• Air cleaner restriction
• Restriction in exhaust system
• Electrical connector disconnection
• Open or short circuit in fuel pump body and related wiring harness
• No battery power supply to PCM or poor GND
• Inadequate fuel pressure
• Fuel pump body mechanical malfunction
• Fuel leakage from fuel injector
• Fuel injector clogging
• Ignition coil malfunction
• Improper air/fuel mixture ratio control
• Improper valve timing
• Improper operation variable valve timing control system
• Immobilizer system and/or circuit malfunction (if equipped)
• Immobilizer system operating properly. (Ignition key is not registered.)
• Pressure regulator malfunction
The following troubleshooting flow chart contains the fuel system diagnosis and repair
procedures. Read the following warnings before performing the fuel system services:
Diagnostic procedure
STEP INSPECTION
Note
1
Downloaded from
Warning
• Fuel vapor is hazardous. It can easily ignite, causing serious injury and
damage. Always keep sparks and flames away from fuel.
• Fuel line spills and leakage are dangerous. Fuel can ignite and cause
serious injuries or death and damage. Fuel can also irritate skin and eyes. To
prevent this, always complete the "BEFORE SERVICE PRECAUTION" and
"AFTER SERVICE PRECAUTION" described in this manual.
(See BEFORE SERVICE
(See AFTER SERVICE PRECAUTION.)
Caution
• If there is foreign material on the connecting area of the quick release
connector, it might damage the connector or fuel pipe. To prevent this,
disconnect the connector and clean the connecting area before connecting.
RESULTS
Yes
https://carmanualshub.com/
PRECAUTION.)
Both conditions appear:
Go to Step 3.
- automotive repair manuals website
ACTION
