Appendix C: System Specifications
Appendix C
System Specifications
Processors
E403-9D-16C-IPD2: Single Intel® Xeon® D-2183IT
E403-9D-14CN-IPD2: Single Intel® Xeon® D-2177NT
Note: Refer to the motherboard specifications page on our website for updates to supported processors.
BIOS
512Mb AMI BIOS® SPI Flash BIOS
Plug and Play (PnP), ACPI 6.1, BIOS rescue hot-key, SMBIOS 2.8/3.1, PCI F/W 3.2 RTC Wakeup, UEFI 2.7
Memory
Supports up to 256GB of ECC RDIMM or 512GB of ECC LRDIMM DDR4-2400 memory in four DIMM slots
Storage Drives
Four internal SATA3 2.5" drive bays
Expansion Slots
Two PCIe 3.0 x16 or two PCIe 3.0 x8 + one PCIe 3.0 x16 (FHFL) slots
One M.2 M-Key 2280/22110
One M.2 B-Key 3042
One M.2 E-Key 2230
Input/Output
Four SATA3 (6Gbps) ports supporting RAID 0, 1, 5, 10
USB: two USB 3.0 ports, two USB 2.0 ports
Serial Port: one COM via RJ45
Video: one VGA port
Network
Nine RJ45 10GbE LAN ports, four 10G SFP+ LAN ports, one RJ45 dedicated IPMI LAN port
Motherboard
E403-9D-16C-IPD2: X11SDW-16C-TP13F+
E403-9D-14CN-IPD2: X11SDW-14CN-TP13F+
Dimensions: 8" x 10" (203.2 mm x 254 mm)
Enclosure
B403-IP65; (WxHxD) 12.56 x 32.31 x 10.16 in. (319 x 821 x 258 mm)
System Cooling
Three 80 x 80-mm chassis fans, three 80 x 80-mm waterproof enclosure fans
Server Power Supply
Model: PWS-601D-1R, 600W DC multi-output power supply with PFC; 92%+ efficiency
DC Voltage (terminal block input connector)
-44VDC to -65VDC
+5V standby: 3A
+12V: 50A
Server Power
-44VDC to 59VDC, 900W maximum
