SuperServer SYS-E403-9D-16C-IPD2/E403-9D-14CN-IPD2 User's Manual
Hose Clamp Rings
I-shaped
Mounting Bracket
Figure 2-1. Removing the Screws from under the Mounting Bracket
Hoist rings
(hidden in image)
20
Thread Rod (M12)
Nuts and Washers (M12)
Holding Bar
Bracket Locking Screws (M8)
