Table A-10. C-Band Offline Unit Termination Bypass Waveguide Kit (Comtech P/N Kt-0020523) Parts List - Comtech EF Data HPOD Installation And Operation Manual

A.3.7 C-Band Offline Unit Termination Bypass Waveguide Kit (Comtech P/N KT-0020523)

Table A-10. C-Band Offline Unit Termination Bypass Waveguide Kit (Comtech P/N KT-0020523) Parts List

ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Appendix A
QTY Comtech P/N
1 FP/BR12242-1
1 SW/WG-3NFAS-COLD
1 FP/WG10359-1
1 RF/CG-137-40-N
1 FP/5683
1 FP-0020546
6 CB/CX50NMALE
56 HW/10-FLT
48 HW/10-SPLIT
2 GA/CPR137-R-F-C
5 GA/CPR137-R-H-C
40 HW/10-32X5/8SHC
8 HW/10-32HEXNUT
8 HW/10-32X3/4SH
2 HW/3/8SPRINGNUT
2 HW/3/8-FLT
2 HW/3/8-SPLIT
2 HW/3/8-16X1BLT
DESCRIPTION
Bracket, Mount (ROHS)
Switch, CPR 137
Waveguide
Crossguide, WR 137
Waveguide Adapter
Waveguide, CPRG 137
Connector, CN-50-OHM, Type 'N', Male
Washer, #10 Flat
Lock Washer, #10 Split
Gasket, CPR 137, Full Height
Gasket, CPR 137, Half Height
Screw, Socket Head #10-32 x 5/8 LG
Hex Nut,3/8
Screw, Socket Head #10-32 x 3/4 LG
Spring Nut, 3/8
Washer, Flat, 3/8
Lock Washer, Split, 3/8
Bolt, Hex Head, 3/8-16 x 1" LG
A–26
