1.1 Overview

This chapter provides a brief outline of the functions and features of the outdoor DC platform
SuperServer SYS-E403-9D-16C-IPD2/E403-9D-14CN-IPD2. Applications for these servers
include 5G Radio Access Network (RAN), Multi-Access Edge Computing (MEC), Edge AI
Inferencing, Vehicle to Everything (C-V2X/V2X) and Virtualized Functions and Services.
The server is suitable for Network Telecommunication Facilities and Outside Plants. These
Outdoor Edge systems are based on the E403-9D-14CN-FRDN13+/E403-9D-16C-FRDN13+
embedded server and the B403-IP65 IP65 Enclosure.
In addition to the server and chassis, several important parts that are included with the server
are listed below.
Description
Weather resistance IP65 enclosure
Power and control board
SuperServer Embedded Server
E403-9D-14CN-IPD2 E403-9D-14CN-FRDN13+
E403-9D-16C-IPD2 E403-9D-16C-FRDN13+
N o t e : t h e f o l l o w i n g
SYS-E403-9D-16C-IPD2/E403-9D-14CN-IPD2 have been certified as compliant with UL or
CSA: B403-IP and B403-IPOE.
Chapter 1
Introduction
Main Parts List
Model Variation Table
Motherboard
X11SDW-14CN-TP13F+
X11SDW-16C-TP13F+
s a f e t y m o d e l s
8
Part Number Quantity
CSE-B403-IP65 1
PDB-PT403-1400 1
IP65 Power Dist.
Enclosure Board
B403-IP65 PDB-PT403-1400
B403-IP65 PDB-PT403-1400
a s s o c i a t e d w i t h t h e
