- Page 1 SuperServer ® SYS-E302-12A-4C SYS-E302-12A-8C USER’S MANUAL Revision 1.0...
- Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
- Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...
-
Page 4: Table Of Contents
SuperServer SYS-E302-12A-4C/8C User's Manual Contents Contacting Supermicro ......................6 Chapter 1 Introduction 1.1 Overview ..........................7 1.2 System Features ........................8 Front View ...........................8 Control Panel ........................8 1.3 Motherboard Layout ......................10 Quick Reference Table ......................11 System Block Diagram ......................13 Chapter 2 Server Installation 2.1 Overview ..........................14... - Page 5 Preface Motherboard Battery ......................27 3.5 Chassis Components ......................28 Installing the Storage Drive ....................28 Chapter 4 Motherboard Connections 4.1 Power Connections ......................31 4.2 Headers and Connectors ....................32 Control Panel ........................36 4.3 Ports ...........................38 4.4 Jumpers ..........................40 Explanation of Jumpers.....................40 4.5 LED Indicators ........................43 Chapter 5 Software 5.1 SuperDoctor 5 ........................44...
-
Page 6: Contacting Supermicro
SuperServer SYS-E302-12A-4C/8C User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) -
Page 7: Chapter 1 Introduction
Form Factor Compact: 11.6" x 2.9" x 8.1" (295 x 73 x 205mm) (WxHxD) Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the SYS-E302-12A-4C/8C have been certified... -
Page 8: System Features
Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Power LED HDD LED Power Button Figure 1-1. Front View System Features: Front Feature Description The main power switch applies or removes primary power from the power supply to the Power button server but maintains standby power. - Page 9 Chapter 1: Introduction Rear View IPMI LAN Port SATA Drive Bay Power Input K-slot VGA Port Two SFP+ Ports Four GbE LAN Ports USB 3.0 Ports Figure 1-2. System: Rear View System Features: Rear Feature Description The main power switch applies or removes primary power from the power supply to the Power input server but maintains standby power.
-
Page 10: Motherboard Layout
Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the A3SPI-4C-LN6PF/8C-LN6PF motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 3 or the Motherboard... -
Page 11: Quick Reference Table
Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBM1 Disable IPMI Shared LAN Pins 1-2 Open: Enable JBM2 Disable IPMI Dedicated LAN Pins 1-2 Open: Enable JBT1 CMOS Clear Open: Normal JDB1 COM Port or BMC Debug Port Select Open: COM PORT Pins 1-2: SATA (Default) JNS1... - Page 12 Chapter 1: Introduction Connector Description JPH1 4-pin HDD and NVMe HDD Power Connector Power Supply SMBus I C Header (if the power supply has the PMbus 1x5 (male) pin) JPV1 8-pin 12V DC Power Connector JPW1 24-pin ATX Power Connector JRT3 Thermal Diode Header JSD1...
-
Page 13: System Block Diagram
Chapter 1: Introduction System Block Diagram The block diagram below shows the connections and relationships between the subsystems and major components of the overall system. CPLD SMBus LCMXO2-1200HC LCMXO2 - VGA CONNECTOR UART1 AST2500 AST2500 COM1 HEADER TACHOMETER Fan x3 (Zone1/2) RGMII2 1000BASE-T... -
Page 14: Chapter 2 Server Installation
Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory, etc., refer to Chapter 3 for details on installing those components. Caution: Electrostatic Discharge (ESD) can damage electronic components. -
Page 15: Server Precautions
Chapter 2: Server Installation • In single-rack installations, stabilizers should be attached to the rack. In multi-rack installations, the racks should be coupled together. • Always verify that the rack is stable before extending a server or other component from the rack. -
Page 16: Mechanical Loading
Chapter 2: Server Installation Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. -
Page 17: Adding Components To Your System
Chapter 2: Server Installation Adding Components to your System • Memory: If your system is not already fully integrated with system memory, refer to Chapter 3 for details on compatible types of memory and the installation procedure. • Drives and Storage: To add storage capabilities to your server, see Chapter 3. •... -
Page 18: Mounting On A Wall
Chapter 2: Server Installation 2.3 Mounting on a Wall The chassis can be mounted on a wall using a bracket (optional, MCP-290-30201-0B). Secure the bracket to the wall where you want the server to be mounted by using four screws through the holes around the center of the bracket, as shown below. Bracket Screws Figure 2-1. - Page 19 Chapter 2: Server Installation With the input/output ports facing up, hang the server on the mounting bracket by hooking the four keyholes on the bottom of the chassis on the four knobs of the bracket. Figure 2-3. Hanging Server on the Bracket Secure the chassis to the bracket by sliding the latch back down and flipping the tab to lock it in place.
- Page 20 Chapter 2: Server Installation The power adapter can be secured to this lower bracket by partially unscrewing its latch, sliding the latch upward, placing the power adapter in the bracket, lowering the latch, and tightening the screw to secure it in place. Power Adapter Bracket Latch Screw of Power Adapter Bracket Latch Figure 2-5.
-
Page 21: Chapter 3 Maintenance And Component Installation
Chapter 3 Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system. -
Page 22: Accessing The System
Chapter 3 Maintenance and Component Installation 3.2 Accessing the System The CSE-302iL features a removable top cover to access the inside of the chassis. Screws Screws Figure 3-1. Removing the Chassis Cover Removing the Top Cover 1. Power down the system as described in section 3.1. 2. -
Page 23: Static-Sensitive Devices
Chapter 3 Maintenance and Component Installation 3.3 Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid damaging your motherboard, it is important to handle it very carefully. The following measures are generally sufficient to protect the system PCBs from ESD. Precautions •... -
Page 24: Memory Support And Installation
Chapter 3 Maintenance and Component Installation 3.4 Memory Support and Installation Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The A3SPI-4C-LN6PF/8C-LN6PF motherboard supports up to 128GB of DDR4 ECC RDIMM memory to 2400 MT/s (4C) and 2933 MT/S (8C). - Page 25 Chapter 3 Maintenance and Component Installation JPG1 SFP2 SFP1 LAN5 LAN6 LAN3 LAN1 AST2500 LAN4 LAN2 JDB1 A3SPI-8C-LN6PF REV:1.01 JVR1 LEDT4 LEDT3 JGP1 LEDM1 COM1 LEDT2 LEDT1 SRW1 JPH1 JBT1 JPF1 DIMMA1 DIMMB1 JPW1 JMD1 JMD2 JPV1 JSIM1 JRT3 SRW2 JTPM1 JPT1 LED1 JFP1...
-
Page 26: Installing Memory
Chapter 3 Maintenance and Component Installation Installing Memory When installing memory modules, the DIMM slots should be populated in the following order: DIMMA1, DIMMB1. • Always use DDR4 DIMM modules of the same size, type and speed. Mixing memory modules of different types and speeds is not allowed. •... -
Page 27: Motherboard Battery
Chapter 3 Maintenance and Component Installation Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Figure 3-3. Installing the Onboard Battery Replacing the Battery 1. -
Page 28: Chassis Components
Chapter 3 Maintenance and Component Installation 3.5 Chassis Components Installing the Storage Drive The CSE-302iL can accommodate one fixed 2.5" storage drive of 7mm height and one 2.5" drive of 15mm height, installed to a mounting tray inside the chassis. Figure 3-4. - Page 29 Chapter 3 Maintenance and Component Installation Installing the Hard Drive The motherboard should be installed before installing the drive(s). 1. Make sure there is no power to the system as described in section 3.1 and remove the chassis cover. 2. See section 3.2 for instructions on how to remove the top cover. 3.
- Page 30 Chapter 3 Maintenance and Component Installation Figure 3-6. Installing a 7mm 2.5" Hard Drives 5. Optionally, for a 7mm 2.5" drive, slide it inside the tray first, then secure it to the drive tray with the standoff plugs as shown above. 6.
-
Page 31: Chapter 4 Motherboard Connections
Chapter 4 Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the A3SPI-4C-LN6PF/8C-LN6PF motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1. -
Page 32: Headers And Connectors
Chapter 4 Motherboard Connections 4.2 Headers and Connectors Fan Headers This motherboard has four 4-pin fan headers. Pins 1-3 of the fan headers are backward compatible with the traditional 3-pin fans, but using 4-pin fans takes advantage of the fan speed control via Pulse Width Modulation through the BMC. - Page 33 The JTPM1 header is used to connect a Trusted Platform Module (TPM), which is available from Supermicro or a third-party vendor. A TPM is a security device that supports encryption and authentication in hard drives. It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.
- Page 34 Chapter 4 Motherboard Connections System Management Bus Header A System Management Bus header for additional slave devices or sensors is located at JSMB1. SMBus Header Pin Definitions Pin# Definition Data Ground Clock No Connection LAN Port Activity LED Headers JTGLED1 is the activity header for LAN3 and LAN4. LAN Activity LED Pin Definitions Pin#...
- Page 35 Chapter 4 Motherboard Connections M.2 Slot Pin Definitions (JMD1 M-Key) M.2 Slot Pin Definitions (JMD2 B-Key) Pin# Definition Pin# Definition Pin# Definition Pin# Definition P3V3_DUAL P3V3SB USB_JMD2_DP P3V3_DUAL P3V3SB USB_JMD2_DN FULL_CARD_POWER_ OFF#(PU to P1V8SB only) USB_D+ W_DISABLE1#(PU to P3V3SB only) USB_D- UART_BT_ WAKE_R_N...
-
Page 36: Control Panel
Chapter 4 Motherboard Connections Control Panel JFP1 contains header pins for various control panel connections. See the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All JFP1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the motherboard. - Page 37 Chapter 4 Motherboard Connections Overheat (OH)/Fan Fail Connect an LED cable to pins 7 and 8 of JFP1 (Front Control Panel) to use the Overheat/ Fan Fail/Power Fail and UID LED connections. The blue LED on pin 7 works as the front panel UID LED indicator.
-
Page 38: Ports
Chapter 4 Motherboard Connections 4.3 Ports Rear I/O Ports Description Description Description BMC_LAN LAN1 (Share NIC) (RJ45 GbE) LAN5 (SFP+ 10GbE) USB1 LAN4 (RJ45 GbE) USB0 LAN3 (RJ45 GbE) UID Switch LAN2 LAN6 (SFP+ 10GbE) Ethernet Ports (GbE) Four Gigabit Ethernet ports (LAN1–4) and an IPMI LAN port provide network connections. These ports accept RJ45 type cables. - Page 39 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at https://www.supermicro.com/ support/manuals/. UID Switch...
-
Page 40: Jumpers
Chapter 4 Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations. - Page 41 Chapter 4 Motherboard Connections VGA Enable/Disable Jumper JPG1 allows you to enable or disable the VGA port using the onboard graphics controller. The default setting is Enabled. VGA Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled (Default) Pins 2-3 Disabled ME Manufacturing Mode Select Close JPME2 to bypass SPI flash security and force the system to use the Manufacturing...
- Page 42 Chapter 4 Motherboard Connections ATX/Force PS-ON Mode Select Use jumper JPF1 to select ATX or Force PS-ON Mode (default). Refer to the table below for pin definitions. ATX/Force PS-ON Mode Jumper Settings Jumper Setting Definition Pins 1-2 ATX Mode Pins 2-3 Force PS-ON Mode IPMI Shared LAN Enable/Disable Set the JBM1 jumper to enabled to share LAN1 with IPMI.
-
Page 43: Led Indicators
Chapter 4 Motherboard Connections 4.5 LED Indicators LAN LEDs Each Ethernet port on the I/O back panel has two LEDs. One LED indicates activity when flashing, while the other (Link) LED may be green, amber or off to indicate the speed of the connection. -
Page 44: Chapter 5 Software
5.1 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP). -
Page 45: Bmc
There are several BIOS settings that are related to BMC. For general documentation and information on BMC, visit our website at: www.supermicro.com/en/solutions/management-software/bmc-resources BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user. -
Page 46: Appendix A Standardized Warning Statements For Ac Systems
Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/... - Page 47 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
- Page 48 Appendix A: Warning Statements . ٌ ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز ٍ...
- Page 49 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .יש...
- Page 50 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
- Page 51 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告 システムコンポーネントの取り付けまたは取り外しのために、...
- Page 52 Appendix A: Warning Statements אזהרה מפני ניתוק חשמלי !אזהרה יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק .לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد انطاقت...
- Page 53 Appendix A: Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !אזהרה .צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד واملدربيه...
- Page 54 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
- Page 55 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
- Page 56 Appendix A: Warning Statements هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل اسحبذال البطارية فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
- Page 57 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
- Page 58 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
- Page 59 Appendix A: Warning Statements هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
- Page 60 Appendix A: Warning Statements תיאום חוקי החשמל הארצי !אזהרה .התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة بالكهرباء 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
- Page 61 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. סילוק המוצר !אזהרה .סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה التخلص...
- Page 62 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
- Page 63 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
- Page 64 .قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحيUL وأCSA ( ةمالع لمحت يتلاوUL/CSA) لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عمSupermicro.
- Page 65 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
-
Page 66: Appendix B System Specifications
Appendix B: System Specifications Appendix B System Specifications Processors SYS-E302-12A-4C: Single Intel Atom® Processor C5315 in an FCBGA2106 socket SYS-E302-12A-8C: Single Intel Atom® Processor C5325 in an FCBGA2106 socket Note: Refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel®... - Page 67 Appendix B: System Specifications Regulatory Compliance FCC, ICES, CE, VCCI, RCM, UKCA, NRTL, CB Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 EN/BS EN55032 EN/BS EN55035 CISPR 32 CISPR 35 EN/BS 61000-3-2 EN/BS 61000-3-3 EN/BS 61000-4-2...
