SuperServer E403-9D-16C-IPD2/E403-9D-14CN-IPD2 User's Manual

Quick Reference Table

Jumper Description
J1 M.2 SMBus Enable/Disable
JBM1 IPMI Share LAN Enable/Disable
JBM2 IPMI Dedicated/Share LAN Enable/Disable
JBT1 CMOS Clear
JI C1/JI C2 SMB to PCIe Slots Enable/Disable
2 2
JPG1 VGA Enable/Disable
JPL1 LAN1 Enable/Disable
JPL2 LAN2/3/4/5 Enable/Disable
JPL3 LAN6/7/8/9 Enable/Disable
JPME2 Manufacturing Mode Select
JPT1 TPM Enable/Disable
JPUSB1 USB0/1 Wake up
JVRM1 VRM SMB Data (to BMC or PCH)
JWD1 Watch Dog Timer
LED Description
LED1 Power LED
LED2 UID LED
LED3 Overheat/Power Fail/Fan Fail LED
LEDM1 BMC Heartbeat
Connector
BT1
COM1/COM2
FAN1 - FAN4, FANA, FANB
IPMI LAN
JD1
JF1
JGP1
JIPMB1
JL1
JLANLED1
JLANLED2
JLANLED3
JMD1
Table continued on next page.
Description
Onboard Battery
COM1: Port, COM2: Header
CPU/System Fan Headers
Dedicated IPMI LAN Port
Power LED/Speaker Header (Pins 1-3: Power LED, Pins 4-7: Speaker)
Front Control Panel Header
General Purpose I/O Header
System Management Bus Header (for IPMI only)
Chassis Intrusion Header
LAN1 Activity LED Header
LAN2-5 Activity LED Header
LAN6-9 Activity LED Header
M.2 Slot M-Key 2280/22110 (SATA3.0 / PCIe x4)
50
Default Setting
Pins 1-2 (Enabled)
Open: Enabled (Default)
Closed: Disabled
Open: Enabled (Default)
Closed: Disabled
Open: Normal
Closed: Clear CMOS
Pins 2-3 (Disabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Normal)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (BMC)
Pins 1-2 (Reset)
Status
Solid Green: Power On
Solid Blue: Unit Identified
Solid Red: Overheat
Blinking Red: Power Failure/Fan Failure
Blinking Green: BMC Normal
