Connector
Group
(Section)
RF Signal
(Sect. 2.3)
Ground and
Power
(Sect. 2.4)
Electrical
Control
Interface
(Sect. 2.5)
External Connectors and Pinouts

Figure 2-3. HPOD External Connectors

Table 2-1. HPOD SSPA External Connectors

Ref
Item Connector Name
Des
1 J1 RF IN
2 J2 RF OUT
3 N/A N/A
4 J3 AC IN
– J10 N/A
REDUNDANT
5 J4
LOOP
6 J6 COM1
7 J8 INPUT SAMPLE
8 J9 OUTPUT SAMPLE
HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier
Connector Type
Type 'N' female
Waveguide Flange
M4 Stud
3-Pin Circular Conn.
4-Pin Circular Conn.
19-Pin Circular
Conn.
19-Pin Circular
Conn.
Type 'N' female
Type 'N' female
2–3
Revision 9
Connector Function
RF Input
RF Output
Common Chassis
Ground
Prime Input AC Power
Optional -48VDC
Power
Redundancy operation
SSPA M&C
-20 dB input signal
sample
-40 dB output signal
sample
MN/HPOD.IOM
