Item Features
1 Hoist Rings
2 Server
3 Info LEDs
Power & Control
4
Board
5 Grounding
6 Test Button
Cabinet
7
Intrusion
8 DC Power Input
9 Heat Exchanger
10 Cable Gland
11 Buckle
Number Description
1 Thermal Sensor
2 Server Power
3 Heater Power
4 Control Power
5 Fan1
6 Fan2
7 Fan3
8 Fan4
9 Intrusion
IP65 Enclosure Features
Description
Rings for lifting the system
SYS-E403-9D-16C-IPD2 or SYS-E403-9D-14CN-IPD2
See table below for details. LEDs are numbered 1-9 from top to bottom.
Internal environment control
Grounding strip
Button to run self-diagnostics
Intrusion mechanism to send notice that the enclosure has been opened
DC power input terminal
Transfers internal heat to external cooling airflow
2" cable gland for cable inlet/outlet (may be replaced with a 2" conduit hub)
Used to lock the B403-IP65 enclosure
Info LEDs
Indication
Red light: thermal sensor fail
Green light on: power is being supplied to the server
Light off: no power being supplied to the server
Green light: heater is on
Red light: heater fail
Light off: heater is off
Green light on: system in powered on
Green light blinking: enclosure under test
Green: fan1 is operating
Red: fan fail
Light off: no power to Fan1
Green: fan2 is operating
Red: fan fail
Light off: no power to Fan2
Green: fan3 is operating
Red: fan fail
Light off: no power to Fan3
Green: fan4 is operating
Red: fan fail
Light off: no power to Fan4
Intrusion detected
