SuperServer
®
SYS-E200-12A-4C
SYS-E200-12A-8C
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SuperServer SYS-E200-12A-4C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Supermicro SuperServer SYS-E200-12A-4C

Summary of Contents for Supermicro SuperServer SYS-E200-12A-4C

  • Page 1 SuperServer ® SYS-E200-12A-4C SYS-E200-12A-8C USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    SuperServer SYS-E200-12A-4C/8C User's Manual Contents Contacting Supermicro ......................6 Chapter 1 Introduction 1.1 Overview ..........................7 1.2 System Features ........................8 Front View ...........................8 Control Panel ........................8 1.3 Motherboard Layout ......................10 Quick Reference Table ......................11 System Block Diagram ......................13 1.4 Server Installation and Setup .....................14 Unpacking the System ......................14...
  • Page 5 Preface Explanation of Jumpers.....................34 3.5 LED Indicators ........................37 Chapter 4 Software 4.1 SuperDoctor 5 ........................38 ® 4.2 BMC ............................39 BMC ADMIN User Password ....................39 Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications...

  • Page 6: Contacting Supermicro

    SuperServer SYS-E200-12A-4C/8C User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support)

  • Page 7: Chapter 1 Introduction

    Form Factor Mini-iTX: 7.6" x 1.7" x 8.9" (193 x 43 x 226mm) (WxHxD) Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the SYS-E200-12A-4C/8C have been certified...

  • Page 8: System Features

    Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Control Panel Figure 1-1. Front View Control Panel NIC LEDs HDD LED Information LED Power Fail LED Reset Button Power Button Figure 1-2.
  • Page 9 Chapter 1: Introduction Information LED Color, Status Description An overheat condition has occurred. (This may be caused by Red, solid cable congestion.) Red, blinking at 1Hz Fan failure, check for an inoperative fan. Red, blinking at 0.25Hz Power failure, check for a non-operational power supply. UID has been activated locally to locate the server in a rack Blue, solid environment.

  • Page 10: Motherboard Layout

    Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the A3SPI-4C-HLN4F/8C-HN4LF motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 3 or the Motherboard...

  • Page 11: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBM1 Disable IPMI Shared LAN Pins 1-2 Open: Enable JBM2 Disable IPMI Dedicated LAN Pins 1-2 Open: Enable JBT1 CMOS Clear Open: Normal JDB1 COM Port or BMC Debug Port Select Open: COM PORT Pins 1-2: SATA (Default) JNS1...
  • Page 12 Chapter 1: Introduction Connector Description JPH1 4-pin HDD and NVMe HDD Power Connector Power Supply SMBus I C Header (if the power supply has the PMbus 1x5 (male) pin) JPV1 8-pin 12V DC Power Connector JPW1 24-pin ATX Power Connector JRT3 Thermal Diode Header JSD1...

  • Page 13: System Block Diagram

    Chapter 1: Introduction System Block Diagram The block diagram below shows the connections and relationships between the subsystems and major components of the overall system. CPLD SMBus LCMXO2-1200HC LCMXO2 - VGA CONNECTOR UART1 AST2500 AST2500 COM1 HEADER TACHOMETER Fan x3 (Zone1/2) RGMII2 1000BASE-T...

  • Page 14: Server Installation And Setup

    Chapter 1: Introduction 1.4 Server Installation and Setup The server is shipped with the onboard processor and the motherboard installed in the chassis. Several steps are necessary to begin using your server. You must add memory, mount the hard disk drive, and mount the system in place. Unpacking the System Inspect the box in which the system was shipped and note if it was damaged.

  • Page 15: Installing Mounting Brackets

    Chapter 1: Introduction Installing Mounting Brackets Optional brackets allow the server to be mounted in any convenient space in the work environment. 1. Install the brackets, using two screws through the holes in each bracket to secure the bracket to the chassis. 2.

  • Page 16: Installing Rack Mounting Brackets

    Chapter 1: Introduction Installing Rack Mounting Brackets The chassis can be mounted in a rack using two rack brackets and a two-part power adapter shelf bracket (optional, MCP-290-10110-0B). 1. Attach the rack brackets using three screws through the holes in each bracket to secure the bracket to the chassis.

  • Page 17: Chapter 2 Maintenance And Component Installation

    Chapter 2: Maintenance and Component Installation Chapter 2 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 18: Accessing The System

    Chapter 2: Maintenance and Component Installation 2.2 Accessing the System The CSE-101F features a removable top cover to access to the inside of the chassis. Figure 2-1. Removing the Chassis Cover Removing the Top Cover 1. Power down the system as described in section 2.1. 2.

  • Page 19: Memory Support And Installation

    Chapter 2: Maintenance and Component Installation 2.3 Memory Support and Installation Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The A3SPI-4C-HLN4F/8C-HN4LF motherboard supports up to 128GB of DDR4 ECC RDIMM memory to 2400 MT/s (4C) and 2933 MT/S (8C).
  • Page 20 Chapter 2: Maintenance and Component Installation JPG1 SFP2 SFP1 LAN5 LAN6 LAN3 LAN1 AST2500 LAN4 LAN2 JDB1 A3SPI-8C-LN6PF REV:1.01 JVR1 LEDT4 LEDT3 JGP1 LEDM1 COM1 LEDT2 LEDT1 SRW1 JPH1 JBT1 JPF1 DIMMA1 DIMMB1 JPW1 JMD1 JMD2 JPV1 JRT3 JSIM1 SRW2 JTPM1 JPT1 LED1 JFP1...

  • Page 21: Installing Memory

    Chapter 2: Maintenance and Component Installation Installing Memory When installing memory modules, the DIMM slots should be populated in the following order: DIMMA1, DIMMB1. • Always use DDR4 DIMM modules of the same size, type and speed. Mixing memory modules of different types and speeds is not allowed. •...

  • Page 22: Solid State Storage

    Chapter 2: Maintenance and Component Installation Solid State Storage This motherboard supports an internally mounted solid state storage card by means of an M.2 slot supporting PCIe. Figure 2-3. Installing an M.2 Expansion Card Installing the M.2 Card 1. Access the motherboard and locate the M.2 connector (Figure 1.6, JMD1: M2) 2.

  • Page 23: Motherboard Battery

    Chapter 2: Maintenance and Component Installation Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Figure 2-4. Installing the Onboard Battery Replacing the Battery 1.

  • Page 24: Chassis Components

    Chapter 2: Maintenance and Component Installation 2.4 Chassis Components System Cooling The CSE-101F includes two 4 cm fans. Replacing the System Fan 1. Power down the system as described in section 2.1 and remove the AC power cord and the chassis cover. 2.

  • Page 25: Chapter 3 Motherboard Connections

    Chapter 3 Motherboard Connections Chapter 3 Motherboard Connections This section describes the connections on the A3SPI-4C-HLN4F/8C-HN4LF motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 26: Headers And Connectors

    SuperServer SYS-E200-12A-4C/8C User's Manual 3.2 Headers and Connectors Fan Headers This motherboard has four 4-pin fan headers. Pins 1-3 of the fan headers are backward compatible with the traditional 3-pin fans, but using 4-pin fans takes advantage of the fan speed control via Pulse Width Modulation through the BMC.
  • Page 27 The JTPM1 header is used to connect a Trusted Platform Module (TPM), which is available from Supermicro or a third-party vendor. A TPM is a security device that supports encryption and authentication in hard drives. It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.
  • Page 28 SuperServer SYS-E200-12A-4C/8C User's Manual System Management Bus Header A System Management Bus header for additional slave devices or sensors is located at JSMB1. SMBus Header Pin Definitions Pin# Definition Data Ground Clock No Connection LAN Port Activity LED Headers JTGLED1 is the activity header for LAN3 and LAN4.
  • Page 29 Chapter 3 Motherboard Connections M.2 Slot Pin Definitions (JMD1 M-Key) M.2 Slot Pin Definitions (JMD2 B-Key) Pin# Definition Pin# Definition Pin# Definition Pin# Definition P3V3_DUAL P3V3SB USB_JMD2_DP P3V3_DUAL P3V3SB USB_JMD2_DN FULL_CARD_POWER_ OFF#(PU to P1V8SB only) USB_D+ W_DISABLE1#(PU to P3V3SB only) USB_D- UART_BT_ WAKE_R_N...

  • Page 30: Control Panel

    SuperServer SYS-E200-12A-4C/8C User's Manual Control Panel JFP1 contains header pins for various control panel connections. See the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All JFP1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the motherboard.
  • Page 31 Chapter 3 Motherboard Connections Overheat (OH)/Fan Fail Connect an LED cable to pins 7 and 8 of JFP1 (Front Control Panel) to use the Overheat/ Fan Fail/Power Fail and UID LED connections. The blue LED on pin 7 works as the front panel UID LED indicator.

  • Page 32: Ports

    SuperServer SYS-E200-12A-4C/8C User's Manual 3.3 Ports Rear I/O Ports Description Description IPMI LAN Port LAN4 USB1 LAN3 USB0 VGA Port LAN2 UID Switch/LED LAN1 (Shares NIC) Ethernet Ports Four Gigabit Ethernet ports (LAN1–4) and an IPMI LAN port provide network connections.
  • Page 33 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at https://www.supermicro.com/ support/manuals/. UID Switch...

  • Page 34: Jumpers

    SuperServer SYS-E200-12A-4C/8C User's Manual 3.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 35 Chapter 3 Motherboard Connections VGA Enable/Disable Jumper JPG1 allows you to enable or disable the VGA port using the onboard graphics controller. The default setting is Enabled. VGA Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled (Default) Pins 2-3 Disabled ME Manufacturing Mode Select Close JPME2 to bypass SPI flash security and force the system to use the Manufacturing...
  • Page 36 SuperServer SYS-E200-12A-4C/8C User's Manual ATX/Force PS-ON Mode Select Use jumper JPF1 to select ATX or Force PS-ON Mode (default). Refer to the table below for pin definitions. ATX/Force PS-ON Mode Jumper Settings Jumper Setting Definition Pins 1-2 ATX Mode Pins 2-3...

  • Page 37: Led Indicators

    Chapter 3 Motherboard Connections 3.5 LED Indicators LAN LEDs Each Ethernet port on the I/O back panel has two LEDs. One LED indicates activity when flashing, while the other (Link) LED may be green, amber or off to indicate the speed of the connection.

  • Page 38: Chapter 4 Software

    4.1 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 39: Bmc

    There are several BIOS settings that are related to BMC. For general documentation and information on BMC, visit our website at: www.supermicro.com/en/solutions/management-software/bmc-resources BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.

  • Page 40: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 41 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 42 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 43 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 44 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 45 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告 システムコンポーネントの取り付けまたは取り外しのために、...
  • Page 46 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 47 Appendix A: Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 48 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 49 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 50 Appendix A: Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 51 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 52 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 53 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 54 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 55 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 56 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 57 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 58 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 59 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 60: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors SYS-E200-12A-4C: Single Intel Atom® Processor C5315SuperServerSuperServer in an FCBGA2106 socket SYS-E200-12A-8C: Single Intel Atom® Processor C5325 in an FCBGA2106 socket Note: Refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel®...
  • Page 61 Appendix B: System Specifications Regulatory Compliance FCC, ICES, CE, VCCI, RCM, UKCA, NRTL, CB Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 EN/BS EN55032 EN/BS EN55035 CISPR 32 CISPR 35 EN/BS 61000-3-2...

This manual is also suitable for:

Superserver sys-e200-12a-8c
