REPEATER OPERATION
2.
Subaudible tones
Some repeaters require subaudible tones to access
Subaudible tones are superimposed over your normal
signal and must be set in advance
1 Set the operating frequency
2 Push [SET LOCK] to enter the Set mode
3 Repeatedly push [SET LOCK] or [MONI ANM PA]
to select " " and "rt" (Repeater Tone frequency)
4 Rotate [DIAL] to select the desired frequency
5 Push any key other than [SET LOCK] or
[MONI ANM PA] to save and exit the Set mode
Using the HM-133V
1 Set the operating frequency
L The subaudible tone frequency or code can be
independently set for each Memory channel, Call
channel, and the VFO mode
2 Push [SET B D-OFF] to enter the Set mode
3 Repeatedly push [SET B D-OFF] or
[ENT C T-OFF] to select " " and "rt" (Repeater
Tone frequency)
4 Push [▲] or [▼] to select the desired frequency.
L Hold down [▲] or [▼] to sequentially change the
frequencies
5 Push [CLR A MW] to save and exit the Set mode
DTone information
Some repeaters require a different tone system to be
accessed
DTMF codes
You can enter and transmit a DTMF code or manually
transmit a DTMF tone
See pages 6-2 and 6-4 for details
DTCS codes
The DTCS encoder superimposes the selected DTCS
code over your transmitted signal
See page 7-8 for details
L See the CTCSS tone or DTCS code (p 7-2)
NOTE:
• If you do not know the subaudible tone or DTCS
code used for a repeater, the tone scan is
convenient for detecting it See page 7-7 for
details
• The subaudible tone frequency can be temporarily
set in a Memory or Call channel However,
when another Memory channel or VFO mode is
selected, the set frequency is deleted To save the
tone frequency, overwrite the channel setting
DIGITAL PRIO AO BUSY
MUTE
NAR
MID
LOW
LOCK ANM
S ET MONI
The Repeater Tone frequency item
Selectable Repeater Tone frequencies (unit: Hz)
670 797 948 1109
693 825 974 1148
719 854 1000 1188
744 885 1035 1230
770 915 1072 1273
2-6
1318 1567 1713 1862 2035
1365 1598 1738 1899 2065
1413 1622 1773 1928 2107
1462 1655 1799 1966 2181
1514 1679 1835 1995 2257
2291
2336
2418
2503
2541
