2.4 Detaching the Cabinet Door

The enclosure allows the door to be detached to facilitate installation. However, the door was
not designed to be lifted above seven feet on its own. If the system is to be deployed at a
height above seven feet, please install the door to the enclosure first and then use the hoist
rings to raise the entire enclosure to the desired height.
Detaching the Door
1. Disconnect the power cable from the system.
2. Unscrew the door stopper.
3. Open the door and place a proper support behind it.
4. Detach the two fan cables.
5. Detach the grounding cable attaching point and door retainer kit by unscrewing the three
screws.
6. Make sure the door is opened more than 100 degrees, then carefully slide the door
upwards to separate it from the enclosure.
7. To reattach the door, reverse the above steps. When reattaching the cables, pay
attention to their tag labels to avoid mismatching them.
Door stopper
Ground cable attaching
point and door retainer
kit
Figure 2-4. Detaching the Door
23
Chapter 2: System Installation
Fan cables
