3.2 Accessing the Server

Open the fan cover to access the server fans. Remove the entire server cover to access
other server components. Remove the hard drive cage, the expansion card module, and the
air shroud to access the motherboard.
Accessing the Server Fans
The server fans can be accessed without powering down the system.
1. Remove the two screws on the fan cover. See the figure below.
2. Flip open the fan cover to access the server fans.
Chapter 3: Maintenance and Component Installation
Figure 3-1. Removing Fan Cover Screws
