Electrical system
Fuses
To check the fuses it is necessary to remove the seats to access the auxiliary fuses and the left side
panel to access the main fuse
It is necessary to check the fuses whenever an electrical component fails to operate or malfunctions or
when the engine does not start.
Start by checking the secondary fuses in order of size (from the lowest amperage fuse to the highest),
and then check the 30A main fuse.
CAUTION
DO NOT ATTEMPT TO REPAIR FAULTY FUSES.
NEVER USE A FUSE THAT IS DIFFERENT THAN WHAT IS SPECIFIED TO PREVENT DAMAGES
TO THE ELECTRICAL SYSTEM OR SHORT CIRCUITS, AND THE RISK OF FIRE.
CAUTION
A FUSE THAT BLOWS FREQUENTLY MAY INDICATE A SHORT CIRCUIT OR OVERLOAD. CON-
TACT AN authorised aprilia Dealer.
To check:
•
To avoid an accidental short-circuit,
place the power switch to "OFF".
•
Remove the passenger and rider sad-
dles.
•
Open the covers of the secondary fuse
boxes (1).
