STEP
VERIFY FREEZE FRAME DATA HAS
BEEN RECORDED
1
• Has FREEZE FRAME DATA been
recorded?
VERIFY RELATED REPAIR
INFORMATION AVAILABILITY
• Verify related service repair information
2
availability.
• Is any related repair information available?
INSPECT IAC VALVE CONNECTOR FOR
POOR CONNECTION
• Turn the ignition switch off.
• Disconnect the IAC valve connector.
3
• Inspect for poor connection (such as
damaged/pulled-out pins, corrosion).
• Is there any malfunction?
INSPECT IAC VALVE CIRCUIT FOR
SHORT TO GND
• Turn the ignition switch off.
• Inspect for continuity between the following
circuits:
4
- IAC valve terminal A (wiring
harness-side) and body GND
- IAC valve terminal B (wiring
harness-side) and body GND
• Is there continuity?
INSPECT IAC VALVE CIRCUIT FOR
SHORT TO POWER SUPPLY
• Turn the ignition switch to the ON position
(Engine off).
• Measure the voltage between the following
circuits:
5
- IAC valve terminal A (wiring
harness-side) and body GND
- IAC valve terminal B (wiring
harness-side) and body GND
• Is the voltage B+?
6 INSPECT IAC VALVE
Downloaded from
INSPECTION
https://carmanualshub.com/
ACTION
Yes Go to the next step.
Record the FREEZE FRAME DATA on the
No
repair order, then go to the next step.
Perform repair or diagnosis according to the
available repair information.
Yes
• If the vehicle is not repaired, go to the next
step.
No Go to the next step.
Repair or replace the terminal, then go to Step
Yes
9.
No Go to the next step.
Repair or replace the wiring harness for a
Yes
possible short to GND, then go to Step 9.
No Go to the next step.
Repair or replace the wiring harness for a
Yes possible short to power supply, then go to
Step 9.
No Go to the next step.
Yes Replace the IAC valve, then go to Step 9.
