C.2

Replace the Power Supply

C.2.1 Remove the Old Power Supply
The SSPA/power supply interconnection is waterproof only when the power supply and
SSPA are mated. When exposed, the connection is only water-resistant. Do not leave
the SSPA or power supply exposed to the elements unless properly mated and
assembled.

Figure C-1. Remove/Replace the HPOD Power Supply

To remove the old power supply, do these steps:
Step Task
1 Disconnect the HPOD SSPA from its power source.
2 Loosen the four captive fasteners as shown in Figure C-1.
3 Remove the power supply from the SSPA.
Appendix C
Be sure to use an appropriate screwdriver, such as the one
provided with the SSPA, to avoid damaging the fasteners.
