1.2 System Features

The table below gives an overview of the main features included with the SuperServer
SYS-E403-9D-16C-IPD2/E403-9D-14CN-IPD2.
Processor
SYS-E403-9D-16C-IPD2: Single Intel® Xeon® D-2183IT
SYS-E403-9D-14CN-IPD2: Single Intel® Xeon® D-2177NT
Motherboard
SYS-E403-9D-16C-IPD2: X11SDW-16C-TP13F+
SYS-E403-9D-14CN-IPD2: X11SDW-14CN-TP13F+
Chassis
Enclosure: B403-IP65
Inner Chassis: CSE-E403iF-000NBP2
Memory
Supports up to 256GB of ECC RDIMM or 512GB of ECC LRDIMM DDR4-2400 memory in four DIMM slots
Chipset
System on Chip
Expansion Slots
Either two PCIe 3.0 x16 or two PCIe 3.0 x8 + one PCIe 3.0 x16 (FHFL) slots
One M.2 M-Key 2280/22110 (SATA3.0 / PCIe x4)
One M.2 B-Key 2242/3042 (USB2.0 / USB3.0 / SATA3.0 / PCIe x2)
One M.2 E-Key Slot 2230 (USB2.0 / PCIe x1)
Input/Output
USB: two USB 3.0 ports (front), two USB 2.0 ports (front)
Serial Port: one COM via RJ45
Video: VGA port
Network
One RJ45 dedicated IPMI LAN port
Four SPF+ ports
Nine GbE LAN ports
Storage Drives
Four internal SATA3 2.5" drive bays, Intel
Power
Enclosure: -44 to -59VDC power, 900W maximum
Server: 600W -48VDC
Cooling
Enclosure: Three PWM redundant fans
Server Chassis: Three 80x80mm PWM redundant fans
Dimensions (IP65 Enclosure)
IP65 Enclosure (WxHxD) 12.56 x 32.31 x 10.16 in. (319 x 821 x 258 mm)
System Features
RSTe, RAID 0, 1, 5, 10
®
