SuperServer
®
E302-9D
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SuperServer E302-9D

Summary of Contents for Supermicro SuperServer E302-9D

  • Page 1 SuperServer ® E302-9D USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 Preface About this Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer E302-9D. Installation and maintenance should be performed by experienced technicians only. Notes For your system to work properly, please follow the links below to download all necessary drivers, utilities and the user’s manual for your server.

  • Page 4: Table Of Contents

    SuperServer E302-9D User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................7 1.2 System Features ........................8 1.3 Chassis Features .........................9 Front Features ........................9 Rear Features ........................10 Chassis Dimensions ......................11 1.4 Motherboard Layout ......................12 Quick Reference Table ......................13 System Block Diagram ......................15 Chapter 2 Server Installation 2.1 Overview ..........................16...
  • Page 5 Preface Motherboard Battery ......................28 3.4 Chassis Components ......................29 Installing the Storage Drive ....................29 Chapter 4 Motherboard Connections 4.1 Power Connections ......................32 4.2 Headers and Connectors ....................33 4.3 Rear I/O Ports ........................38 4.4 Front Control Panel ......................40 4.5 Jumpers ..........................43 Explanation of Jumpers ....................43 4.6 LED Indicators ........................46 Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................47...
  • Page 6 SuperServer E302-9D User's Manual Contacting Supermicro Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 7: Chapter 1 Introduction

    Introduction 1.1 Overview The SuperServer E302-9D is a compact, embedded system comprised of the CSE-E302iL chassis and the X11SDV-4C-TP8F single processor motherboard. Refer to our website for information on operating systems that have been certified for use with the system (www.

  • Page 8: System Features

    SuperServer E302-9D User's Manual 1.2 System Features The following table provides an overview of the main features of the E302-9D. Please refer to Appendix D for additional specifications. System Features Motherboard X11SDV-4C-TP8F-01 Chassis CSE-E302iL Intel Xeon D-2123IT 4C 8T 60W...

  • Page 9: Chassis Features

    Chapter 1: Introduction 1.3 Chassis Features The CSE-E302iL is a compact embedded 1U chassis for Mini ITX and Flex ATX motherboards. Front Features The front of the chassis includes the control panel. Figure 1-1. Chassis Front and Control Panel Control Panel Features Item Features Description...

  • Page 10: Rear Features

    SuperServer E302-9D User's Manual Rear Features The chassis rear holds input/output ports, described in Chapter 4. Figure 1-2. Rear Chassis View Rear Chassis Features Item Features Description The main power switch applies or removes primary power from the power supply Power input to the server but maintains standby power.

  • Page 11: Chassis Dimensions

    Chapter 1: Introduction Chassis Dimensions The compact chassis measures 295.2 x 205 mm from the top view and 295.2 x 73.3 mm from the I/O view. 275.20 mm 295.20 mm Figure 1-3. Chassis Dimensions (Top View) 275.20 mm 295.20 mm Figure 1-4.

  • Page 12: Motherboard Layout

    SuperServer E302-9D User's Manual 1.4 Motherboard Layout Below is a layout of the X11SDV-4C-TP8F with jumper, connector, and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pin-out information, and jumper settings, refer to Chapter 4.

  • Page 13: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open: Normal, Closed: Clear CMOS JI2C1, JI2C2 SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disabled) JNS1 Mini-SAS HDD NVMe/SATA Mode Select Pins 1-2: SATA (Default) Pins 2-3: NVMe JPG1 Onboard VGA Enable Pins 1-2 (Enabled)
  • Page 14 SuperServer E302-9D User's Manual Connector Description JPV1 12V 8-pin DC Power Connector (Required to provide extra power to CPU, or as alternative power for special enclosure when the 24 pin ATX power is not in use) JSD1 SATA Disk On Module (DOM) Power Connector JSIM1 Nano SIM Slot for M.2 B-Key WAN card support...

  • Page 15: System Block Diagram

    Chapter 1: Introduction System Block Diagram DDR4 1866/2133/2400 DDR4 1866/2133/2400 JLAN2 JLAN1 PCIE 3.0 x8 PCIE 3.0 x4 JPCIE1 SLOT7 PCIE 3.0 x8 I350 AM4 PE2[15:12] PE2[7:0] PCIE 3.0 x16 PE1[15:0] JPCIE2 SLOT6 PCIE 3.0 x16 PCIE 3.0 x4 PE2[11:8] M.2(M-key)CONN JLAN3 10G PHY...

  • Page 16: Chapter 2 Server Installation

    SuperServer E302-9D User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory, etc., refer to Chapter 3 for details on installing those components.

  • Page 17: Server Precautions

    Chapter 2: Server Installation • In single-rack installations, stabilizers should be attached to the rack. In multi-rack instal- lations, the racks should be coupled together. • Always verify that the rack is stable before extending a server or other component from the rack.

  • Page 18: Mechanical Loading

    SuperServer E302-9D User's Manual Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.

  • Page 19: Adding Components To Your System

    Chapter 2: Server Installation Adding Components to your System • Memory: If your system is not already fully integrated with system memory, refer to Chapter 3 for details on compatible types of memory and the installation procedure. • Drives and Storage: To add storage capabilities to your server, see Chapter 3. •...

  • Page 20: Mounting On A Wall

    SuperServer E302-9D User's Manual 2.3 Mounting on a Wall The chassis can be mounted on a wall using a bracket (optional, MCP-290-30201-0B). 1. Secure the bracket to the wall where you want the server to be mounted by using four screws through the holes around the center of the bracket, as shown below.
  • Page 21 Chapter 2: Server Installation 3. With the input/output ports facing up, hang the server on the mounting bracket by hooking the four keyholes on the bottom of the chassis on the four knobs of the bracket. Figure 2-3. Hanging Server on the Bracket 4.
  • Page 22 SuperServer E302-9D User's Manual 6. The power adapter can be secured to this lower bracket by partially unscrewing its latch, sliding the latch upward, placing the power adapter in the bracket, lowering the latch, and tightening the screw to secure it in place.

  • Page 23: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 24: Accessing The System

    SuperServer E302-9D User's Manual 3.2 Accessing the System The CSE-E302iL features a removable top cover to access the inside of the chassis. Screws Screws Figure 3-1. Removing the Chassis Cover Removing the Top Cover 1. Power down the system as described in section 3.1.

  • Page 25: Motherboard Components

    Chapter 3: Maintenance and Component Installation 3.3 Motherboard Components Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Attention: This system requires the installation of heat spreaders to the memory RAM.

  • Page 26: Dimm Module Population Sequence

    SuperServer E302-9D User's Manual DIMM Module Population Sequence When installing memory modules, the DIMM slots should be populated in the following order: DIMMB1, DIMMA1, DIMME1, DIMMD1. • Always use DDR4 DIMM modules of the same type, size, and speed. •...

  • Page 27: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation JPB1:(debug only) PRESS FIT JPL1: 1-2:ENABLE 2-3:DISABLE 1. Insert the desired number of DIMMs into IPMI_LAN LAN 3/4 LAN 1/2 USB 4/5 (3.0) the memory slots, starting with DIMMB1, LEDM1 LAN 5/6 JPG1 DIMMA1, DIMME1, then DIMMD1.

  • Page 28: Motherboard Battery

    SuperServer E302-9D User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1.

  • Page 29: Chassis Components

    Chapter 3: Maintenance and Component Installation 3.4 Chassis Components Installing the Storage Drive The CSE-E302iL can accommodate two fixed 2.5" storage drives of 7 mm height or one 2.5" drive of 15 mm height, installed to a mounting tray inside the chassis. Figure 3-4.
  • Page 30 SuperServer E302-9D User's Manual Installing the Hard Drive The motherboard should be installed before installing the drive(s). 1. Make sure there is no power to the system as described in section 3.1 and remove the chassis cover. 2. See section 3.2 for instructions on how to remove the top cover.
  • Page 31 Chapter 3: Maintenance and Component Installation Figure 3-6. Installing 7 mm 2.5" Hard Drives 5. Optionally, for 7 mm 2.5" drives, slide them inside the tray first, then secure them to the drive tray with the standoff plugs as shown above. 6.

  • Page 32: Chapter 4 Motherboard Connections

    SuperServer E302-9D User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 33: Headers And Connectors

    Chapter 4: Motherboard Connections Secondary Power Connector JPV1 must also be connected to the power supply. This connector is used to power the process and provides alternative power for special enclosure when the 24-pin ATX power is not in use. +12V 8-pin Power Pin Definitions Pin#...
  • Page 34 NC = No Connection NVMe I C Header JNVI2C1 is a management header for the Supermicro AOC NVMe PCI-E peripheral cards. Connect a corresponding I C cable to this header. Refer to the table below for pin definitions. C Header...
  • Page 35 Chapter 4: Motherboard Connections Standby Power The +5V Standby Power header is located at JSTBY1 on the motherboard. You must have a card with a Standby Power connector and a cable to use this feature. Refer to the table below for pin definitions. Standby Power Pin Definitions Pin#...
  • Page 36 SuperServer E302-9D User's Manual TPM/Port 80 Header A Trusted Platform Module (TPM)/Port 80 header is located at JTPM1 to provide TPM support and a Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions.
  • Page 37 Chapter 4: Motherboard Connections LAN Activity LED Headers JTGLED1 is the activity LED header for LAN7 and LAN8, and JTGLED2 is the activity header for LAN5 and LAN6. LAN Activity LED LAN Activity LED Pin Definitions Pin Definitions Pin# Definition Pin# Definition 3V3 Stby...

  • Page 38: Rear I/O Ports

    SuperServer E302-9D User's Manual 4.3 Rear I/O Ports See Figure 4-1 below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 4-1. I/O Port Locations and Definitions Rear I/O Ports Item Description...
  • Page 39 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at https://www.supermicro.com/ support/manuals/. UID Button...

  • Page 40: Front Control Panel

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 41 Chapter 4: Motherboard Connections Power Fail LED The Power Fail LED connection is located on pins 5 and 6 of JF1. Refer to the table below for pin definitions. Power Fail LED Pin Definitions (JF1) Pin# Definition 3.3V PWR Supply Fail Overheat (OH)/Fan Fail Connect an LED cable to pins 7 and 8 of the Front Control Panel to use the Overheat/Fan Fail LED connections.
  • Page 42 SuperServer E302-9D User's Manual Power LED The Power LED connection is located on pins 15 and 16 of JF1. See the table below for pin definitions. Power LED Pin Definitions (JF1) Pin# Definition 3.3V PWR LED NMI Button The non-maskable interrupt (NMI) button header is located on pins 19 and 20 of JF1. Refer to the table below for pin definitions.

  • Page 43: Jumpers

    Chapter 4: Motherboard Connections 4.5 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 44 SuperServer E302-9D User's Manual LAN Port Enable/Disable Use jumper JPL1 to enable or disable LAN1 - LAN4. Refer to the table below for jumper settings. LAN Port Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled (Default) Pins 2-3 Disabled...
  • Page 45 Chapter 4: Motherboard Connections SMBus to PCI-E Slots Use jumpers JI2C1 and JI2C2 to enable PCI-E SMB (System Management Bus) support to improve system management for the onboard PCI-E slot. SMBus to PCI-E Slots Jumper Settings Jumper Setting Definition Pins 1-2 Enabled Pins 2-3 Disabled (Default)

  • Page 46: Led Indicators

    SuperServer E302-9D User's Manual 4.6 LED Indicators LAN LEDs Eight LAN ports (LAN1 - LAN8) are located on the I/O back panel. Each Ethernet LAN port has two LEDs. The green LED indicates activity, while the other Link LED may be green, amber, or off to indicate the speed of the connection.

  • Page 47: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 48 SuperServer E302-9D User's Manual 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner.

  • Page 49: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash drive or a DVD.

  • Page 50: Superdoctor ® 5

    FTP, and SMTP services to optimize the efficiency of your operation. Note: The default username and password for SuperDoctor 5 is ADMIN/ADMIN. Figure 5-4. SuperDoctor 5 Interface Display Screen (Health Information) Note: The SuperDoctor 5 program and user’s manual can be downloaded from the Supermicro website at http://www.supermicro.com/products/nfo/sms_sd5.cfm.

  • Page 51: Ipmi

    There are several BIOS settings that are related to IPMI. Supermicro ships standard products with a unique password for the BMC ADMIN user. This password can be found on a label on the motherboard. For general documentation and information on IPMI, please visit our website at: http://www.supermicro.com/products/nfo/IPMI.cfm.

  • Page 52: Chapter 6 Uefi Bios

    SuperServer E302-9D User's Manual Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the X11SDV-4C-TP8F motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 53: Main Menu

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is the BIOS build date after RTC reset. Supermicro X11SDV-4C-TP8F BIOS Version This feature displays the version of the BIOS ROM used in the system.

  • Page 54: Advanced Settings Menu

    SuperServer E302-9D User's Manual 6.3 Advanced Settings Menu Use this menu to configure advanced settings. Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect BIOS timing setting may cause the system to malfunction.
  • Page 55 Chapter 6: UEFI BIOS INT19 (Interrupt 19) Trap Response Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup immediately and allow the drives that are attached to these host adaptors to function as bootable disks.
  • Page 56 SuperServer E302-9D User's Manual • Processor Max Ratio • Processor Min Ratio • Microcode Revision • L1 Cache RAM • L2 Cache RAM • L3 Cache RAM • Processor 0 Version Hyper-Threading (ALL) Select Enabled to support Intel Hyper-threading Technology to enhance CPU performance.
  • Page 57 Chapter 6: UEFI BIOS DCU Streamer Prefetcher (Available when supported by the CPU) Select Enable to enable the DCU (Data Cache Unit) Streamer Prefetcher which will stream and prefetch data and send it to the Level 1 data cache to improve data processing and system performance.
  • Page 58 SuperServer E302-9D User's Manual ENERGY_PERF_BIAS_CFG Mode The Energy Perfomance BIAS (EPB) feature allows the user to configure CPU power and performance settings. Select Maximum Performance to set the highest performance. Select Performance to optimize performance over energy efficiency. Select Balanced Performance to prioritize performance optimization while conserving energy.
  • Page 59 Chapter 6: UEFI BIOS Hardware PM State Control  Hardware P-States This setting allows the user to select between OS and hardware-controlled P-states. Selecting Native Mode allows the OS to choose a P-state. Selecting Out of Band Mode allows the hardware to autonomously choose a P-state without OS guidance. Selecting Native Mode with No Legacy Support functions as Native Mode with no support for older hardware.
  • Page 60 SuperServer E302-9D User's Manual Chipset Configuration  Warning: Setting the wrong values in the sections below may cause the system to malfunction. North Bridge Configuration  Memory Configuration  Enforce POR Select POR (Plan of Record) to enforce POR restrictions on DDR4 frequency and volt- age programming.
  • Page 61 Chapter 6: UEFI BIOS Static Virtual Lockstep Mode Select Enable to run the system's memory channels in lockstep mode to minimize memory access latency. The options are Disable and Enable. Mirror mode This feature allows memory to be mirrored between two channels, providing 100% redundancy.
  • Page 62 SuperServer E302-9D User's Manual Patrol Scrub Patrol Scrub is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source). When this feature is set to Enable, the IO hub will read and write back one cache line every 16K cycles if there is no delay caused by internal processing.
  • Page 63 Chapter 6: UEFI BIOS PCI-E Port Link Status This feature shows the status of the device plugged into this slot. PCI-E Port Link Max This feature shows the status of the device plugged into this slot. PCI-E Port Link Speed This feature shows the status of the device plugged into this slot.
  • Page 64 SuperServer E302-9D User's Manual Prioritize TPH Use this feature to enable Prioritize TPH support. The options are Enable and Disable. Relaxed Ordering Select Enable to enable Relaxed Ordering support, which will allow certain transac- tions to violate the strict-ordering rules of PCI bus for a transaction to be completed prior to other transactions that have already been enqueued.
  • Page 65 Chapter 6: UEFI BIOS Intel® VMD Technology  Intel® VMD for Volume Management Device on CPU  VMD Config for PStack0 Intel® VMD for Volume Management Device Select Enable to use the Intel Volume Management Device Technology for this stack. The options are Disable and Enable.
  • Page 66 SuperServer E302-9D User's Manual Port 60/64 Emulation Select Enabled for I/O port 60h/64h emulation support, which in turn will provide complete legacy USB keyboard support for the operating systems that do not support legacy USB devices. The options are Disabled and Enabled.
  • Page 67 Chapter 6: UEFI BIOS Aggressive Link Power Management When this feature is set to Enable, the SATA AHCI controller manages the power usage of the SATA link. The controller will put the link in a low power mode during extended periods of I/O inactivity, and will return the link to an active state when I/O activity resumes.
  • Page 68 SuperServer E302-9D User's Manual Configure sSATA as Select AHCI to configure an sSATA drive specified by the user as an AHCI drive. Select RAID to configure an sSATA drive specified by the user as a RAID drive. The options are AHCI and RAID.
  • Page 69 Chapter 6: UEFI BIOS PCIe/PCI/PnP Configuration  The following information will display: • PCI Bus Driver Version • PCI Devices Common Settings Above 4G Decoding (Available if the system supports 64-bit PCI decoding) Select Enabled to decode a PCI device that supports 64-bit in the space above 4G Address. The options are Disabled and Enabled.
  • Page 70 SuperServer E302-9D User's Manual 1. Enable AMI Native Support in the Advanced > NVME Firmware Source menu. 2. After the installation is complete, enable Boot Option 1 for the NVMe device. Go to Boot > UEFI Hard Disk Drive BBS Priorities > Boot Option # 1 > NVMe device.
  • Page 71 Chapter 6: UEFI BIOS Onboard LAN Option ROM Type Use this feature to select the option for onboard LAN devices. The options are Legacy and EFI. Select Legacy to display and configure the Onboard LAN1 - LAN8 Option ROM features. Onboard LAN1 Option ROM Use this feature to select which option for LAN Port 1 is used for system boot.
  • Page 72 SuperServer E302-9D User's Manual Media Detect Count Use this option to specify the number of times media will be checked. Press "+" or "-" on your keyboard to change the value. The default setting is 1. Super IO Configuration ...
  • Page 73 Chapter 6: UEFI BIOS Serial Port Console Redirection  COM1 Console Redirection Select Enabled to enable COM Port 1 for Console Redirection, which will allow a client machine to be connected to a host machine at a remote site for networking. The options are Disabled and Enabled.
  • Page 74 SuperServer E302-9D User's Manual Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 75 Chapter 6: UEFI BIOS Terminal Type Use this feature to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support. Select ANSI to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 76 SuperServer E302-9D User's Manual Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled. Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support. The options are 80x24 and 80x25.
  • Page 77 Chapter 6: UEFI BIOS Out-of-Band Mgmt Port The feature selects a serial port in a client server to be used by the Microsoft Windows Emergency Management Services (EMS) to communicate with a remote host server. The options are COM1 and SOL. Terminal Type Use this feature to select the target terminal emulation type for Console Redirection.
  • Page 78 SuperServer E302-9D User's Manual High Precision Event Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback and reducing the dependency on other timestamp calculation devices, such as an x86 RDTSC Instruction embedded in the CPU.
  • Page 79 Chapter 6: UEFI BIOS SMCI BIOS-Based TPM Provision Support Use feature to enable the Supermicro TPM Provision support. The options are Disabled and Enabled. TXT Support Intel TXT (Trusted Execution Technology) helps protect against software-based attacks and ensures protection, confidentiality, and integrity of data stored or created on the system. Use this feature to enable or disable TXT Support.
  • Page 80 Use this feature to disable or enable Platform Hierarchy (PH) Randomization. The options are Disabled and Enabled. SMCI BIOS-Based TPM Provision Support Use feature to enable the Supermicro TPM Provision support. The options are Disabled and Enabled. TXT Support Intel TXT (Trusted Execution Technology) helps protect against software-based attacks and ensures protection, confidentiality, and integrity of data stored or created on the system.

  • Page 81: Event Logs

    Chapter 6: UEFI BIOS 6.4 Event Logs Use this menu to configure event log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Change this feature to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 82 SuperServer E302-9D User's Manual MECI (Multiple Event Count Increment) Enter the increment value for the multiple event counter. Enter a number between 1 to 255. The default setting is 1. METW (Multiple Event Count Time Window) This feature is used to determine how long (in minutes) the multiple event counter should wait before generating a new event log.

  • Page 83: Ipmi

    Chapter 6: UEFI BIOS 6.5 IPMI Use this menu to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This feature indicates the IPMI firmware revision in your system. IPMI STATUS This feature indicates the status of the IPMI firmware installed in your system. System Event Log Enabling/Disabling Options SEL Components...
  • Page 84 SuperServer E302-9D User's Manual When SEL is Full This feature allows the user to determine what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full.
  • Page 85 Chapter 6: UEFI BIOS Gateway IP Address This feature displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). VLAN This feature is configurable if the Update IPMI LAN Configuration feature is set to Yes. Use this feature to enable or disable the IPMI VLAN function.
  • Page 86 The boot up time is faster when the option is Disabled. When this feature is disabled, the user cannot use Supermicro Update Manager (SUM) OOB (out of band) to update the BIOS, nor utilize the extended IPMI features such as AOC and PCIe sensor readings, and the BMC network configuration in the BIOS setup is also disabled.

  • Page 87: Security

    Chapter 6: UEFI BIOS 6.6 Security Use this menu to configure the security settings for the system. Administrator Password Use this feature to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long. Password Check Select Setup for the system to check for a password at Setup.
  • Page 88 SuperServer E302-9D User's Manual CSM Support This feature is for manufacturing debugging purposes. Key Management This submenu allows the user to configure the following Key Management settings. Factory Key Provision Select Enabled to install the default Secure Boot keys set by the manufacturer. The options are Disabled and Enabled.
  • Page 89 Chapter 6: UEFI BIOS Update Select Yes to load a factory default PK or No to load from a file on an external media. Delete Select Ok to remove the PK and then the system will reset to Setup/Audit Mode. ...
  • Page 90 SuperServer E302-9D User's Manual  Forbidden Signatures Details Select this feature to view the details of the dbx. Export Select Yes to export a dbx from a file on an external media. Update Select Yes to load a factory default dbx or No to load from a file on an external media.
  • Page 91 Chapter 6: UEFI BIOS Append Select Yes to add the dbr from the manufacturer's defaults list to the existing dbr. Select No to load the dbr from a file. The options are Yes and No. Delete Select Ok to remove the dbr and then the system will reset to Setup/Audit Mode.

  • Page 92: Boot

    SuperServer E302-9D User's Manual 6.7 Boot Use this menu to configure boot settings: Boot mode select Use this feature to select the boot mode. The options are LEGACY, UEFI, and DUAL. Legacy to EFI Support Select Enabled to boot EFI OS support after Legacy boot order has failed. The options are Disabled and Enabled.
  • Page 93 Chapter 6: UEFI BIOS • Boot Option #11 • Boot Option #12 • Boot Option #13 • Boot Option #14 • Boot Option #15 • Boot Option #16 • Boot Option #17  Delete Boot Option Use this feature to select a boot device to delete from the boot priority list. ...

  • Page 94: Save & Exit

    SuperServer E302-9D User's Manual 6.8 Save & Exit Use this menu to configure save and exit settings. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.
  • Page 95 Chapter 6: UEFI BIOS Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>. This enables the user to save any changes to the BIOS setup for future use. Restore User Defaults To set this feature, select Restore User Defaults from the Exit menu and press <Enter>.

  • Page 96: Appendix A Bios Codes

    SuperServer E302-9D User's Manual Appendix A BIOS Codes A.1 BIOS Error POST (Beep) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 97 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 98: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 99 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 100 SuperServer E302-9D User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 101 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 102 SuperServer E302-9D User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 103 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 104 SuperServer E302-9D User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원...
  • Page 105 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 106 SuperServer E302-9D User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...
  • Page 107 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 108 SuperServer E302-9D User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 109 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 110 SuperServer E302-9D User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 111 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 112 SuperServer E302-9D User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.
  • Page 113 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 114 SuperServer E302-9D User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 115 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 116 ‫حجم املوصل والقابس السليم. استخدام أي كابالت ومحوالت أخرى قد يتسبب يف عطل أو حريق. يحظر قانون السالمة لألجهزة الكهربائية واملعدات استخدام الكابالت املعتمدة‬ ‫ من قبل‬UL ‫ أو‬CSA ‫( والتي تحمل عالمة‬UL/CSA) ‫ مع أي معدات أخرى غري املنتجات املعنية واملحددة من قبل‬Supermicro.
  • Page 117 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 118: Appendix C Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 119 Directory of a USB device or a writeable CD/DVD. Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website at www.supermicro.com to download the BIOS image into a USB flash device and rename it "Super.ROM" for BIOS recovery use.
  • Page 120 SuperServer E302-9D User's Manual 4. After locating the new BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 121 Appendix C: UEFI BIOS Recovery 6. After the BIOS recovery process is completed, press any key to reboot the system. 7. Using a different system, extract the BIOS package into a USB flash drive. 8. Press <Del> continuously to enter the BIOS setup utility. Set the item, Boot Option #1, to [UEFI AP:UEFI: Built-in EFI Shell].
  • Page 122 SuperServer E302-9D User's Manual 9. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory which contains the BIOS package extracted earlier from Step 7. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process.

  • Page 123: Appendix D System Specifications

    Appendix D: System Specifications Appendix D System Specifications Processors Single Intel Xeon D-2123IT 4C 8T 60W Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. BIOS 128Mb SPI Flash with AMI BIOS® Memory Supports up to 256GB of ECC/non-ECC RDIMM or 512GB of ECC LRDIMM DDR4 with speeds of up to 2400MHz in four memory slots SATA Controller...
  • Page 124 SuperServer E302-9D User's Manual Regulatory Compliance Electromagnetic Emissions: FCC Class B, EN 55032 Class B, EN 61000-3-2/3-3, CISPR 32/22 Class B Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11)
