of
Arguments)
MN/HPOD.IOM
