Upper Steering Yoke; Installation - APRILIA TUAREG 660 Service Station Manual

TUAREG 660
•
Remove the upper steering yoke (11).

Installation

To install the upper steering triple clamp, proceed
as described:
•
Position the ignition assembly (1) on
the upper steering triple clamp (2) and
secure it by tightening the two screws
(3) to torque.
•
Position the upper steering triple clamp
(2) in its seat, insert the bush (4) com-
plete with washer (5) and tighten it to
torque.
•
Working from both sides, tighten the
screws (6) securing the stanchions to
the upper triple clamp to torque.
Suspensions
SUSP - 145
