SATA Ports
The X11SDW-16C-TP13F+/X11SDW-14CN-TP13F+ has four S-SATA 3.0 ports. Refer to the
tables below for pin definitions. SATA ports provide serial-link signal connections, which are
faster than the connections of Parallel ATA.
M.2 Slot
The X11SDW-16C-TP13F+/X11SDW-14CN-TP13F+ has four M.2 slots. M.2 was formerly
known as Next Generation Form Factor (NGFF). M.2 allows for a variety of card sizes,
increased functionality, and spatial efficiency. The M.2 slot at JMD1 supports PCIe 3.0 x4
and SATA 3.0 interfaces in a 2280/22110 form factor, whereas the M.2 slot at JMD2 supports
PCIe 3.0 x4, SATA 3.0, and USB 3.0 interfaces in a 3042 form factor. The M.2 slot at JMD3
supports PCIe 3.0 x1.
TPM/Port 80 Header
A Trusted Platform Module (TPM)/Port 80 header is located at JTPM1 to provide TPM support
and a Port 80 connection. Use this header to enhance system performance and data security.
Refer to the table below for pin definitions.
SATA 3.0 Port
Pin Definitions
Pin# Signal
1 Ground
2 SATA_TXP
3 SATA_TXN
4 Ground
5 SATA_RXN
6 SATA_RXP
7 Ground
Trusted Platform Module Header
Pin Definitions
Pin# Definition Pin# Definition
1 +3.3V 2 SPI_CS#
3 RESET# 4 SPI_MISO
5 SPI_CLK 6 GND
7 SPI_MOSI 8
9 +3.3V Stby 10 SPI_IRQ#
