Quick Reference Table

Jumper
JBT1
JPF1
JPG1
JPL1
JPT1
JSEL1
LED
LE1
LED1
LED2
LED6
LED9
Connector
BT1
CN1, CN2
COM1
FAN1 – FAN4
I-SATA1–2
J17
JF1
JIPMB1
JL1
JOH1
JPI2C1
JPWR1
JPWR2
JRK1
JSTBY1
JTPM1
JUIDB1
JVGA1
LAN1–13
Description
CMOS Clear
Power Force On
VGA Enable/Disable
LAN1 Enable/Disable
Onboard TPM Module Enable/Disable
SMA1 to SMA4 Voltage Level Selection
Description
Power LED
BMC Heartbeat LED
UID LED
Power/Fan Fail LED
GNSS Timepulse LED
Description
Extended CMOS Battery
PCIe 5.0 x8 MCIO Connectors
COM Header
Fan Headers
SATA 3.0 Ports
Dry Contact Connector
Front Control Panel Header
4-pin BMC External I C Header (for an IPMI card)
2
Chassis Intrusion Header
Overheat LED Header
Power System Management Bus (SMB) I
8-pin Power Connector (Required). Need to connect 24-pin ATX power cable to 8-pin
8-pin 12 V DC Power Connector (Required)
Intel RAID Key Header
Standby Power Header (5 V)
Trusted Platform Module/Port 80 Connector
Unit Identifier (UID) Button
VGA Header
LAN Ports
16
Chapter 1: Introduction
Default Setting
Open (Normal)
Pins 1-2 (Power Button On)
Pins 2-3 (Force Power On)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enablled)
Pins 1-2 (3.3 V)
Pins 2-3 (5 V)
Status
Solid Green: Power On
Blinking Green: BMC Normal
Solid Blue: Unit Identified
Solid Red: Power/Fan Failed
Blinking Blue: Timepulse Normal
C Header
2
