Diagnostic procedure
STEP
VERIFY FREEZE FRAME DATA HAS BEEN
RECORDED
1
• Has FREEZE FRAME DATA been
recorded?
VERIFY RELATED REPAIR INFORMATION
AVAILABILITY
• Verify related service repair information
2
availability.
• Is any related repair information available?
INSPECT POOR CONNECTION OF IAC
VALVE CONNECTOR
• Turn the ignition switch off.
• Disconnect IAC valve connector.
3
• Inspect for poor connection (such as
damaged/pulled-out pins, corrosion).
• Is there any malfunction?
INSPECT IAC VALVE ELECTRICAL
MALFUNCTION
4
• Inspect the IAC valve.
Downloaded from
INSPECTION
https://carmanualshub.com/
ACTION
Yes Go to the next step.
Record the FREEZE FRAME DATA on the
No
repair order, then go to the next step.
Perform repair or diagnosis according to the
available repair information.
Yes
• If the vehicle is not repaired, go to the next
step.
No Go to the next step.
Repair or replace the terminal, then go to
Yes
Step 9.
No Go to the next step.
Yes Go to the next step.
No Replace IAC valve, then go to Step 9.
