Page 1 Mazda. Should you resell the vehicle, leave this manual with it for the next owner. All speciﬁcations and descriptions are accurate at the time of printing. Because improvement is a con- stant goal at Mazda, we reserve the right to make changes in speciﬁcations at any time without notice and without obligation.
Page 2 “Do not do this” or “Do not let the manual to best explain how to this happen”. enjoy your Mazda. By reading your manual, you can ﬁnd out about the features, important safety information, and driving under various road conditions.
Page 3: Table Of Contents
Table of Contents Pictorial Index Interior, exterior views and part identiﬁcation of your Mazda. Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Before Driving Use of various features, including keys, doors, mirrors and windows.
Page 5: Pictorial Index
Pictorial Index Interior, exterior views and part identiﬁcation of your Mazda. Interior Overview (Left-Hand Drive Interior Overview (Right-Hand Drive Model)........1-2 Model)........1-8 Interior Equipment (View Interior Equipment (View A)......... 1-2 A)......... 1-8 Interior Equipment (View Interior Equipment (View B)......... 1-3 B).........
Page 6 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View A) ▼ Interior Equipment (View A) ① High beam control switch/Adaptive LED headlight switch..page 4-107, 4-110 ② Lighting control................. page 4-59 ③ Turn and lane-change signals............. page 4-65 ④ Audio remote control switches............page 5-22 ⑤...
Page 7 Interior Equipment (View B) ▼ Interior Equipment (View B) ① Instrument cluster................page 4-23 ② Active driving display................. page 4-42 ③ Mazda Connect................page 5-14 ④ Air-conditioning system............... page 5-2 ⑤ Heated steering wheel switch.............page 2-21 ⑥ Seat warmer switches................ page 2-20 ⑦...
Page 8 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View C) ▼ Interior Equipment (View C) ① Head restraint................... page 2-17 ② Front seat................... page 2-5 ③ Seat belt................... page 2-23 ④ Bottle holder..................page 5-39 ⑤ Vanity mirror..................page 5-33 ⑥ Sunvisor................... page 5-33 ⑦...
Page 9 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View D) ▼ Interior Equipment (View D) ① Push knob..................page 2-14 ② Head restraint................... page 2-17 ③ Child safety lock................page 3-21 ④ Rear coat hook..................page 5-40 ⑤ Overhead light (rear)................. page 5-34 ⑥...
Page 10 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View E) ▼ Saloon ① Remote handles................page 2-14 ② Boot light..................page 5-34 The equipment and installation position varies by vehicle...
Page 11 Pictorial Index Interior Overview (Left-Hand Drive Model) ▼ Hatchback ① Luggage compartment cover.............. page 3-25 ② Anchor brackets................page 2-44 ③ Luggage compartment light..............page 5-34 The equipment and installation position varies by vehicle...
Page 12 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View A) ▼ Interior Equipment (View A) ① High beam control switch/Adaptive LED headlight switch..page 4-107, 4-110 ② Lighting control................. page 4-59 ③ Turn and lane-change signals............. page 4-65 ④ Audio remote control switches............page 5-22 ⑤...
Page 13 ③ Hazard warning ﬂasher switch............page 4-73 ④ Rear window defogger switch............page 4-71 ⑤ Heated steering wheel switch.............page 2-21 ⑥ Mazda Connect................page 5-14 ⑦ Active driving display................. page 4-42 ⑧ Instrument cluster................page 4-23 ⑨ Storage pocket.................. page 5-41 ⑩...
Page 14 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View C) ▼ Interior Equipment (View C) ① Vent....................page 5-3 ② Rearview mirror................page 3-39 ③ Overhead light (front)/Map lights............page 5-34 ④ Overhead console................page 5-41 ⑤ Sunroof switch.................. page 3-44 ⑥...
Page 15 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View D) ▼ Interior Equipment (View D) ① Assist grip..................page 5-39 ② Power window switch................page 3-42 ③ Door-lock knob................page 3-20 ④ Overhead light (rear)................. page 5-34 ⑤ Rear coat hook..................page 5-40 ⑥...
Page 16 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View E) ▼ Saloon ① Remote handles................page 2-14 ② Boot light..................page 5-34 1-12 The equipment and installation position varies by vehicle...
Page 17 Pictorial Index Interior Overview (Right-Hand Drive Model) ▼ Hatchback ① Luggage compartment cover.............. page 3-25 ② Anchor brackets................page 2-44 ③ Luggage compartment light..............page 5-34 1-13 The equipment and installation position varies by vehicle...
Page 18 Pictorial Index Exterior Overview Saloon ▼ Saloon ① Windscreen wiper blades..............page 6-33 ② Sunroof.................... page 3-44 ③ Door....................page 3-12 ④ Window................... page 3-41 ⑤ Touch sensor..................page 3-15 ⑥ Fuel-ﬁller ﬂap..................page 3-34 ⑦ Outside mirror.................. page 3-36 ⑧ Boot lid.................... page 3-22 ⑨...
Page 19 Pictorial Index Exterior Overview Hatchback ▼ Hatchback ① Windscreen wiper blades..............page 6-33 ② Door....................page 3-12 ③ Window................... page 3-41 ④ Touch sensor..................page 3-15 ⑤ Fuel-ﬁller ﬂap..................page 3-34 ⑥ Outside mirror.................. page 3-36 ⑦ Liftgate..................... page 3-22 ⑧ Electric liftgate opener............... page 3-23 ⑨...
Page 20 MEMO 1-16...
Page 21: Essential Safety Equipment
Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats........2-2 SRS Air Bags......2-48 Seat Precautions....2-2 Supplementary Restraint System Front Seat......2-5 (SRS) Precautions....2-48 Rear Seat......2-14 Front Passenger Air Bag Head Restraints....
Page 22 After adjusting the injuries. Always have an expert repairer seatback at any time, even when there (we recommend an Authorised Mazda are no other passengers, rock the Repairer) inspect the front seats, front seatback to make sure it is locked in seat belt pretensioners and air bags place.
Page 23 Essential Safety Equipment Seats Do not drive with either front seats Never allow a passenger to sit or reclined: stand on the folded seatback while Sitting in a reclined position while the the vehicle is moving: vehicle is moving is dangerous because Driving with a passenger on the folded you do not get the full protection from seatback is dangerous.
Page 24 Essential Safety Equipment Seats NOTE CAUTION When returning a rear seat to its  When operating a seat, be careful original position, place the seat belt not to put your hands or ﬁngers near in its normal position. Verify that the the moving parts of the seat or on seat belt pulls out and retracts.
Page 25 Also, you can be assured of a clear view in the forward direction to help you drive more safely and comfortably. The adjustments for the driving position recommended by Mazda are done using the following procedures. 1. Moving the steering wheel and seat to their default positions.
Page 26 Press the rear part of the switch to decrease ﬁrmness. Before making adjustments to the driving position recommended by Mazda Before making adjustments, move the steering wheel and seat to their default positions. How to move the steering wheel to its...
Page 27 After adjusting the steering wheel Seat adjustment procedure for the position, make sure it is securely driving position recommended by locked by trying to move it up and Mazda down: Adjusting the seatback angle Driving with the steering wheel not (reclining) securely locked in position is dangerous.
Page 28 Essential Safety Equipment Seats 2. Move the seatback backward to a 2. With your heel set on the ﬂoor, set comfortable seated posture without your right foot on the brake pedal any feeling of cramping in your and move the seat forward as far as waist.
Page 29 Essential Safety Equipment Seats 5. Depress the accelerator pedal Adjusting the seat height completely with your heel set on Adjust the seat height to a position the ﬂoor and make sure that your where you have a clear forward view ankle does not feel over-stretched.
Page 30 Essential Safety Equipment Seats Adjusting the height on the front edge Adjusting the steering wheel position of the seat bottom Adjust the steering wheel to the Adjust the height on the front edge of position where it can be operated the seat bottom to the position where easily and the gauges can be viewed the back of your knees contacts the...
Page 31 Essential Safety Equipment Seats ▼ Driving Position Memory (Power Programming Seat) 1. Make sure the parking brake is on. 2. (Automatic transmission) The desired driving position can be Make sure the selector lever is in called up after programming the the P position.
Page 32 Essential Safety Equipment Seats If the angle of the outer mirrors only The angle of the outer mirrors is   changes a little, the angle of the adjusted. outer mirrors may not have been The SET button is pressed. ...
Page 33 Essential Safety Equipment Seats ▼ Adjusting the Front Passenger's Outside mirrors  Seat A sound is activated when the adjustment is completed. NOTE When adjustment of the driving  position is not necessary, a sound is not activated. The driving position adjustment is ...
Page 34 Essential Safety Equipment Seats 3. Seat Recline Rear Seat To change the seatback angle, lean forward slightly while raising the ▼ Split Folding lever. Then lean back to the desired position and release the lever. By lowering the rear seatbacks the Make sure the lever returns to its luggage compartment space can be original position and the seatback is...
Page 35 Essential Safety Equipment Seats When transporting cargo, do not (Saloon) allow the cargo to exceed the height 1. Open the boot lid and pull the of the seatbacks. lever of the seatback you want to Transporting cargo stacked higher than fold down.
Page 36 Essential Safety Equipment Seats To return the seatback to its upright 1. Make sure that the seat belt passes position: through the seat belt guide correctly and it is not twisted, then raise the seatback while preventing WARNING the seat belt from being caught in the seatback.
Page 37 Essential Safety Equipment Seats 2. Seat belt guide Head Restraints 2. Press the seatback rearward and ▼ Head Restraints lock it in place. After returning the Your vehicle is equipped with head seatback to its upright position, restraints on all outboard seats and the make sure it is securely locked.
Page 38 Essential Safety Equipment Seats ▼ Removal/Installation Front seats To remove the head restraint, pull it up while pressing the stop-catch. To install the head restraint, insert the legs into the holes while pressing the stop-catch. WARNING Always drive with the head restraints installed when seats are being used and make sure they are properly Rear outboard seats...
Page 39 Essential Safety Equipment Seats CAUTION When installing a head restraint, make sure that it is installed correctly with the front of the head restraint facing forward. If the head restraint is installed incorrectly, it could detach from the seat during a collision and result in injury.
Page 40 ▼ Seat Warmer procedure. The front seats can be warmed up a) Select “Settings” from the Mazda while the engine is running. Connect home screen. While the seat warmer is operating, b) Select “Vehicle Settings”.
Page 41 Essential Safety Equipment Seat Warmer/Heated Steering Wheel People who are intoxicated Heated Steering Wheel People who have taken sleep-inducing medicine such as ▼ Heated Steering Wheel sleeping pills or cold medicine The grips on the left and right of the steering wheel can be warmed up Do not use the seat warmer with when the ignition is switched ON.
Page 42 Temperatures” has been disabled, Infants, small children, elderly enable it using the following procedure. people, and physically challenged a) Select “Settings” from the Mazda people People with delicate skin Connect home screen. b) Select “Vehicle Settings”. People who are excessively fatigued c) Enable “Link Seat &...
Page 43 Mazda passengers could be crushed together recommends that the driver and all and seriously injured or even killed.
Page 44 Essential Safety Equipment Seat Belt Systems Positioning the Shoulder Portion of It is essential to replace the entire the Seat Belt: assembly after it has been worn in a Improper positioning of the shoulder severe impact even if damage to the portion of the seat belt is dangerous.
Page 45 Essential Safety Equipment Seat Belt Systems ▼ Pregnant Women and Persons with Seat Belt Serious Medical Conditions ▼ Fastening the Seat Belt Pregnant women should always wear seat belts. Ask your doctor for speciﬁc Insert the seat belt tongue into the recommendations.
Page 46 If it is still not retracting properly, have it inspected at an expert repairer (we recommend an Authorised Mazda Repairer). After adjusting, press the front shoulder belt adjuster downward and make sure that it is securely locked.
Page 47 Essential Safety Equipment Seat Belt Systems Seat Belt Warning Seat Belt Pretensioner Systems and Load Limiting Systems ▼ Seat Belt Warning Systems ▼ Seat Belt Pretensioner and Load If it detects that the occupant seat belt Limiting Systems is unfastened, the warning light or beep alerts the occupant.
Page 48 Load limiter: Always have an expert repairer (we The load limiting system releases belt recommend an Authorised Mazda webbing in a controlled manner to Repairer) immediately inspect the seat reduce belt force on the occupant's belt pretensioners and air bags after chest.
Page 49 Essential Safety Equipment Seat Belt Systems NOTE The pretensioner system may not  operate depending on the type of the collision. For details, refer to the SRS Air Bag Deployment Criteria (page 2-61). Some smoke (non-toxic gas) will be  released when the air bags and pretensioners deploy.
Page 50 The front passenger's seat is ▼ Child-Restraint Precautions also the least preferred seat for other child-restraint systems. Mazda strongly urges the use of child-restraint systems for children For some models, we have provided a small enough to use them.
Page 51 Essential Safety Equipment Child Restraint Always secure a child in a proper Even in a moderate collision, the child-restraint system: child-restraint system can be hit by a Holding a child in your arms while the deploying air bag and moved violently vehicle is moving is extremely backward resulting in serious injury or dangerous.
Page 52 Essential Safety Equipment Child Restraint Do not install a front-facing Do not allow a child or anyone to child-restraint system on the front lean over or against the side window passenger seat unless it is of a vehicle with side and curtain air unavoidable: bags: In a collision, the force of a deploying...
Page 53 Never use one belt for more than one NOTE person at a time and always operate Your Mazda is equipped with ISOFIX the vehicle with each occupant anchors for attachment of ISOFIX properly restrained.
Page 54 Essential Safety Equipment Child Restraint Child-Restraint System Installation ▼ Categories of Child-Restraint Systems NOTE When purchasing, ask the manufacturer of the child-restraint system which type of child-restraint system is appropriate for your child and vehicle. (Europe and countries conforming to the UN-R 44 and UN-R 129 regulation) Child-restraint systems are classiﬁed into the following 5 groups according to the UN-R 44 regulation.
Page 55 Essential Safety Equipment Child Restraint Due to variations in the design of (Europe)  child-restraint systems, vehicle seats Recommended child-restraint system: and seat belts, all child-restraint Britax Römer Duo Plus systems may not ﬁt all seating positions. Before purchasing a child-restraint system, it should be tested in the speciﬁc vehicle seating position (or positions) where it is...
Page 56 Essential Safety Equipment Child Restraint ▼ Baby Seat Installation Position The child-restraint system can be hit by the deploying air bag and knocked out A baby seat is used in the rear-facing of position. A child in the position only. child-restraint system could be seriously injured or killed.
Page 57 Essential Safety Equipment Child Restraint Rear-facing type Front-facing type WARNING WARNING Always install a rear-facing child seat Never install a front-facing child seat in the correct seat position: in the wrong seat position: Installing a rear-facing child seat Installing a front-facing child seat without ﬁrst consulting the table without ﬁrst consulting the table “Child-Restraint System Suitability for...
Page 58 Essential Safety Equipment Child Restraint Make sure that the front passenger air WARNING bag deactivation switch is in the OFF position. Refer to Front Passenger Air Always install a junior seat in the Bag Deactivation Switch (page 2-54). correct seat position: Installing a junior seat without ﬁrst consulting the table “Child-Restraint System Suitability for Various Seat...
Page 59 Essential Safety Equipment Child Restraint Child-Restraint System Suitability for Various Seat Positions Table ▼ Child-Restraint System Suitability for Various Seat Positions Table (Europe and countries conforming to the UN-R 16 regulation) Provided information in the table shows your child-restraint system suitability for various seating position.
Page 60 Essential Safety Equipment Child Restraint Except Taiwan Passenger Seating posi- Rear (Left) Rear (Centre) Rear (Right) Airbag activat- Airbag de-acti- tion vated Seating position suitable for uni- Yes (UF) Yes (U) Yes (U) Yes (U) Yes (U) versal belted (Yes/No) i-Size seating position Yes (i-U)
Page 61 No = Child-restraint system cannot be secured on the seat, or there is no ﬁxture. X = Child-restraint system cannot be installed. Child restraint system can only be installed in the forward-facing position. A Mazda genuine child-restraint system can be installed. Regarding child-restraint systems which can be installed, refer to the accessories catalog. Taiwan...
Page 62 IL = suitable for particular ISOFIX child-restraint systems (CRS). These ISOFIX CRS are those of the “speciﬁc vehicle”, “restricted” or “semi-universal” categories. A Mazda genuine child-restraint system can be installed. Regarding child-restraint systems which can be installed, refer to the accessories catalog.
Page 63 UF = Suitable for forward-facing “universal” category restraints approved for use in this mass group. X = Seat position not suitable for children in this mass group. (Other countries) Regarding child-restraint systems which can be installed to your Mazda, consult an  expert repairer (we recommend an Authorised Mazda Repairer).
Page 64 Essential Safety Equipment Child Restraint Always remove the head restraint and Installing Child-Restraint install child-restraint system: Systems Installing a child-restraint system without removing the head restraint is dangerous. The child-restraint system ▼ Anchor Bracket cannot be installed correctly which Anchor brackets for securing may result in death or injury to the child-restraint systems are equipped in child in a collision.
Page 65 Essential Safety Equipment Child Restraint ▼ Using ISOFIX Anchor Make sure there are no seat belts or foreign objects near or around the ISOFIX anchor-secured child-restraint WARNING system: Not following the child-restraint system Follow the manufacturer's manufacturer's instructions when instructions for the use of the installing the child-restraint system is child-restraint system: dangerous.
Page 66 Essential Safety Equipment Child Restraint 1. First, adjust the front seat to allow NOTE clearance between the The ISOFIX anchors marking on  child-restraint system and the front the cover indicates the position of seat. the ISOFIX anchors for the Refer to Adjusting the Driver's Seat attachment of a child-restraint on page 2-5.
Page 67 Essential Safety Equipment Child Restraint Always remove the head restraint and set the tether strap (except when installing a booster seat): Routing the tether strap on top of the head restraint is dangerous. In a collision the tether strap could slide off the head restraint and loosen the child-restraint system.
Page 68 Essential Safety Equipment SRS Air Bags The air bag supplementary restraint Supplementary Restraint systems are designed to provide System (SRS) Precautions supplementary protection in certain situations so seat belts are always ▼ Supplementary Restraint System important in the following ways: (SRS) Precautions Without seat belt usage, the air bags The front and side supplementary...
Page 69 Essential Safety Equipment SRS Air Bags Even in a moderate collision, the WARNING child-restraint system can be hit by a deploying air bag and moved violently Seat belts must be worn in air bag backward resulting in serious injury or equipped vehicles: death to the child.
Page 70 Essential Safety Equipment SRS Air Bags Sit in the centre of the seat and wear Do not hang net bags, map pouches or seat belts properly: backpacks with side straps on the front Sitting too close to the side air bag seats.
Page 71 Always have under the front seats: an expert repairer (we recommend an Placing luggage or other objects under Authorised Mazda Repairer) inspect a the front seats is dangerous. The damaged front door: components essential to the Modifying a front door or leaving any supplementary restraint system could damage unrepaired is dangerous.
Page 72 (we recommend an through friction. Authorised Mazda Repairer) can fully Should you sell your Mazda, we urge  evaluate these systems to see that they you to tell the new owner of its air will work in any subsequent accident.
Page 73 Essential Safety Equipment SRS Air Bags (Taiwan, except front passenger seat, if equipped with the following label) The highly-visible labels warn against the use of a rear-facing child-restraint system on the seat protected by an air bag. 2-53...
Page 74 Essential Safety Equipment SRS Air Bags Front Passenger Air Bag Deactivation Switch ▼ Front Passenger Air Bag Deactivation Switch WARNING Do not deactivate the front passenger air bag unnecessarily: Unnecessary deactivation of the front passenger air bag is dangerous. If turned off unnecessarily, the front passenger will not receive the added protection of the air bag.
Page 75 NOTE Have the front passenger air bag deactivation switch inspected by an expert repairer (we recommend an Authorised Mazda Repairer) if any of these conditions occur: The front passenger air bag deactivation indicator light does not illuminate for a ...
Page 76 Essential Safety Equipment SRS Air Bags ▼ Switch Positions Switching to OFF position 1. Insert the key into the front Before driving, always conﬁrm that the passenger air bag deactivation front passenger air bag deactivation switch and turn the key clockwise switch is in the appropriate position until the key points to OFF.
Page 77 Essential Safety Equipment SRS Air Bags Supplementary Restraint System Components ▼ Supplementary Restraint System Components 1. Seat belt pretensioners (page 2-27) 2. Side and curtain inﬂators and air bags 3. Side crash sensors 4. Driver/Front passenger inﬂators and air bags 5.
Page 78 ▼ How the SRS Air Bags Work mainly to the driver's head or chest caused by directly hitting the steering Your Mazda is equipped with the wheel. following types of SRS air bags. SRS air For more details about air bag bags are designed to work together deployment, refer to "SRS Air Bag...
Page 79 Essential Safety Equipment SRS Air Bags ▼ Front Passenger Air Bag ▼ Side Air Bags The front passenger air bag is mounted The side air bags are mounted in the in the front passenger instrument outboard sides of the front seatbacks. panel.
Page 80 Essential Safety Equipment SRS Air Bags In a side impact: Greater than moderate impact to one side of the vehicle will cause the curtain air bag on that side only to inﬂate. Only one side curtain air bag will deploy on the side of the vehicle that receives the force of an impact.
Page 81 Essential Safety Equipment SRS Air Bags SRS Air Bag Deployment Criteria ▼ SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) Types of collision SRS equip- A roll-over/near...
Page 82 Essential Safety Equipment SRS Air Bags Types of collision SRS equip- A roll-over/near A severe frontal/near frontal A severe side col- ment A rear collision collision lision roll-over Front seat belt preten- sioner Rear seat belt preten- sioner Driver air No air bag and ―...
Page 83 Essential Safety Equipment SRS Air Bags Frontal offset impact to the vehicle Limitations to SRS Air Bag ▼ Limitations to SRS Air Bag In severe collisions such as those described previously in "SRS Air Bag Deployment Criteria", the applicable SRS air bag equipment will deploy. However, in some accidents, the equipment may not deploy depending Rear-ending or running under a...
Page 84 Essential Safety Equipment SRS Air Bags Side impacts involving trees or poles Limitations to roll-over detection (With roll-over sensor): The following illustration is an example of an accident that may not be detected as a roll-over accident. Therefore, the front seat belt pretensioners and curtain air bags may not deploy.
Page 85 Essential Safety Equipment SRS Air Bags Constant Monitoring ▼ Constant Monitoring The following components of the air bag systems are monitored by a diagnostic system: Front air bag sensors  Crash sensors, and diagnostic  module (SAS unit) Side crash sensors ...
Page 86 MEMO 2-66...
Page 87 Before Driving Use of various features, including keys, doors, mirrors and windows. Keys........3-2 Security System.......3-47 Keys........3-2 Modiﬁcation and Add- Keyless Entry System....3-4 On Equipment.....3-47 Immobilizer System....3-47 Theft-Deterrent System ..3-49 Advanced Keyless Entry System........3-10 Advanced Keyless Entry Driving Tips......3-53 System .......
Page 88: Before Driving
The key (transmitter) contacts or is covered by a metal object. The key (transmitter) is near electronic devices such as personal computers. Non-Mazda genuine electronic equipment is installed in the vehicle. There is equipment which discharges radio waves near the vehicle.
Page 89 2. Remove the auxiliary key. If your key (auxiliary key) is lost, consult an expert repairer (we recommend an Authorised Mazda Repairer) and have your code number ready. 1. Key code number plate...
Page 90 If your key is lost or stolen, consult an Keyless Entry System expert repairer (we recommend an Authorised Mazda Repairer) as soon as ▼ Keyless Entry System possible for a replacement and to make the lost or stolen key inoperative.
Page 91 ▼ Transmitter The volume of the beep sound can also be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. The operation indicator light ﬂashes when the buttons are pressed. Lock button To lock the doors, liftgate/boot lid and fuel-ﬁller ﬂap, press the lock...
Page 92 Before Driving Keys Unlock button Refer to the Settings section in the Mazda Connect Owner's Manual. Type A (Auto re-lock function)  After unlocking with the key, all the To unlock the driver's door and the fuel-ﬁller ﬂap, press the unlock button...
Page 93 Before Driving Keys Boot button (Saloon) Power saving function To open the boot lid, press and hold By turning on the transmitter power the boot button until the boot lid saving function, the advanced keyless opens. entry and push button start system Type A functions turn off and the battery power consumption of the transmitter...
Page 94 Before Driving Keys 2. Press the lock button on the With the advanced keyless function transmitter 4 times within 3 seconds to turn on the operation indicator light. 3. Press the lock button continuously for 1.5 seconds or longer while the operation indicator light turns on (for 5 seconds).
Page 95 Before Driving Keys ▼ Key Suspend Function If a key is left in the vehicle, the functions of the key left in the vehicle are temporarily suspended to prevent theft of the vehicle. To restore the functions, press the unlock button on the functions-suspended key in the vehicle.
Page 96 Consult device manufacturer or your physician an expert repairer (we recommend an if radio waves from the key will affect Authorised Mazda Repairer) for the device. details. If the advanced keyless entry system has been deactivated, you can...
Page 97 Before Driving Advanced Keyless Entry System NOTE Operational Range The system may not operate if you  ▼ Operational Range are too close to the windows or door handles, or liftgate. The system operates only when the If the key is left in the following areas ...
Page 98 Before Driving Doors and Locks After closing the doors and the Door Locks liftgate/boot lid, always verify that they are securely closed: ▼ Door Locks Doors and the liftgate/boot lid not securely closed are dangerous, if the WARNING vehicle is driven with a door and the liftgate/boot lid not securely closed, Always take all children and pets with the door and the liftgate/boot lid...
Page 99 Before Driving Doors and Locks (With the advanced keyless NOTE function) Always stop the engine and lock the  The beep sound is heard for about doors. In addition, to prevent theft of 10 seconds to notify the driver that valuables, do not leave them inside the key has been left in the vehicle.
Page 100 (we recommend an 4. The indicator light illuminates for Authorised Mazda Repairer). about 3 seconds to indicate that the system has been activated. 3-14 *Some models.
Page 101 Before Driving Doors and Locks Locking NOTE The system cannot be activated when any door or the liftgate is open. How to Deactivate the System Unlock the driver's door or start the engine. NOTE Unlocking If the power supply is interrupted (fuse blows or the battery is disconnected), the system can only be deactivated by unlocking a door with the auxiliary key.
Page 102 The ignition is switched OFF.  Refer to the Settings section in the All the doors are closed.  Mazda Connect Owner's Manual. You are carrying the transmitter.  The following locations are locked by When unlocking, the hazard warning touching the sensing area of the door lights operate two times.
Page 103 The volume of the beep sound can After unlocking with the touch also be changed. Refer to the sensor, all the doors , fuel-ﬁller ﬂap, Settings section in the Mazda and liftgate/boot lid will Connect Owner's Manual. automatically lock if any of the...
Page 104 The time required for the doors to lock automatically can be changed. The following locations are locked/ Refer to the Settings section in the unlocked by pressing the door-lock Mazda Connect Owner's Manual. switch. All doors For vehicles with the boot lid release button, ...
Page 105 Before Driving Doors and Locks After locking by pressing the When the liftgate closes, the hazard  door-lock switch and when the warning lights operate 1 time. liftgate/boot lid is closed last with the transmitter left in the vehicle, (Without theft-deterrent system only the liftgate/boot lid is unlocked.
Page 106 2. Lock 3. Unlock The auto lock/unlock function settings can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. For vehicles with the boot lid release button, the boot lid cannot be locked/unlocked using this method. 3-20...
Page 107 Before Driving Doors and Locks ▼ Rear Door Child Safety Locks Operation from outside To lock any door using its door-lock Rear doors that have been locked knob from the outside, press the using the child safety lock switched to door-lock knob to the lock position the lock side cannot be opened from and close the door (holding the door...
Page 108 It damper stay. Consult an expert may affect the side or rear ﬁeld of view. repairer (we recommend an Authorised Mazda Repairer) if a CAUTION liftgate damper stay is deformed or damaged for reasons such as a Before opening the liftgate/boot lid,...
Page 109 Before Driving Doors and Locks ▼ Opening and Closing the Liftgate/ When the liftgate latch is released by  pressing the electric liftgate opener, Boot Lid the liftgate raises slightly. If the Opening the liftgate (Hatchback) liftgate is not operated for a certain period of time, the liftgate cannot be Using the electric liftgate opener raised.
Page 110 Before Driving Doors and Locks Refer to When Liftgate/Boot Lid Using the electric boot lid opener Cannot be Opened on page 7-80. Unlock the doors and boot lid, then Closing the liftgate/boot lid press the electric boot lid opener on the boot lid and raise the boot lid Lower the liftgate/boot lid slowly using when the latch releases.
Page 111 Before Driving Doors and Locks NOTE CAUTION Conﬁrm that the liftgate/boot lid is Make sure the luggage compartment securely closed. Move the liftgate/boot lid without cover is ﬁrmly secured. If it is not pressing the electric liftgate/boot lid ﬁrmly secured, it could unexpectedly opener to verify that the liftgate/boot disengage resulting in injury.
Page 112 Before Driving Doors and Locks 2. Press the luggage compartment cover upward from near the pins and remove the luggage compartment cover from the pins. 1. Pin 3. Lift the front end of the luggage compartment cover and remove it. 3-26...
Page 113 Before Driving Fuel and Emission Fuel and Engine Exhaust Precautions ▼ Fuel Requirements (SKYACTIV-G 1.5, SKYACTIV-G 2.0, SKYACTIV-G 2.5, SKYACTIV-X 2.0) Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL, which will reduce exhaust emissions and keep spark plug fouling to a minimum.
Page 114 The use of E10 fuel with 10 % ethanol in Europe is safe for your vehicle. Damage to your vehicle may occur when ethanol exceeds this recommendation. Never add fuel system additives other than a Mazda genuine product, otherwise the emission control system could be damaged. Consult an expert repairer (we recommend an Authorised Mazda Repairer) for details.
Page 115 Before Driving Fuel and Emission NOTE (Premium unleaded fuel (within E85)) To maintain good engine startability and performance, the following points must be observed. Refuelling using the same-type fuel is recommended.  Add 16 L (4.2 US gal, 3.5 Imp gal) or more of fuel when refuelling. ...
Page 116 Mazda genuine deposit cleaner in the How to use the cleaner speciﬁed countries. Refer to SCHEDULED MAINTENANCE for the With the fuel tank full, infuse 1 bottle details.
Page 117 When refuelling, always add at least 10 USE ONLY UNLEADED FUEL. L (2.6 US gal, 2.2 Imp gal) of fuel. Do not drive your Mazda with any ▼ Emission Control System sign of engine malfunction. Do not coast with the ignition (SKYACTIV-G 1.5, SKYACTIV-G...
Page 118 Do not drive your Mazda with any Exhaust gas is dangerous. When the sign of engine malfunction. vehicle is stopped with the windows Do not coast with the ignition...
Page 119 Before Driving Fuel and Emission Clear snow from underneath and Fuel-Filler Flap and Cap around your vehicle, particularly the tail pipe, before starting the engine: ▼ Fuel-Filler Flap and Cap Running the engine when a vehicle is stopped in deep snow is dangerous. WARNING The exhaust pipe could be blocked by the snow, allowing exhaust gas to...
Page 120 Before Driving Fuel and Emission Auto lock/unlock function  CAUTION (page 3-20) Always use only a designated Mazda Auto re-lock function (page  3-5) and (page 3-15) fuel-ﬁller cap or an approved 2. Press the location shown in the equivalent, available at an expert illustration and open the fuel ﬂap.
Page 121 Before Driving Fuel and Emission Hatchback NOTE Lock the doors after closing the fuel-ﬁller ﬂap. If the fuel-ﬁller ﬂap is closed after locking the doors, the fuel-ﬁller ﬂap cannot be locked. 1. Fuel-ﬁller ﬂap 2. Fuel-ﬁller cap 5. Insert the refuelling nozzle all the way and begin refuelling.
Page 122 Before Driving Mirrors NOTE Mirrors (Driver's Side Wide Angle Mirror ▼ Mirrors The wide angle mirror has 2  curvatures on its surface separated by Before driving, adjust the inside and a region line into outer and inner outside mirrors. regions.
Page 123 Before Driving Mirrors 2. Press the adjustment switch to 2. Press the select switch for the adjust the angle of the outside outside mirror to be tilted mirror. downward to turn on the indicator light of the select switch. 3. Shift the shift lever/selector lever to the R position to tilt the outer mirror on the side where the select button was pressed downward.
Page 124  be turned on or off. Refer to the Settings section in the Only operate the power folding Mazda Connect Owner's Manual. outside mirror with the vehicle safely In the following cases, the outside parked:  mirrors do not fold out Operating the power folding outside automatically.
Page 125 Before Driving Mirrors Engine-off outside mirror operation Rearview mirror adjustment The outside mirrors can be operated Before driving, adjust the rearview for about 40 seconds after the ignition mirror to centre on the scene through is switched from ON to off. the rear window.
Page 126 Before Driving Mirrors Auto-dimming mirror The auto-dimming mirror automatically reduces the glare of headlights from vehicles at the rear when the ignition is switched ON. NOTE Do not use glass cleaner or suspend  objects on or around the light sensor.
Page 127 Before Driving Windows Make sure nothing blocks the window Power Windows just before it reaches the fully closed position or while fully holding up the ▼ Power Windows power window switch: The windows can be opened/closed Blocking the power window just before by operating the power window it reaches the fully closed position or switches.
Page 128 Before Driving Windows ▼ Opening/Closing Windows 9. Unlocked position The window opens while the switch is Front passenger's window switch/ pressed and it closes while the switch Rear window switches is pulled up with the ignition switched ON. Do not open or close 3 or more windows at the same time.
Page 129 Before Driving Windows ▼ Auto-opening/Closing ▼ Jam-safe Window To fully open the window When the window is closing and a automatically, press the switch foreign object is detected between the completely down, then release. The window and the window frame, the window will fully open automatically.
Page 130 Make sure the opening is clear before does not get inside the cabin area. closing the sunroof: After washing your Mazda or after it A closing sunroof is dangerous. The  rains, wipe the water off the sunroof...
Page 131 Before Driving Windows 1. Tilt/Slide switch Slide Operation Tilt Operation To fully open automatically, momentarily press the tilt/slide switch The rear of the sunroof can be tilted in the backward direction. open to provide more ventilation. To fully close automatically, momentarily press the tilt/slide switch To fully tilt automatically, momentarily in the forward direction.
Page 132 Before Driving Windows ▼ Jam-safe Sunroof If a person's hands, head or an object blocks the sunroof while it is closing, the sunroof will stop and move in the open direction. NOTE The jam-safe function may operate  under the following conditions: A strong impact is detected while ...
Page 133 The immobilizer system allows the Equipment engine to start only with a key the system recognises. Mazda cannot guarantee the immobilizer and the theft-deterrent If someone attempts to start the systems' operation if the system has engine with an unrecognised key, the been modiﬁed or if any add-on...
Page 134 Authorised Mazda Repairer. Always keep a spare key in case one  is lost. If a key is lost, consult an Authorised Mazda Repairer as soon as possible. If you lose a key, an Authorised  Mazda Repairer will reset the...
Page 135 ▼ Theft-Deterrent System Do not install seats that are not If the theft-deterrent system detects an Mazda genuine products. inappropriate entry into the vehicle or To prevent obstruction of intrusion the intrusion sensor detects movement sensor, do not place objects or cargo...
Page 136 Before Driving Security System ▼ How to Arm the System The system will be triggered again (up to 10 times) if one of the above 1. Close the windows and the conditions remains. sunroof securely. NOTE Disconnecting the battery terminal ...
Page 137 Before Driving Security System ▼ Cancelling the Intrusion Sensor NOTE (With the Intrusion Sensor) The theft-deterrent system can  also be armed by activating the If the theft deterrent system has been auto relock function with all the armed while any of the following doors, the liftgate/boot lid and conditions are present, cancel the the bonnet closed.
Page 138 Before Driving Security System ▼ To Stop the Alarm To cancel the intrusion sensor, press the intrusion sensor cancel button on A triggered alarm can be turned off the transmitter within 20 seconds after using any one of the following pressing the lock button.
Page 139 (600 miles) may add to the Environment performance, economy, and life of the vehicle. How you operate your Mazda determines how far it will travel on a Do not race the engine.  tank of fuel. Use these suggestions to Do not maintain one constant ...
Page 140 Before Driving Driving Tips Hazardous Driving WARNING ▼ Hazardous Driving Never stop the engine when going down a hill: Stopping the engine when going down WARNING a hill is dangerous. This causes the loss of power steering and power brake Be extremely careful if it is necessary control, and may cause damage to the to downshift on slippery surfaces:...
Page 141 ▼ Floor Mat If using an all-weather mat for winter We recommend the use of Genuine use always remove the original ﬂoor Mazda ﬂoor mats. mat. WARNING Make sure the ﬂoor mats are secured with the grommets or the retainers to...
Page 142 Do not spin the wheels at high speed, Ask an expert repairer (we recommend and do not allow anyone to stand an Authorised Mazda Repairer) to behind a wheel when pushing the check the following: vehicle:...
Page 143 Before Driving Driving Tips ▼ Tyre Chains Drive slowly. Braking performance  can be adversely affected if snow or Check local regulations before using ice adheres to the brake tyre chains. components. If this situation occurs, drive the vehicle slowly, releasing the CAUTION accelerator pedal and lightly applying the brakes several times until the...
Page 144 Before Driving Driving Tips Tyre chain selection (Europe) Side view Mazda recommends hexagon type steel ring chains. Select the proper type according to your tyre size. 1. A Cross section view Tyre size Tyre chain 205/60R16 Hexagon type 215/45R18 Hexagon type...
Page 145 If the vehicle has been provides improved operation and immersed in water, consult an expert requires minimum maintenance. repairer (we recommend an Authorised Mazda Repairer). To get the most from it, observe the following. 1. Change engine oil and ﬁlter according to Scheduled Maintenance.
Page 146 Repairer) if you need further details. CAUTION Do not tow a trailer during the ﬁrst 1,000 km (600 miles) of your new Mazda. If you do, you may damage the engine, transmission, differential, wheel bearings, and other power train components.
Page 147 Before Driving Towing ▼ Weight Limits The total trailer weight, gross combination weight and trailer nose weight must be within the prescribed limits in the Trailer Towing-Load Table. TOTAL TRAILER WEIGHT: Sum of weights of the trailer and its load. GROSS COMBINATION WEIGHT: Sum of total trailer weight and towing vehicle weight;...
Page 148 Before Driving Towing Maximum trailer towing-load table Europe/Gradient up to 12% GROSS COMBI- MODEL TOTAL TRAILER WEIGHT NATION WEIGHT Transmis- Drive Trailer without Trailer with Trailer with Body Engine sion system brake brake brake Manual SKYAC- 600 kg (1,322.7 1,300 kg 3,169 kg Saloon transmis-...
Page 149 Before Driving Towing GROSS COMBI- MODEL TOTAL TRAILER WEIGHT NATION WEIGHT Transmis- Drive Trailer without Trailer with Trailer with Body Engine sion system brake brake brake Automatic SKYAC- 600 kg (1,322.7 1,300 kg 3,313 kg Hatchback transmis- TIV-X 2.0 (2,865.9 lb) (7,303.8 lb) sion Manual...
Page 150 Before Driving Towing GROSS COMBI- MODEL TOTAL TRAILER WEIGHT NATION WEIGHT Transmis- Drive Trailer without Trailer with Trailer with Body Engine sion system brake brake brake Manual SKYAC- 600 kg (1,322.7 1,300 kg 3,175 kg Hatchback transmis- TIV-G 2.0 (2,865.9 lb) (6,999.6 lb) sion Automatic...
Page 151 Before Driving Towing GROSS COMBI- MODEL TOTAL TRAILER WEIGHT NATION WEIGHT Transmis- Drive Trailer without Trailer with Trailer with Body Engine sion system brake brake brake Automatic SKYAC- 600 kg (1,322.7 1,200 kg 3,045 kg Saloon transmis- TIV-G 1.5 (2,645.5 lb) (6,713.0 lb) sion Automatic...
Page 152 Before Driving Towing GROSS COMBI- MODEL TOTAL TRAILER WEIGHT NATION WEIGHT Transmis- Drive Trailer without Trailer with Body Engine Trailer with brake sion system brake brake Automatic SKYAC- 600 kg (1,322.7 1,300 kg 3,271 kg Hatchback transmis- TIV-X 2.0 (2,865.9 lb) (7,211.2 lb) sion TRAILER NOSE WEIGHT: 80 kg (176.3 lb)
Page 153 Before Driving Towing South Africa/Gradient up to 12% GROSS COMBI- MODEL TOTAL TRAILER WEIGHT NATION WEIGHT Transmis- Drive Trailer without Trailer with Body Engine Trailer with brake sion system brake brake Manual SKYAC- 600 kg (1,322.7 1,000 kg 2,812 kg Saloon transmis- TIV-G 1.5...
Page 154 ▼ Trailer Hitch When towing a trailer, use an appropriate trailer hitch. We recommend using a genuine Mazda trailer hitch. Use the original holes drilled by the vehicle manufacture for securing the trailer hitch. Contact your Authorised Mazda Repairer for more information.
Page 155 Before Driving Towing Saloon 1. 350 ― 420 mm (13.8 ― 16.5 in) 2. 1103.7 mm (43.453 in) 3. 1022.2 mm (40.244 in) 4. MAX. 80 kg (176.3 lb) 5. Hitch coupling point 3-69...
Page 156 Do not connect a trailer lighting system tyre pressure chart on the driver's door directly to the lighting system of your frame. Trailer tyre size, load rating, and Mazda. This may damage your inﬂation pressures should conform to vehicle's electrical system and lighting tyre manufacturer speciﬁcations.
Page 157 Towing ▼ Trailer Towing Tips CAUTION Before driving If the vehicle exceeds 100 km/h (62 Verify that your Mazda maintains a mph) with a trailer in tow, the  vehicle could be damaged. near-normal attitude when a loaded When ascending a hill, shift into a or unloaded trailer is connected.
Page 158 Before Driving Towing Starting on an Incline 1. Start the engine (page 4-5). 2. Release the parking brake and slowly pull away a short distance from the wheel blocks. 3. Stop on the nearest level ground, set the parking brake, and pick up the wheel blocks.
Page 159 When Driving Information concerning safe driving and stopping. Start/Stop Engine..... 4-4 Switches and Controls..... 4-59 Ignition Switch.......4-4 Lighting Control....4-59 Starting the Engine....4-5 Rear Fog Light ..... 4-64 Turning the Engine Off..4-11 Turn and Lane-Change i-stop .........4-12 Signals........ 4-65 Windscreen Wipers and Cylinder Deactivation ..4-22 Washer.......
Page 160 AWD......4-98 Mazda Radar Cruise Control i-ACTIV AWD Operation ..4-98 (MRCC) ......4-138 Mazda Radar Cruise Control with Stop & Go function (MRCC with Power Steering..... 4-100 Stop & Go function) ..4-147 Power Steering....4-100 Cruising & Traffic Support (CTS) .......
Page 161 Petrol Particulate Filter..4-249 Rear View Monitor....4-251 Petrol Particulate Filter Rear View Monitor ... 4-251 (SKYACTIV-X 2.0)....4-249 Parking Sensor System... 4-267 Diesel Particulate Filter..4-250 Parking Sensor System ..4-267 Diesel Particulate Filter (SKYACTIV-D 1.8)..... 4-250 *Some models.
Page 162: When Driving
When Driving Start/Stop Engine Ignition Switch The power supply to electrical devices ▼ Push Button Start Positions turns off and the indicator light (amber) also turns off. The system operates only when the key In this position the steering wheel is is within operational range.
Page 163 When the push button start is pressed Consult an expert repairer (we to ON, the sound of the fuel pump recommend an Authorised Mazda motor operating near the fuel tank can Repairer) for details. If the push be heard. This does not indicate an button start system functions have abnormality.
Page 164 When Driving Start/Stop Engine This is for improved exhaust gas 6. Make sure that the push button puriﬁcation and does not indicate start indicator light (green) turns any parts defect. 1. Make sure you are carrying the key. 2. Occupants should fasten their seat belts.
Page 165 ACC repairer (we recommend an or ON. Authorised Mazda Repairer) as Refer to KEY Warning Indication/ soon as possible. If this occurs, Warning Light (Red) on page the engine can be force-started.
Page 166 (manual transmission) or the expert repairer (we recommend brake pedal (automatic an Authorised Mazda Repairer) transmission) until the glow (page 7-46). indicator light in the instrument cluster turns off and the engine starts, after pressing the push button start.
Page 167 When Driving Start/Stop Engine ▼ Engine Start Function When Key (SKYACTIV-D 1.8)  If the ambient temperature is Battery is Dead lower than about － 10 °C (14 °F), the maximum engine CAUTION speed may not be attained for about 3 minutes after the engine When starting the engine by holding starts to protect the engine.
Page 168 (amber) ﬂashes. In this case, the engine may start, however, have the vehicle checked at an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. If the push button start indicator  light (green) does not illuminate, perform the operation from the beginning again.
Page 169 Have your vehicle inspected at an 1. Stop the vehicle completely. expert repairer (we recommend an 2. (Manual transmission) Authorised Mazda Repairer) as soon as Shift into neutral and set the possible. If this occurs, the engine can parking brake.
Page 170 When Driving Start/Stop Engine NOTE i-stop The cooling fan in the engine  ▼ i-stop compartment could turn on for a few minutes after the ignition is switched The i-stop function automatically stops from ON to OFF, whether or not the the engine when the vehicle is stopped A/C is on or off, to cool the engine at a traffic light or stuck in traffic, and...
Page 171 (AUTOHOLD operation turned off and than neutral. When not using Mazda Radar Cruise The engine restarts automatically Control with Stop & Go function after releasing the brake pedal or (MRCC with Stop &...
Page 172 When Driving Start/Stop Engine (When the vehicle is stopped by the 3. If the selector lever is in the N or P MRCC with Stop & Go function/CTS position, the engine does not stop hold control) restart when the brake pedal is 1.
Page 173 When Driving Start/Stop Engine Operation conditions (With M Hybrid)  The temperature and charge Under the following conditions, engine  condition of the M Hybrid battery idling stops and the i-stop indicator is good. light (green) turns on. The Integrated Starter-Generator ...
Page 174 When Driving Start/Stop Engine The steering wheel is almost in the While driving (With M Hybrid)  straight-ahead position (idling may The selector lever is in the D  not stop even with the steering position (not in second gear ﬁxed wheel in the straight-ahead mode).
Page 175 When Driving Start/Stop Engine After the battery terminals are The temperature setting dial of the   disconnected for some reasons such air conditioner is in the maximum as for battery replacement. heating or maximum cooling (A/C (SKYACTIV-X 2.0) ON) position. ...
Page 176 Engine idling may not stop right after driver's door is opened, or the the battery terminals are disconnected. bonnet is opened. In addition, if the battery is replaced, the i-stop functions must be veriﬁed. Consult an expert repairer (we recommend an Authorised Mazda Repairer). 4-18...
Page 177 When Driving Start/Stop Engine ▼ i-stop OFF Switch ▼ Vehicle Roll Prevention Function (Automatic transmission) When pressing the switch, the i-stop function stops and the i-stop OFF Vehicles with the i-stop function are switch indicator light turns on. If the equipped with a vehicle roll prevention switch is pressed again, the i-stop function.
Page 178 When Driving Start/Stop Engine The selector lever is in the N 3. Engine restarted position. If the selector lever is shifted to the N position and the brake pedal is released while the i-stop function is operating, the brake force is gradually released.
Page 179 NOTE display. A problem in the system may be Refer to the Fuel Efficiency Monitor indicated under the following section in the Mazda Connect conditions. Have your vehicle Owner's Manual. inspected by an expert repairer (we recommend an Authorised Mazda i-stop warning light (amber) Repairer).
Page 180 When Driving Start/Stop Engine (European model)  Cylinder Deactivation The light ﬂashes when the driver's door is opened while engine idling is ▼ Cylinder Deactivation stopped to notify the driver that The cylinder deactivation is a function engine idling is stopped. It turns off designed to reduce fuel consumption when the driver's door is closed.
Page 181 When Driving Instrument Cluster and Display Instrument Cluster and Instrument Cluster Display ▼ Instrument Cluster ▼ Instrument Cluster and Display ① Tachometer....page 4-24 ② Multi-information Display....① Instrument Cluster..page 4-23 ........page 4-25 ② Active Driving Display..page 4-42 ③...
Page 182 When Driving Instrument Cluster and Display ▼ Tachometer The tachometer shows engine speed in thousands of revolutions per minute (rpm). CAUTION Do not run the engine with the tachometer needle in the RED ZONE. This may cause severe engine damage. 1.
Page 183 When Driving Instrument Cluster and Display ▼ Multi-information Display 1. Multi-information Display 2. INFO switch The multi-information display indicates the following information. Speedometer  Odometer  Trip meter  Outside temperature  Distance-to-empty  Average fuel economy  Current fuel economy ...
Page 184 3. i-ACTIVSENSE display 4. Message display Displayed only when a warning occurs. The type of display for the fuel economy and the maximum driving distance can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. 4-26...
Page 185 When Driving Instrument Cluster and Display ▼ Odometer, Trip Meter and Trip Trip meter Meter Selector The driving distance for a speciﬁed interval is indicated. Two types (TRIP A, You can switch between the odometer TRIP B) of interval distance and the and trip meter display using the TRIP average fuel economy for each can be switch.
Page 186 When Driving Instrument Cluster and Display ▼ Engine Coolant Temperature During normal driving, the engine  coolant temperature stabilizes at Gauge 100 °C (210 °F) or less, and the Displays the engine coolant gauge indicates a range lower than temperature. The blue range of the 100 °C (210 °F).
Page 187 When Driving Instrument Cluster and Display Refer to Low Fuel Warning Indication/ The brightness of the instrument panel Warning Light on page 7-65. and instrument panel illuminations can be adjusted by pressing the instrument NOTE panel illumination switch while the After refuelling, it may require some instrument panel illumination is ...
Page 188 Refer to the Settings section in the of the daytime screen. Mazda Connect Owner's Manual. ▼ Outside Temperature Display NOTE When the temperature unit indicated When the ignition is switched ON, the in the outside temperature display is outside temperature is displayed.
Page 189 When Driving Instrument Cluster and Display ▼ Distance-to-empty ▼ Average Fuel Economy This displays the approximate distance The average fuel economy is calculated you can travel on the remaining fuel every minute from the total travelled based on the fuel economy. distance on the trip meter and the total The distance-to-empty will be fuel consumption, and the average fuel...
Page 190 The red arrow on the scale indicates  the average fuel economy. 1. “Speed Alert” message is displayed The vehicle speed alarm can be set using the centre display. Refer to the Settings section in the Mazda Connect Owner's Manual. 4-32...
Page 191 Refer to Front Cross Traffic Alert  Multi-information Display on page (FCTA) on page 4-131. 7-69. Refer to Mazda Radar Cruise Control  (MRCC) on page 4-140. Refer to Mazda Radar Cruise Control  with Stop & Go function (MRCC with Stop &...
Page 192 When Driving Instrument Cluster and Display ▼ Warning/Indicator Lights Instrument Cluster varies depending on model and speciﬁcations. 1. Instrument Cluster 2. Front Centre of Headliner Warning lights will appear in any of the highlighted areas 4-34...
Page 193 When Driving Instrument Cluster and Display ▼ Warning Indication/Warning Lights These lights turn on or ﬂash to notify the user of the system operation status or a system malfunction. Signal Warning Refer to 7-54 Brake System Warning Indication/Warning Light (Red) Electronic Brake Force Distribution...
Page 194 When Driving Instrument Cluster and Display Signal Warning Refer to 7-59 i-stop Warning Indication/Warning Light (Amber) 7-60 Automatic Transmission Warning Indication/Warning Light 7-62 AWD Warning Indication/Warning Light Air Bag/Seat Belt Pretensioner System Warning Indication/Warning 7-61 Light Flashing 7-63 Tyre Pressure Monitoring System (TPMS) Warning Indication/Warn- ing Light Turns on 7-67...
Page 195 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer). ▼ Indication/Indicator Lights These lights turn on or ﬂash to notify the user of the system operation status or a...
Page 196 *1*2 7-58 Electric Parking Brake (EPB) Indication/Indicator Light 4-82 AUTOHOLD Active Indicator Light Mazda Radar Cruise Control with Stop & Go function (MRCC with 4-156 Stop & Go function) indicator Light 4-171 Cruising & Traffic Support (CTS) Indicator Light 4-38...
Page 197 4-109 Adaptive LED Headlights (ALH) Indicator Light (Green) 4-142 Mazda Radar Cruise Control (MRCC) Standby Indication Mazda Radar Cruise Control with Stop & Go function (MRCC with 4-152 Stop & Go function) Standby Indication (White) 4-164 Cruising & Traffic Support (CTS) Standby Indication...
Page 198 If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer). 2 The light turns on continuously when the parking brake is applied.
Page 199 When the maintenance period unit is necessary. Refer to the Information section in arrives, have your vehicle inspected the Mazda Connect Owner's by an expert repairer (we Manual. recommend an Authorised Mazda Repairer) as soon as possible. If maintenance is neglected, a ▼...
Page 200 When Driving Instrument Cluster and Display Active Driving Display ▼ Active Driving Display 1. Display 2. Dust-proof sheet WARNING Always adjust the display brightness and position with the vehicle stopped: Adjusting the display brightness and position while driving the vehicle is dangerous as doing so could distract your attention from the road ahead and lead to an accident.
Page 201 Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings  Refer to Mazda Radar Cruise Control (MRCC) on page 4-138. Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go  function) Operation Conditions and Warnings Refer to Mazda Radar Cruise Control with Stop &...
Page 202 When Driving Instrument Cluster and Display NOTE The desired driving position (display position, brightness level, display  information) can be called up after programming the position. Refer to Driving Position Memory on page 2-11. The street name may not be displayed depending on the market and region. ...
Page 203 When Driving Manual Transmission Operation Manual Transmission WARNING Shift Pattern Do not use sudden engine braking on slippery road surfaces or at high ▼ Manual Transmission Shift Pattern speeds: Shifting down while driving on wet, snowy, or frozen roads, or while driving at high speeds causes sudden engine braking, which is dangerous.
Page 204 When Driving Manual Transmission Operation ▼ Gear Shift Indicator (GSI) NOTE If shifting to R is difficult, shift back The GSI supports you to obtain  into neutral, release the clutch pedal, optimum fuel economy and smooth and try again. driving.
Page 205 When Driving Manual Transmission Operation NOTE The GSI turns off when the following operations are performed. The vehicle is stopped.  The vehicle is put in neutral.  The vehicle is driven in reverse.  The clutch is not fully engaged when ...
Page 206 When Driving Automatic Transmission NOTE Automatic Transmission The Sport AT has an option that is not Controls included in the traditional automatic transmission that gives the driver the ▼ Automatic Transmission Controls option of selecting each gear instead of leaving it to the transmission to shift gears.
Page 207 4. Move the selector lever. out of P unless the brake pedal is Take the vehicle to an expert repairer depressed. (we recommend an Authorised Mazda Repairer) to have the system checked. To shift from P: Type B 1. Depress and hold the brake pedal.
Page 208 When Driving Automatic Transmission N (Neutral) Transmission Ranges In N, the wheels and transmission are ▼ Transmission Ranges not locked. The vehicle will roll freely even on the slightest incline unless the The shift position indication in the  parking brake or brakes are on. instrument cluster illuminates.
Page 209 When Driving Automatic Transmission M (Manual) Manual Shift Mode M is the manual shift mode position. ▼ Manual Shift Mode Gears can be shifted up or down by operating the selector lever. The manual shift mode gives you the Refer to Manual Shift Mode on page feel of driving a manual transmission 4-51.
Page 210 When Driving Automatic Transmission ▼ Indicators (SKYACTIV-D 1.8 (European  model)) If the engine oil temperature becomes too high, there is the possibility that the transmission will switch to automatic shift mode, cancelling manual shift mode and turning off the gear position indicator illumination.
Page 211 When Driving Automatic Transmission Using steering shift switch CAUTION To shift up to a higher gear with the Do not rely solely on the shift-up/ steering shift switches, pull the UP shift-down recommendations by switch (+/OFF) toward you once with indications.
Page 212 When Driving Automatic Transmission This function is cancelled while the Using steering shift switch DSC is turned off. However, if the To shift down to a lower gear with the vehicle is continuously driven at a steering shift switches, pull the DOWN high rpm, the gears may switch (–) toward you once with your automatically shift up to protect the...
Page 213 When Driving Automatic Transmission ▼ Second Gear Fixed Mode Keep your hands on the steering wheel rim when using ﬁngers on the When the selector lever is moved back steering shift switches: + while the vehicle speed is about 10 Putting your hands inside the rim of km/h (6.2 mph) or less, the the steering wheel when using the...
Page 214 When Driving Automatic Transmission ▼ Shift Gear (Shifting) Speed Limit For each gear position while in the manual mode, the speed limit is set as follows: When the selector lever is operated within the range of the speed limit, the gear is shifted.
Page 215 When Driving Automatic Transmission NOTE Direct Mode Shifting up and down while in direct mode may not be possible depending ▼ Direct Mode on the vehicle speed. In addition, Direct mode can be used for because direct mode is cancelled temporarily switching gears by (released) depending on the rate of operating the steering shift switch...
Page 216 When Driving Automatic Transmission Climbing steep grades from a stop Driving Tips To climb a steep grade from a stopped ▼ Driving Tips position: 1. Depress the brake pedal. 2. Shift to D or M1, depending on the WARNING load weight and grade steepness. 3.
Page 217 When Driving Switches and Controls Lighting Control ▼ Headlights Turn the headlight switch to turn the headlights and other exterior lights on or off. When the tail lights, position lights, and the number plate lights are turned on, the lights-on indicator light in the instrument cluster turns on. NOTE To prevent discharging the battery, do not leave the lights on while the engine is ...
Page 218 When Driving Switches and Controls When the light switch is switched to the OFF position, and then to the position again, the running lights turn off directly after starting the engine. The running lights turn on when you begin driving the vehicle. With auto-light control AUTO Surround-...
Page 219 The sensitivity of the auto-light control may be changed.  Refer to the Settings section in the Mazda Connect Owner's Manual. 4-61...
Page 220  after all of the doors are closed can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. If no operations are done for 3  minutes after the lever is pulled, the headlights turn off.
Page 221 The running lights turn on or off automatically. NOTE (Except countries prohibited by law) The running lights can be deactivated. Refer to the Settings section in the Mazda Connect Owner's Manual. 1. Lock button 2. Unlock button NOTE Operation of the leaving home light ...
Page 222 When Driving Switches and Controls NOTE Rear Fog Light While the position lights are turned on, the rear fog light remains on even if the ▼ Rear Fog Light headlights are turned off. The rear fog The rear fog light can be used when light turns off when the position lights the ignition is switched ON.
Page 223 A personalised function is available  to change the turn indicator sound volume. Refer to the Settings section in the Mazda Connect Owner's Manual. 1. Right turn 2. Right lane change 3. OFF 4. Left lane change 5. Left turn...
Page 224 Only use windscreen washer ﬂuid Refer to the Settings section in the mixed with anti-freeze protection in Mazda Connect Owner's Manual. freezing weather conditions: Using windscreen washer ﬂuid without anti-freeze protection in freezing weather conditions is dangerous as it...
Page 225 OFF, consult an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. ▼ Windscreen Wipers Turn the wipers on by pressing the lever up or down.
Page 226 When Driving Switches and Controls CAUTION Switch Position Wiper operation Type A Type B Do not shade the rain sensor by Operation while adhering a sticker or a label on the MIST pulling up lever windscreen. Otherwise the rain sensor will not operate correctly. Stop Auto control AUTO...
Page 227 When Driving Switches and Controls Refer to the Settings section in the NOTE Mazda Connect Owner's Manual. Switching the auto-wiper lever from  ▼ Windscreen Washer the OFF to the AUTO position while driving activates the windscreen Pull the wiper lever toward you to wipers once, after which they spray washer ﬂuid and operate the...
Page 228 ﬂuid level (page 6-32). If the ﬂuid level is normal and the washer still does not work, consult an expert repairer (we recommend an Authorised Mazda Repairer). Turn the wiper on by turning the rear wiper/washer switch. Switch Position Wiper operation Spray washer ﬂuid and op-...
Page 229 When Driving Switches and Controls Rear Window Defogger Headlight Washer ▼ Rear Window Defogger ▼ Headlight Washer The rear window defogger clears fog The engine must be started and the from the rear window. headlights must be turned on. The ignition must be switched ON to If you want to operate headlight use the defogger.
Page 230 OFF. Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Windscreen Wiper De-icer 1. Indicator light The thermal ﬁlaments at the following ▼ Mirror Defogger...
Page 231 When Driving Switches and Controls Horn Hazard Warning Flasher ▼ Horn ▼ Hazard Warning Flasher The hazard warning lights should To sound the horn, press the always be used when you stop on or mark on the steering wheel. near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take...
Page 232 When Driving Switches and Controls If the brake pedal is depressed while  driving on slippery roads, the emergency stop signal system could operate causing all the turn and lane change signals to ﬂash. Refer to Emergency Stop Signal System on page 4-84.
Page 233 When Driving Brake Dry off brakes that have become wet Brake System by driving slowly, releasing the accelerator pedal and lightly applying ▼ Foot Brake the brakes several times until the This vehicle has power-assisted brakes brake performance returns to normal: that adjust automatically through Driving with wet brakes is dangerous.
Page 234 When Driving Brake ▼ Electric Parking Brake (EPB) Apply the parking brake when leaving the vehicle: The EPB system applies the parking Not applying the parking brake when brake using an electric motor. The parking the vehicle is dangerous as the system can operate automatically and vehicle may move unexpectedly and manually.
Page 235 When Driving Brake If there is a problem with the brake Releasing the parking brake manually  system (foot brake) while driving the When the brake pedal is ﬁrmly vehicle, continually pulling up the depressed and the EPB switch is EPB switch will apply the brakes and pressed while the ignition is switched decelerate or stop the vehicle.
Page 236 When Driving Brake Cancelling the parking brake NOTE To release the parking brake when the automatic operation ignition is switched OFF, it is necessary The parking brake automatic operation to cancel the parking brake auto can be cancelled by doing any of the operation.
Page 237 When you hear this noise, consult an indicate a malfunction. expert repairer (we recommend an The brake assist equipment does not  Authorised Mazda Repairer) as soon as supersede the functionality of the possible. vehicle's main braking system. WARNING ▼ Brake Override System...
Page 238 When Driving Brake AUTOHOLD ▼ AUTOHOLD The AUTOHOLD function automatically holds the vehicle stopped, even if you take your foot off the brake pedal. This function can be best used while stopped in traffic or at a traffic light. The brakes are released when you start driving the vehicle. WARNING Do not rely completely on the AUTOHOLD function: The AUTOHOLD function is only designed to assist the brake operation while the...
Page 239 Under the following conditions, a problem with the AUTOHOLD is occurring.  Have your vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. A message is indicated on the multi-information display and a warning sound is ...
Page 240 When Driving Brake ▼ AUTOHOLD System is Turned On NOTE When all of the following conditions Press the AUTOHOLD switch and are met, the AUTOHOLD operates and when the AUTOHOLD standby the brakes are held. indicator light turns on, the The ignition is switched ON (engine AUTOHOLD function turns on.
Page 241 When Driving Brake ▼ AUTOHOLD System is Turned Off NOTE If the Electric Parking Brake (EPB) Depress the brake pedal and press the  switch is pulled while the AUTOHOLD switch. The AUTOHOLD AUTOHOLD is operating, the is turned off and the AUTOHOLD parking brake is applied and the standby indicator light turns off.
Page 242 When Driving Brake There is a problem with the Emergency Stop Signal  AUTOHOLD function. System ▼ Emergency Stop Signal System If you apply the brakes suddenly while driving at a speed of about 55 km/h (34 mph) or faster, the emergency stop signal system automatically and rapidly ﬂashes all the direction indicator lights to caution drivers behind your vehicle...
Page 243 When Driving Brake Always conﬁrm the safety around the Hill Launch Assist (HLA) vehicle before starting to drive the vehicle. ▼ Hill Launch Assist (HLA) The HLA functions to assist in NOTE accelerating the vehicle from a stop on HLA does not operate on a gentle ...
Page 244 When Driving ABS/TCS/DSC NOTE Antilock Brake System Braking distances may be longer on (ABS)  loose surfaces (snow or gravel, for example) which usually have a hard ▼ Antilock Brake System (ABS) foundation. A vehicle with a normal The ABS control unit continuously braking system may require less monitors the speed of each wheel.
Page 245 System (TCS) as a substitute for safe correctly. Take your vehicle to an driving: expert repairer (we recommend an The Traction Control System (TCS) Authorised Mazda Repairer). cannot compensate for unsafe and reckless driving, excessive speed, NOTE tailgating (following another vehicle In addition to the indicator light ...
Page 246 ▼ Dynamic Stability Control (DSC) Use tyres of the correct size The Dynamic Stability Control (DSC) speciﬁed for your Mazda on all 4 automatically controls braking and wheels. engine torque in conjunction with Use tyres of the same...
Page 247 If the light remains illuminated and the TCS/DSC is not switched off, take your vehicle to an expert repairer (we 1. DSC OFF switch indicator light recommend an Authorised Mazda Repairer). The DSC may have a Press the switch again to turn the malfunction.
Page 248 When Driving ABS/TCS/DSC Leaving the TCS/DSC on will provide  the best traction. If the DSC OFF switch is pressed and  held for 10 seconds or more, the DSC OFF switch malfunction detection function operates and the DSC system activates automatically. The DSC OFF indicator light turns off while the DSC system is operative.
Page 249 When Driving M Hybrid M Hybrid ▼ M Hybrid M Hybrid uses the Integrated Starter-Generator (ISG) with excellent power generation efficiency to generate electricity from the kinetic energy generated when the vehicle decelerates. The system uses the electrical power stored in the M Hybrid battery, which is a large-capacity battery to improve driveability and fuel economy by reducing engine load and providing motor assist.
Page 250 If there is a problem with M Hybrid, a warning indication is displayed. M Hybrid operation status is displayed on the system operation status display of the fuel efficiency monitor. Refer to the Information section in the Mazda Connect Owner's Manual. ▼ Unique M Hybrid Handling Type (sound/vibra-...
Page 251 M Hybrid cannot be activated, contact Never remove and disassemble the an expert repairer (we recommend an Authorised Mazda Repairer). brackets and connectors securing the terminal part, wiring harness, and ▼ M Hybrid Precautions the M Hybrid battery.
Page 252 If the M Hybrid battery is used on a vehicle in a safe place immediately and vehicle other than one equipped contact an expert repairer (we recommend an Authorised Mazda with M Hybrid (including modiﬁed Repairer). vehicles), accidents such as...
Page 253 When Driving M Hybrid Do not come near the vehicle if electrolyte is leaking from the M Hybrid battery: Even if the M Hybrid battery is damaged, large quantities of electrolyte will not ﬂow out due to the internal structure of the battery, however, in the unlikely event that it does, it will produce steam.
Page 254  driving at higher engine speeds Cruise Control is set.  increases and it may increase fuel Mazda Radar Cruise Control with  consumption. Mazda recommends Stop & Go function (MRCC with that you cancel the sport mode on Stop & Go function) is set.
Page 255 When Driving Drive Selection ▼ Select Mode Indicator Light When the sport mode is selected, the select mode indicator light turns on in the instrument cluster. 1. Select mode indicator light NOTE If the drive selection cannot be switched to sport mode, the select mode indicator light ﬂashes to notify the driver.
Page 256: I-Activ Awd
When Driving i-ACTIV AWD ▼ Tyres and Tyre Chains i-ACTIV AWD Operation The condition of the tyres plays a large ▼ i-ACTIV AWD Operation role in the performance of the vehicle. Moreover, to prevent adverse effects to AWD provides excellent drivability on the drive assembly, please note the snow-covered and ice-packed roads, following:...
Page 257 When Driving i-ACTIV AWD ▼ Towing If the vehicle requires towing, have it towed with all 4 wheels completely off the ground. Refer to Towing Description on page 7-50. 4-99...
Page 258: Power Steering
If the steering feels stiffer than usual during normal driving or the steering vibrates, consult an expert repairer (we recommend an Authorised Mazda Repairer). The malfunction indication notiﬁes  the driver of system abnormalities and operation conditions.
Page 259: I-Activsense
Mazda Radar Cruise Control accidents. (MRCC)......page 4-138 Mazda Radar Cruise Control with Stop Driver awareness support systems & Go function (MRCC with Stop & Go Nighttime visibility function)......page 4-147 Adaptive LED Headlights (ALH) ...
Page 260 Smart Brake Support [Rear] Mazda Radar Cruise Control  (SBS-R)......page 4-189 (MRCC) Smart Brake Support [Rear Crossing] (S Mazda Radar Cruise Control with  BS-RC)......page 4-193 Stop & Go function (MRCC with Stop & Go function) ▼ Camera and Sensors Cruising &...
Page 261 When Driving i-ACTIVSENSE Rear side radar sensor Front camera/side cameras/rear camera The rear side radar sensors emit radio waves and detect the radio waves The front camera, side cameras, and reﬂected off a vehicle approaching rear camera shoot images of the area from the rear or an obstruction.
Page 262 When Driving i-ACTIVSENSE NOTE NOTE The status of the system turned on Even if the i-ACTIVSENSE status symbol using the personalisation feature is (warning/risk avoidance support displayed. system) (green) is displayed, systems which do not meet the operation i-ACTIVSENSE status symbol conditions will not operate.
Page 263 Mazda Radar Cruise Control  (MRCC) Mazda Radar Cruise Control with  Stop & Go function (MRCC with Stop & Go function) Cruising & Traffic Support (CTS) ...
Page 264: High Beam Control System (Hbc)
When Driving i-ACTIVSENSE 1. Forward Sensing Camera (FSC) High Beam Control The recognition distance of the Forward System (HBC) Sensing Camera (FSC) varies according to the surrounding conditions. ▼ High Beam Control System (HBC) The warning light turns on when the system has a malfunction.
Page 265 Shift the lever to the high beam position. The HBC indicator light (green) turns NOTE off and the headlight high-beam Operation of the HBC function can be indicator light is illuminated. disabled. Refer to the Settings section in the Mazda Connect Owner's Manual. 4-107...
Page 266: Adaptive Led Headlights (Alh)
When Driving i-ACTIVSENSE Wide-Range Low Beam Adaptive LED Headlights This feature extends the illumination (ALH) range of the light cast by the low beams while driving at a speed less ▼ Adaptive LED Headlights (ALH) than about 40 km/h (25 mph). The ALH are a system which uses the Forward Sensing Camera (FSC) to determine the situation of a vehicle...
Page 267 When there is insufficient darkness  Refer to the Settings section in the such as at dawn or dusk. Mazda Connect Owner's Manual. When the luggage compartment is  loaded with heavy objects or the rear passenger seats are occupied.
Page 268: Lane Departure Warning System (Ldws)
When Driving i-ACTIVSENSE ▼ Manual Switching Lane Departure Warning Switching to low beams System (LDWS) Switch the headlight switch to the ▼ Lane Departure Warning System position, or press the ALH switch. (LDWS) The ALH indicator light (green) turns off. The LDWS alerts the driver that the vehicle may be deviating from its lane.
Page 269 Consult an expert repairer exiting a tunnel. (we recommend an Authorised Back-light is reﬂected off the road  Mazda Repairer) for tyre surface. replacement. The road surface is wet and shiny  after rain, or there are puddles on the road.
Page 270 When Driving i-ACTIVSENSE A vehicle in front of your vehicle is The system detects white (yellow)   running near a white (yellow) lane lane lines. line making it less visible. The windscreen is dirty or foggy.  Strong light is directed from the front ...
Page 271 (If only the LDWS is turned off)  (warning/risk avoidance support Refer to the Settings section in the system) (white) and the i-ACTIVSENSE Mazda Connect Owner's Manual. warning indication/warning light on (If the LDWS is turned off by  the multi-information display turns on operating the i-ACTIVSENSE switch) and a message is indicated.
Page 272: Blind Spot Monitoring (Bsm)
When Driving i-ACTIVSENSE The detection area on this system Blind Spot Monitoring covers the driving lanes on both sides (BSM) of the vehicle and from the rear part of the front doors to about 50 m (164 ft) ▼ Blind Spot Monitoring (BSM) behind the vehicle.
Page 273 (we recommend an time. Authorised Mazda Repairer) as soon Vehicles approaching in the  as possible. opposite direction. A vehicle in an adjacent driving ...
Page 274 When Driving i-ACTIVSENSE In the following case, the ﬂashing of 1. Objects such as guardrails and  the BSM warning indicator light, and concrete walls running alongside the activation of the warning sound the vehicle. and the warning screen indicator display may not occur or they may be delayed.
Page 275 When Driving i-ACTIVSENSE If a Mazda genuine trailer hitch is BSM warning indicator lights  used, the BSM is automatically The BSM warning indicator lights are turned off. equipped on the left and right door In the following cases, it may be ...
Page 276 (If only the BSM is turned off)  driving display). Refer to the Settings section in the Multi-information Display Mazda Connect Owner's Manual. (If the BSM is turned off by  operating the i-ACTIVSENSE switch) Refer to i-ACTIVSENSE Switch on page 4-105.
Page 277: Traffic Sign Recognition System (Tsr)
When Driving i-ACTIVSENSE Traffic Sign Recognition System (TSR) ▼ Traffic Sign Recognition System (TSR) The TSR helps prevent the driver from overlooking traffic signs, and provides support for safer driving by displaying traffic signs on the active driving display/instrument cluster which are recognised by the Forward Sensing Camera (FSC) or recorded in the navigation system while the vehicle is driven.
Page 278 (we recommend an Authorised Mazda Repairer). The TSR operates only if the navigation system SD card (Mazda genuine) is  inserted in the SD card slot. Consult an expert repairer (we recommend an Authorised Mazda Repairer) for details.
Page 279 The TSR can be set to invisible on the active driving display.  Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Traffic Sign Display Indication Speed limit signs (including auxiliary...
Page 280 When Driving i-ACTIVSENSE If the Forward Sensing Camera (FSC) Inclement weather speed limit signs  cannot classify an auxiliary sign (such are displayed when all of the as time restrictions, turning following conditions are met. restrictions, end of section) correctly, The vehicle speed is about 1 km/h ...
Page 281 When Driving i-ACTIVSENSE Do not enter signs Passing prohibited sign A do not enter sign is displayed A passing prohibited sign is displayed   when all of the following conditions when all of the following conditions are met. are met. The vehicle speed is about 80 The vehicle speed is about 1 km/h ...
Page 282 In addition, the warning pattern and the warning activation timing differ depending on the setting contents. Refer to the Settings section in the Mazda Connect Owner's Manual. Speed Limit Sign Alert setting Off: The excessive speed warning is not activated.
Page 283 When Driving i-ACTIVSENSE Visual + Audible: The area around the speed limit sign displayed in the display  ﬂashes in amber and the warning sound is activated at the same time. If the vehicle speed continues to exceed the displayed speed limit sign, the indication stops ﬂashing and remains on.
Page 284: Distance & Speed Alert (Dsa)
 addition, the system is not for Refer to the Settings section in the maintaining the distance between your Mazda Connect Owner's Manual. vehicle and a vehicle ahead. If you (If the DSA is turned off by  neglect to operate the accelerator and...
Page 285: Driver Attention Alert (Daa)
When Driving i-ACTIVSENSE If the ignition is switched OFF while Driver Attention Alert  you have cancelled the system using (DAA) the i-ACTIVSENSE switch, the system is automatically enabled the next ▼ Driver Attention Alert (DAA) time the ignition is switched ON. However, if the system is cancelled The DAA is a system which detects using the personalisation features,...
Page 286 When Driving i-ACTIVSENSE White (yellow) lane lines are less WARNING  visible because of dirt or fading/ patchiness. Do not rely completely on DAA and The vehicle is jolted or swayed  always drive carefully: continuously by strong winds or The DAA detects driver fatigue and rough roads.
Page 287: Driver Monitoring (Dm)
Fatigue and sleepiness are detected:  Warning pattern (caution) The DAA can be set to not activate. Much more fatigue and sleepiness  Refer to the Settings section in the are detected: Warning pattern Mazda Connect Owner's Manual. (warning) 4-129 *Some models.
Page 288 When Driving i-ACTIVSENSE After displaying the warning WARNING  pattern (caution), the next warning pattern (caution) is not displayed Do not rely completely on the DM until 45 minutes have passed. and always drive carefully: After displaying the warning  The DM is a system which detects pattern (warning), the next driver fatigue and sleepiness, and...
Page 289: Front Cross Traffic Alert (Fcta)
(DM) The Driver Monitoring (DM) can be set to inoperable. Refer to the Settings section in the Mazda Connect Owner's Manual. 1. Your vehicle WARNING Always check the surrounding area visually when the vehicle starts to drive at an intersection:...
Page 290 When Driving i-ACTIVSENSE Operation conditions 360°view monitor (vehicles with 360°view monitor) The system operates when all of the following conditions are met: When your vehicle is driven at less  than about 10 km/h (6 mph). (Automatic transmission)  The selector lever is in the D When your vehicle is being driven position.
Page 291 (we recommend an system may not operate normally. Authorised Mazda Repairer) as soon as possible. The front side radar sensor  detection area is obstructed by a Some problem with the system has ...
Page 292: Rear Cross Traffic Alert (Rcta)
Refer to the Settings section in the of your vehicle while your vehicle is Mazda Connect Owner's Manual. being reversed out of a parking space, (If the FCTA is turned off by ...
Page 293 When Driving i-ACTIVSENSE 360°view monitor (vehicles with WARNING 360°view monitor) The RCTA warning indication in the Always check the surrounding area 360°view monitor also visually before actually putting the synchronizes with the Blind Spot vehicle in reverse: Monitoring (BSM) warning The system is only designed to assist indicator light on the door mirrors.
Page 294  from the rear of your vehicle. have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. Some problem with the system  including the Blind Spot Monitoring (BSM) warning indicator lights has occurred.
Page 295 Refer to Rear Side Radar Sensor on page 4-237. If a Mazda genuine trailer hitch is  used, the RCTA is automatically turned off. 4-137...
Page 296: Mazda Radar Cruise Control (Mrcc)
Mazda Radar Cruise WARNING Control (MRCC) Do not rely completely on the MRCC: The MRCC system has detection ▼ Mazda Radar Cruise Control limitations depending on the type of (MRCC) vehicle ahead and its conditions, the The MRCC system is designed to...
Page 297 When Driving i-ACTIVSENSE When entering and exiting Pedestrians  Stationary objects (stopped interchanges, service areas, and  vehicles, obstructions) parking areas of highways (If you exit If a vehicle ahead is travelling at an a highway while headway control is ...
Page 298 (i-ACTIVSENSE display) control function. Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Mazda Radar Cruise Control (MRCC) Display Indication The MRCC setting status and operation conditions are indicated on the multi-information display and the active driving display.
Page 299 When Driving i-ACTIVSENSE ▼ Close Proximity Warning If your vehicle rapidly closes in on the vehicle ahead because the vehicle ahead applies the brakes suddenly while you are travelling in headway control, the warning sound activates and the brake warning is indicated in the display.
Page 300 When Driving i-ACTIVSENSE ▼ Setting the System The MRCC system operates when all of the following conditions are met. The vehicle speed is as follows:  (European models)  About 30 km/h (19 mph) to 200 km/h (125 mph) (Except European models) ...
Page 301 When Driving i-ACTIVSENSE When the MRCC switch is pressed once, the MRCC system turns on, and the MRCC standby indication (white) turns on and the vehicle speed and the distance between the vehicles while in headway control can be set. In addition, the MRCC system display indication is displayed on the multi-information display and the active driving display at the same time.
Page 302 When Driving i-ACTIVSENSE NOTE If a vehicle ahead is detected while travelling at a constant speed, the  vehicle-ahead indication is displayed and headway control is performed. Additionally, when a vehicle ahead is no longer detected, the vehicle-ahead indication turns off and the system switches back to travel at constant speed. The lowest possible speed which can be set on the MRCC system is 30 km/h (19 ...
Page 303 When Driving i-ACTIVSENSE Distance-between-vehicles Indication on active driving dis- guideline Indication on multi-information (at 80 km/h (50 mph) vehicle display play speed) Extremely short (about 25 m (82 ft)) Displays a pop-up image in the active driving display only when the driver operates the switch. NOTE The distance-between-vehicles differs depending on the vehicle speed, and the ...
Page 304 When Driving i-ACTIVSENSE (European models) (Manual transmission)   When switching to a passing lane The shift lever is shifted to neutral  and operating the direction (N) for a certain period of time. indicator, the system provides more The clutch is depressed for a ...
Page 305: Mazda Radar Cruise Control With Stop & Go Function (Mrcc With Stop & Go Function)
MRCC is operating. When this occurs, Stop & Go function) shift gears because the gear position is not appropriate. ▼ Mazda Radar Cruise Control with Stop & Go function (MRCC with Request Indication on display Stop & Go function)
Page 306 When Driving i-ACTIVSENSE When entering and exiting Front radar sensor (page 4-233)  interchanges, service areas, and parking areas of highways (If you exit WARNING a highway while headway control is in use, the vehicle ahead will no Do not rely completely on the MRCC longer be tracked and your vehicle with Stop &...
Page 307 When Driving i-ACTIVSENSE Do not get out of the vehicle while If there is a structure on the road or  the stop hold control is operating: an object (such as a monorail) at a Getting out of the vehicle while the low height off the ground in front of stop hold control is operating is the vehicle, the system may operate.
Page 308 (i-ACTIVSENSE display) control function. Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) Display Indication The MRCC with Stop & Go function...
Page 309 When Driving i-ACTIVSENSE ▼ Close Proximity Warning If your vehicle rapidly closes in on the vehicle ahead because the vehicle ahead applies the brakes suddenly while you are travelling in headway control, the warning sound activates and the brake warning is indicated in the display.
Page 310 In the following cases, the MRCC with Stop & Go function system is cancelled  when the vehicle is travelling at 30 km/h (20 mph) or less and “Mazda Radar Cruise Control Disabled Under 30 km/h (20mph)” is displayed in the multi-information display.
Page 311 When Driving i-ACTIVSENSE 3. MRCC switch When the MRCC switch is pressed once, the MRCC with Stop & Go function system turns on, and the MRCC with Stop & Go function standby indication (white) turns on and the vehicle speed and the distance between the vehicles while in headway control can be set.
Page 312 When Driving i-ACTIVSENSE NOTE If a vehicle ahead is detected while travelling at a constant speed, the  vehicle-ahead indication is displayed and headway control is performed. Additionally, when a vehicle ahead is no longer detected, the vehicle-ahead indication turns off and the system switches back to travel at constant speed. The lowest possible speed which can be set on the MRCC with Stop &...
Page 313 When Driving i-ACTIVSENSE Distance-between-vehicles Indication on active driving dis- guideline Indication on multi-information (at 80 km/h (50 mph) vehicle display play speed) Extremely short (about 25 m (82 ft)) Displays a pop-up image in the active driving display only when the driver operates the switch. NOTE The distance-between-vehicles differs depending on the vehicle speed, and the ...
Page 314 When Driving i-ACTIVSENSE Cancelling the system Resuming control When the following operations are If the MRCC with Stop & Go function performed, the MRCC with Stop & Go system is cancelled, you can resume function system is cancelled, and the control at the previously set speed by MRCC with Stop &...
Page 315 When Driving i-ACTIVSENSE If the i-stop operation conditions are Resume driving information  met during stop hold control, the If you do not resume driving within a engine stops even though the brake few seconds after the vehicle ahead pedal is not depressed. starts moving, the multi-information Refer to i-stop on page 4-12.
Page 316: Cruising & Traffic Support (Cts)
When Driving i-ACTIVSENSE The CTS may not be able to detect a Cruising & Traffic Support vehicle ahead depending on the type (CTS) of vehicle ahead and its conditions, the weather conditions, and the road ▼ Cruising & Traffic Support (CTS) conditions.
Page 317 (Tyres Consult an expert repairer (we could spin causing you to lose recommend an Authorised Mazda vehicle control, or the stop hold Repairer) for tyre replacement. control may not operate.) Tyres of a different speciﬁed size are...
Page 318 When Driving i-ACTIVSENSE If a vehicle ahead is travelling at an The white (yellow) lane lines are   extremely low speed, the system may less visible because of dirt or paint not detect it correctly. ﬂaking. If there is a structure on the road or White (yellow) lane lines or ...
Page 319 When Driving i-ACTIVSENSE The width of a lane is excessively Headway control function  narrow or wide. If a vehicle ahead is detected while The road is excessively uneven.  travelling at a constant speed, the The vehicle is shaken after hitting a ...
Page 320 When Driving i-ACTIVSENSE ▼ Cruising & Traffic Support (CTS) Active driving display Display Indication The CTS setting status and operation conditions are indicated on the multi-information display or the active driving display. 1. Vehicle ahead display Multi-information display (Basic 2. CTS set vehicle speed display) Steering assist function display When the steering assist function...
Page 321 Check the details of the problem on the centre display and then have your vehicle inspected by an expert repairer (we recommend an Authorised Mazda Repairer). Refer to If a Warning Light Turns On or Flashes on page 7-54.
Page 322 The headway control function of the Mazda Radar Cruise Control (MRCC) or  Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) is set to operable (if it was set to inoperable, set it to operable using the personalisation function).
Page 323 When Driving i-ACTIVSENSE Steering assist function The steering assist function operates when all of the following conditions are met. Your vehicle is moving and less than about 55 km/h (34 mph).  White (yellow) lane lines on both sides are detected and you are driving near the ...
Page 324 When the CTS switch is pressed while the Mazda Radar Cruise Control (MRCC) or  the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) system is operating, the CTS operates. In addition, when the MRCC switch is pressed while the CTS is operating, the Mazda Radar Cruise Control (MRCC) or the Mazda Radar Cruise Control with Stop &...
Page 325 When Driving i-ACTIVSENSE NOTE The warnings and brake control do not operate while depressing the accelerator  pedal. The lowest possible speed which can be set on the CTS is 30 km/h (19 mph).  (European models)  When switching to a passing lane and operating the direction indicator, the system provides more acceleration automatically if it determines that more acceleration is required.
Page 326 When Driving i-ACTIVSENSE Distance-between-vehicles Indication on display guideline Indication on active driving dis- Indication on multi-information (at 80 km/h (50 mph) vehicle display play speed) Extremely short (about 25 m (82 ft)) Displays a pop-up image when the CANCEL switch is operated. NOTE The distance-between-vehicles differs depending on the vehicle speed, and the ...
Page 327 When Driving i-ACTIVSENSE In the following cases, the CTS cancel indication is displayed and a sound is activated one time. The DSC has operated.  The Smart Brake Support (SBS) has operated.  The vehicle is driven on a downslope for a long time. ...
Page 328 When Driving i-ACTIVSENSE The driver takes his/her hands off the steering wheel.  The steering wheel is operated abruptly.  There is a problem with the system.  The temperature in the Forward Sensing Camera (FSC) is too high or too low. ...
Page 329 When Driving i-ACTIVSENSE To resume operation If the CTS is temporarily cancelled, it will resume operation at the previously set speed by pressing the RES switch after all of the operation conditions have been met. NOTE If the set speed is not indicated on the display, the system does not operate even if ...
Page 330 When Driving i-ACTIVSENSE If the i-stop operation conditions are Vehicle departure information  met during stop hold control, the If you do not resume driving within a engine stops even though the brake few seconds after the vehicle ahead pedal is not depressed. starts moving during stop hold control, Refer to i-stop on page 4-12.
Page 331: Lane-Keep Assist System (Las)
1. Forward sensing camera (FSC) and size for the front and rear wheels. Consult an expert repairer WARNING (we recommend an Authorised Mazda Repairer) for tyre Do not rely completely on the LAS: replacement. The LAS is not an automated driving NOTE system.
Page 332 When Driving i-ACTIVSENSE White (yellow) lane lines are less Strong light is directed from the front   visible because of bad weather (rain, of the vehicle (such as sunlight, or fog, or snow). headlights (high-beam) of The vehicle is driven on a temporary on-coming vehicles).
Page 333 When Driving i-ACTIVSENSE System malfunction NOTE When the system does not detect a If there is a problem with the system, white (yellow) lane line on one side the i-ACTIVSENSE status symbol only, the system does not operate on (warning/risk avoidance support the side that is not being detected.
Page 334: Adjustable Speed Limiter (Asl)
(If only the LAS is turned off)  ▼ Adjustable Speed Limiter (ASL) Refer to the Settings section in the Mazda Connect Owner's Manual. The ASL is a function to prevent the (If the LAS is turned off by operating ...
Page 335 When Driving i-ACTIVSENSE Multi-information display (Basic Active driving display display) 1. ASL set vehicle speed Speed limiter switch 1. ASL set vehicle speed 1. CANCEL switch Multi-information display 2. RES switch (i-ACTIVSENSE display) 3. LIM switch 1. ASL set vehicle speed 4-177...
Page 336 When Driving i-ACTIVSENSE ▼ Adjustable Speed Limiter (ASL) Standby Indication (White)/ Adjustable Speed Limiter (ASL) Set Indication (Green) ASL standby indication (white) The indication is display in white when the LIM switch is pressed and the ASL is activated. ASL set indication (green) The indication is display in green when a speed has been set.
Page 337 When Driving i-ACTIVSENSE ▼ Adjustable Speed Limiter (ASL) Display The setting status of the ASL is displayed in the active driving display or the display in the instrument cluster. Indication on multi-informa- Status tion display/ Explanation active driving display Displays when the speed limiter switch is operated and the system Stand-by dis- is turned on.
Page 338 When Driving i-ACTIVSENSE ▼ Setting the System 4. To decrease the set speed, press the RES down (SET-) continuously. The set speed can be adjusted in 10 WARNING km/h (5 mph) increments. The set speed can also be adjusted in Always verify the safety of the about 1 km/h (1 mph) increments surrounding area when setting the...
Page 339: Intelligent Speed Assistance (Isa)
When Driving i-ACTIVSENSE ▼ Temporarily Cancelling the System Intelligent Speed The system is temporarily cancelled Assistance (ISA) (stand-by status) when any of the following operations is done while the ▼ Intelligent Speed Assistance (ISA) ASL is displayed. The ISA is a function which keeps the CANCEL switch is pressed ...
Page 340 Active driving display genuine) is inserted. In addition, the Adjustable Speed Limiter (ASL) operates only when the navigation system's SD card (Mazda genuine) is not inserted. Refer to Adjustable 1. set vehicle speed Speed Limiter (ASL) on page 4-176. The system consists of the ISA display...
Page 341 When Driving i-ACTIVSENSE ▼ Intelligent Speed Assistance (ISA) Display The setting status of the ISA is displayed in the active driving display or the display in the instrument cluster. Indication on multi-informa- Status tion display/ Explanation active driving display Displays when the speed limiter switch is operated and the system Stand-by dis- is turned on.
Page 342 MANUAL, or OFF RES switch down (SET-) Refer to the Settings section in the momentary. For example, the set Mazda Connect Owner's Manual. speed decreases about 4 km/h (4 1 When OFF is selected, the mph) by pressing the RES switch Adjustable Speed Limiter (ASL) is down (SET-) 4 times.
Page 343 Excessive speed range setting The range of speed that can exceed the set speed can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. + 0: The vehicle speed is restricted at  the set speed.
Page 344: Smart Brake Support (Sbs)
When Driving i-ACTIVSENSE Smart Brake Support CAUTION (SBS) In the following cases, turn the system off to prevent an unexpected ▼ Smart Brake Support (SBS) operation. The SBS alerts the driver of a possible The vehicle is being towed or when collision using the warning indications towing another vehicle.
Page 345 When Driving i-ACTIVSENSE The accelerator pedal is depressed If a malfunction is detected or the   abruptly. system temporarily stops the The brake pedal is being function due to dirty sensors (such as  depressed. radar sensor or Forward Sensing The steering wheel is being Camera (FSC)), the i-ACTIVSENSE ...
Page 346  of the collision warning can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Stopping the Smart Brake Support (SBS) System Operation 1. “BRAKE!” message is displayed The SBS can be changed to inoperable.
Page 347: Smart Brake Support [Rear] (Sbs-R)
4 mph) and the system determines that vehicle inspected by an expert a collision is unavoidable. repairer (we recommend an Authorised Mazda Repairer). If the vehicle continues to be driven with cracks or scratch marks left around an ultrasonic sensor, the system may operate unnecessarily and cause an unexpected accident.
Page 348 When Driving i-ACTIVSENSE Do not apply a strong force to a rear NOTE ultrasonic sensor and rear camera: The vehicle posture changes  When washing the vehicle, do not depending on the accelerator pedal, spray highly pressurised water against a brake pedal and steering wheel rear ultrasonic sensor and rear camera, operations, which could make it...
Page 349 2 seconds and the SBS-R sensor has deviated for reasons brake is automatically released. such as a collision. If a Mazda genuine trailer hitch is  The vehicle is affected by other  used, the SBS-R is automatically sound waves such as the horn, turned off.
Page 350 Refer to the Settings section in the and the multi-information display. Mazda Connect Owner's Manual. Multi-information display When the SBS-R is cancelled, the SBS OFF indicator light turns on. NOTE When the ignition is switched OFF ...
Page 351: Smart Brake Support [Rear Crossing] (Sbs-Rc)
When Driving i-ACTIVSENSE 2. If there is the possibility of a Smart Brake Support collision with an approaching [Rear Crossing] (SBS-RC) vehicle, the SBS-RC system applies brake and displays “BRAKE!” on the ▼ Smart Brake Support [Rear active driving display and the Crossing] (SBS-RC) multi-information display.
Page 352 If the i-ACTIVSENSE warning indication/ warning light remains illuminated, have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. Some problem with the system  including the SBS-RC system.
Page 353 When Driving i-ACTIVSENSE A large deviation in the installation The vehicle is parked on a slant.   position of a rear side radar sensor on the vehicle has occurred. There is a large accumulation of  snow or ice on the rear bumper near a rear side radar sensor.
Page 354 “Emergency Braking Activated. Depress Brake Pedal to Hold Stop”, after about 2 seconds and the SBS-RC brake is automatically released. 1. “BRAKE!” message is displayed If a Mazda genuine trailer hitch is  used, the SBS-RC is automatically turned off. 4-196...
Page 355: 360° View Monitor
Refer to the Settings section in the driver in checking the area surrounding Mazda Connect Owner's Manual. the vehicle using various indications in When the SBS-RC is cancelled, the SBS the centre display and a warning sound OFF indicator light turns on.
Page 356 When Driving i-ACTIVSENSE Rear view/rear wide view The Rear Cross Traffic Alert (RCTA)  The image from the rear of the uses rear side radar sensor to detect vehicle is displayed on the centre vehicles approaching from the rear display. left and right sides of the vehicle, The image from the rear assists the and it assists the driver in checking...
Page 357 Consult an expert repairer (we The shooting range of the cameras and detection range of the sensors are recommend an Authorised Mazda limited. For example, the areas in black Repairer) for repair, painting, or at the front and rear of the vehicle...
Page 358 Always consult an fallen, larger, or longer than they expert repairer (we recommend an actually are.) Authorised Mazda Repairer) to have Do not apply stickers to a camera or  the vehicle inspected. the area around it. In addition, do If the camera is subjected to ...
Page 359 When Driving i-ACTIVSENSE ▼ Types of Images Displayed on the Screen Top view/Front view Displays the image of the area around the vehicle and the vehicle front. 1. Top view screen 2. Front view screen 3. “Check surroundings for safety.” message is displayed 4-201...
Page 360 When Driving i-ACTIVSENSE Top view/Front wide view Displays the image of the area around the vehicle and the front of the vehicle (wide-area). 1. Top view screen 2. Front wide view screen 3. “Check surroundings for safety.” message is displayed 4-202...
Page 361 When Driving i-ACTIVSENSE Side view Displays the image of the left and right sides of the vehicle. 1. Left side view screen 2. Right side view screen 3. “Check surroundings for safety.” message is displayed 4-203...
Page 362 When Driving i-ACTIVSENSE Top view/Rear view Displays the image of the area around the vehicle and the rear of the vehicle. 1. Top view screen 2. Rear view screen 3. “Check surroundings for safety.” message is displayed 4-204...
Page 363 When Driving i-ACTIVSENSE Top view/Rear wide view Displays the image of the area around the vehicle and the rear of the vehicle (wide-area). 1. Top view screen 2. Rear wide view screen 3. “Check surroundings for safety.” message is displayed ▼...
Page 364 When Driving i-ACTIVSENSE The shift lever/selector lever is in a position other than R.  Display switching The displayed screen can be changed each time the 360°view monitor switch is pressed. 1. Top view/Front view 2. Top view/Front wide view 3.
Page 365 360°View Monitor switch. The 360°View Monitor settings can be changed as follows.  Refer to the Settings section in the Mazda Connect Owner's Manual. Automatic display of the 360°View Monitor when the ultrasonic senor detects  an obstruction.
Page 366  reverse to a forward gear without operating the 360°View Monitor switch to check the front of the vehicle while parallel parking. Refer to the Settings section in the Mazda Connect Owner's Manual. Screen operation/icon WARNING Always stop the vehicle when adjusting the 360°View Monitor image quality.
Page 367 When Driving i-ACTIVSENSE ▼ Top View/Front View Use the top view/front view to assist in checking the safety of the surrounding area when accelerating from a stop, parking, or stopping the vehicle. Display range 1. Target object NOTE In the top view screen, the areas in black at the front and rear of the vehicle image ...
Page 368 When Driving i-ACTIVSENSE Viewing the screen Display/Icon Content Tyre icon Indicates the tyre direction. Moves in conjunction with the steering wheel operation. Projected vehicle path lines (yellow Indicates the approximate projected path of the vehicle. & red) Moves in conjunction with the steering wheel operation. a) Indicates the path where the edge of the front bumper is expected to travel.
Page 369 NOTE The setting can be changed so that the projected vehicle path lines are not displayed. Refer to the Settings section in the Mazda Connect Owner's Manual. How to use the projected vehicle path line function 1. (Screen display) 2. (Actual condition) Make sure that there are no obstructions within the projected vehicle path lines.
Page 370 When Driving i-ACTIVSENSE Display range 1. Target object NOTE In the top view screen, the areas in black at the front and rear of the vehicle image  and the seams where each of the camera images merge are blind spots. Because images displayed in the top view screen are processed from each camera, ...
Page 371 When Driving i-ACTIVSENSE Viewing the screen Display/Icon Content Extended vehicle width lines and Indicates the approximate width of the vehicle and the distance guide lines (blue & red) distance (from front end of bumper) in front of the vehi- cle. The red lines indicate the points up to about 0.5 m (19 ...
Page 372 When Driving i-ACTIVSENSE Display range 1. Target object Viewing the screen Display/Icon Content Projected vehicle path lines (yellow) Indicates the approximate projected path of the vehicle. Moves in conjunction with the steering wheel operation. The projected vehicle path lines (yellow) indicate the path the inner side of the vehicle is expected to travel.
Page 373 NOTE The setting can be changed so that the projected vehicle path lines are not displayed. Refer to the Settings section in the Mazda Connect Owner's Manual. How to use the projected vehicle path line function 1. (Screen display) 2. (Actual condition) Make sure that there are no obstructions within the projected vehicle path lines.
Page 374 When Driving i-ACTIVSENSE For details, refer to the parking sensor obstruction detection indication and warning sound. Refer to Parking Sensor System on page 4-267. Do not turn the steering wheel any more until the vehicle has passed the obstruction, even if the obstruction is not visible on the side view image. If the steering wheel is turned even more, the vehicle may contact the obstruction if it is turned sharply.
Page 375 When Driving i-ACTIVSENSE Because images displayed in the top view screen are processed from each camera,  the top view screen may display in the following ways. If an image containing an object with a conspicuous colour is picked up by any ...
Page 376 NOTE The setting can be changed so that the projected vehicle path lines are not displayed. Refer to the Settings section in the Mazda Connect Owner's Manual. How to use the projected vehicle path line function CAUTION The front of the vehicle swings out wide when turning the steering wheel while reversing.
Page 377 When Driving i-ACTIVSENSE 1. Back the vehicle into the parking space by turning the steering wheel so that the vehicle enters the centre of the parking space. 1. (Screen display) 2. (Actual condition) 2. After the vehicle starts entering the parking space, stop and adjust the steering wheel so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal, and then continue backing up slowly.
Page 378 When Driving i-ACTIVSENSE 3. Once the vehicle width lines and the sides of the parking space on the left and right are parallel, straighten the wheels and back the vehicle slowly into the parking space. Continue checking the vehicle's surroundings and then stop the vehicle in the best possible position.
Page 379 When Driving i-ACTIVSENSE ▼ Top View/Rear Wide View Use the top view/rear wide view to assist in checking the safety of the surrounding area when accelerating from a stop, parking, or stopping the vehicle. Range of displayed screen image 1. Target object NOTE In the top view screen, the areas in black at the front and rear of the vehicle image ...
Page 380 When Driving i-ACTIVSENSE Viewing the screen Display/Icon Content Extended vehicle width lines and These guide lines indicate the approximate width of the distance guide lines (blue & red) vehicle and distance to a point measured from the rear of the vehicle (from the end of the bumper). The red lines indicate the points up to about 0.5 m ...
Page 381 When Driving i-ACTIVSENSE ▼ Margin of Error Between Road Surface on Screen and Actual Road Surface There might be some margin of error between the road surface appearing on the screen and the actual road surface. A margin of error in the perceived distance could lead to an accident, therefore be aware of the following conditions which can more easily produce errors in the perceived distance.
Page 382 When Driving i-ACTIVSENSE There is a steep up or down grade in the road at the front or rear of the vehicle If there is a steep up or down grade in the road at the front or rear of the vehicle, obstructions picked up by the camera can appear farther or closer than the actual distance from the vehicle.
Page 383 When Driving i-ACTIVSENSE Side camera 1. Appears further than actual distance 2. Distance of obstruction being viewed on screen 3. Actual distance of obstruction from vehicle 4. Actual obstruction 5. Obstruction appearing on screen 6. Appears closer than actual distance 4-225...
Page 384 When Driving i-ACTIVSENSE Rear camera 1. Appears further than actual distance 2. Distance of obstruction being viewed on screen 3. Actual distance of obstruction from vehicle 4. Obstruction appearing on screen 5. Actual obstruction 6. Appears closer than actual distance NOTE If the vehicle is on a slope, obstructions taken by the camera can appear farther or closer than the actual distance from the vehicle.
Page 385 When Driving i-ACTIVSENSE Side camera 1. (Screen display) 2. (Actual condition) Rear camera 1. (Screen display) 2. (Actual condition) 3. Sensed distance on screen A>B>C 4. Actual distance B>C=A 4-227...
Page 386 Action to be taken “No camera signal.” is displayed The control unit might be damaged. Have your vehicle inspected by an expert repairer (we recommend an Authorised Screen is pitch-black and blank The camera might be damaged. Mazda Repairer). 4-228...
Page 387: Forward Sensing Camera (Fsc)
Mazda Radar Cruise Control  to not operate correctly. (MRCC) Consequently, each system may not Mazda Radar Cruise Control with  operate normally which could lead Stop & Go function (MRCC with to an unexpected accident. Stop & Go function) Do not disassemble or modify the...
Page 388 Consult an expert repairer (we damage caused by ﬂying gravel or debris in the area around it, stop recommend an Authorised Mazda using the following systems and Repairer) regarding cleaning the consult an expert repairer (we...
Page 389 When Driving i-ACTIVSENSE The Forward Sensing Camera (FSC) The tail lights of the vehicle ahead  are turned off. includes a function for detecting a A vehicle is outside the soiled windscreen and informing the  illumination range of the driver, however, depending on the headlights.
Page 390 Adaptive LED Headlights (ALH) have the windscreen replaced.  warning indication/warning light Consult an expert repairer (we (amber) recommend an Authorised Mazda i-ACTIVSENSE warning indication/ Repairer) for replacement.  warning light The Forward Sensing Camera (FSC) ...
Page 391: Front Radar Sensor
Mazda Radar Cruise Control slouching.  (MRCC) A pedestrian suddenly jumps into  Mazda Radar Cruise Control with the road right in front of the  Stop & Go function (MRCC with vehicle. Stop & Go function) A pedestrian opens an umbrella, or ...
Page 392 Under the following conditions, the consult an expert repairer (we  front radar sensor may not be able to recommend an Authorised Mazda detect vehicles ahead or Repairer). obstructions. The beginning and end of a curve.
Page 393: Front Side Radar Sensor
Stop the system may be required. immediately and have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer). 4-235 *Some models.
Page 394 (we recommend an Authorised Mazda Repairer). For repairs or replacement of the  front side radar sensor, or bumper repairs, paintwork, and replacement...
Page 395: Rear Side Radar Sensor
(we sensor. recommend an Authorised Mazda Saloon Repairer). NOTE The detection ability of the rear side ...
Page 396: Rear/Rear Corner/Rear Side Ultrasonic Sensor
Saloon have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer). For repairs or replacement of the rear  side radar sensor, or bumper repairs, paintwork, and replacement near the...
Page 397: Front Camera/Side Cameras/Rear Camera
When Driving i-ACTIVSENSE Hatchback Front Camera/Side Cameras/Rear Camera ▼ Front Camera/Side Cameras/Rear Camera Your vehicle is equipped with a front camera, side cameras, and a rear camera. The 360°View Monitor uses each camera. Refer to 360°View Monitor on page 4-197. The front camera, side cameras, and rear camera shoot images of the area surrounding the vehicle.
Page 398: Driver Monitoring Camera
When Driving i-ACTIVSENSE You are driving the vehicle with Driver Monitoring  your head excessively tilted to one Camera side or the other. You are moving around extensively.  ▼ Driver Monitoring Camera Your face or your eyes frequently  turn in direction other than straight The driver monitoring camera detects ahead (direction of travel).
Page 399: Cruise Control
When Driving Cruise Control NOTE Cruise Control If your Mazda has the following steering switch, your Mazda is ▼ Cruise Control equipped with the Mazda Radar Cruise Control (MRCC) system, the With cruise control, you can set and Mazda Radar Cruise Control with Stop automatically maintain any speed of &...
Page 400 When Driving Cruise Control ▼ To Set Speed Cruise Set Indication (Green) The indication turns on (green) when a 1. Activate the cruise control system cruising speed has been set. by pressing the cruise switch. The cruise standby indication (white) turns on.
Page 401 When Driving Cruise Control ▼ Changing the Set Vehicle Speed The cruise control will cancel if the  vehicle speed decreases below 20 Follow either of these procedures. km/h (12 mph) when the cruise control is activated, such as when To increase/decrease speed using climbing a steep grade.
Page 402 When Driving Cruise Control ▼ To Resume Cruising Speed at More (Manual transmission)  The shift lever is in the neutral Than 30 km/h (19 mph) position. If the cruise control system is When the cruise control system is  temporarily cancelled (such as by temporarily cancelled by even one of applying the brake pedal) and the...
Page 403: Tyre Pressure Monitoring System
Accordingly, when Refer to the Vehicle Status Monitor the low tyre pressure telltale section in the Mazda Connect illuminates, you should stop and Owner's Manual. check your tyres as soon as possible, and inﬂate them to the proper NOTE pressure.
Page 404 Consult an expert repairer (we illumination of the TPMS low tyre recommend an Authorised Mazda pressure telltale. Repairer) to have the system inspected. Your vehicle has also been equipped...
Page 405 TPMS. procedure. Have an expert repairer (we recommend an Authorised Mazda Repairer) do the registration or register the ID signal codes of the tyre pressure sensors using the following procedure. 4-247...
Page 406 CAUTION When replacing the tyres and wheels, consult an expert repairer (we recommend an Authorised Mazda Repairer) Otherwise, the tyre pressure sensors could be damaged when replacing them. Do not install non-genuine wheels. If wheels other than genuine ones are installed, it may not be possible to install the tyre pressure sensors.
Page 407: Petrol Particulate Filter
When Driving Petrol Particulate Filter Petrol Particulate Filter (SKYACTIV-X 2.0) ▼ Petrol Particulate Filter The petrol particulate ﬁlter collects and removes most of the particulate matter (PM) in the exhaust gas of a petrol engine. PM collected by the petrol particulate ﬁlter is cleared during normal driving, however, PM may not be removed and the petrol particulate ﬁlter warning...
Page 408: Diesel Particulate Filter
When Driving Diesel Particulate Filter Diesel Particulate Filter (SKYACTIV-D 1.8) ▼ Diesel Particulate Filter The diesel particulate ﬁlter collects and removes most of the particulate matter (PM) in the exhaust gas of a diesel engine. PM collected by the diesel particulate ﬁlter is cleared during normal driving, however, PM may not be removed and the diesel particulate ﬁlter warning...
Page 409: Rear View Monitor
Always consult usual, which could cause difficulty in an expert repairer (we recommend conﬁrming the surrounding an Authorised Mazda Repairer) to conditions of the vehicle. Always have the vehicle inspected. drive carefully conﬁrming the safety of the rear and the surrounding conditions by looking directly with your eyes.
Page 410 (we recommend an (automatic transmission) to reverse (R) Authorised Mazda Repairer). position with the ignition switched ON (Predicted vehicle path assist lines  to switch the display to the rear view display type) monitor display.
Page 411 When Driving Rear View Monitor ▼ Displayable Range on the Screen The images on the screen may be different from the actual conditions. 1. (Screen display) 2. (Actual view) 3. Bumper 4. “Check surroundings for safety.” message is displayed 5. Object 4-253...
Page 412 When Driving Rear View Monitor NOTE The displayable range varies depending on the vehicle and road conditions.  If the camera lens is touched or there is any dirt on it, it could affect the screen  image. Wipe the lens using a soft cloth. The displayable range is limited.
Page 413 When Driving Rear View Monitor ▼ Viewing the Display Predicted vehicle path assist lines display type The projected path guidance mode displays the predicted path of the vehicle after you turn the steering wheel. Use this mode for parking your vehicle in a parking space or garage. a) Projected vehicle path (yellow) These lines are displayed as a reference for the projected path of the vehicle.
Page 414 When Driving Rear View Monitor Fixed assist lines display type Guide lines which indicate the width of the vehicle (yellow) are displayed on the screen as a reference to the approximate width of the vehicle in comparison to the width of the parking space you are about to back into. Use this display view for parking your vehicle in a parking space or garage.
Page 415 When Driving Rear View Monitor ▼ Rear View Monitor Operation The operation of the rear view monitor when reversing the vehicle varies depending on the traffic, road, and vehicle conditions. The amount of steering and the timing also varies depending on conditions, so conﬁrm the surrounding conditions directly with your eyes and steer the vehicle in accordance with the conditions.
Page 416 When Driving Rear View Monitor 2. Before backing the vehicle into the parking space, turn the steering wheel while referring to the projected vehicle path display so that the vehicle enters the centre of the parking space. 1. (Display condition) 2.
Page 417 When Driving Rear View Monitor 3. After your vehicle begins entering the parking space, continue backing up slowly so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal. 1.
Page 418 When Driving Rear View Monitor 4. Continue to adjust the steering wheel until the vehicle width guide lines are parallel to the left and right sides of the parking space. 5. Once they are parallel, straighten the wheels and back your vehicle slowly into the parking space.
Page 419 When Driving Rear View Monitor When parking in a space with a division line on only one side of the parking space,  the division line and the vehicle width guide line appear aligned in the monitor, but they may not actually be aligned on the ground. Fixed assist lines display type NOTE Images displayed on the monitor from the rear view parking camera are reversed...
Page 420 When Driving Rear View Monitor 2. Conﬁrming the surrounding conditions, reverse the vehicle. 1. (Display condition) 2. (Vehicle condition) 3. After your vehicle begins entering the parking space, continue backing up slowly so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal.
Page 421 When Driving Rear View Monitor 5. Once they are parallel, straighten the wheels and back your vehicle slowly into the parking space. Continue checking the vehicle's surroundings and then stop the vehicle in the best possible position. (If the parking space has division lines, check whether the vehicle width guide lines are parallel to them.) 1.
Page 422 When Driving Rear View Monitor When parking in a space with a division line on only one side of the parking space,  the division line and the vehicle width guide line appear aligned in the monitor, but they may not actually be aligned on the ground. ▼...
Page 423 When Driving Rear View Monitor When there is a steep grade behind the vehicle When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the screen appears farther (downgrade: closer) than the actual distance. 1. Appears farther than actual distance 2.
Page 424 When Driving Rear View Monitor (Predicted vehicle path assist lines display type) When reversing near a three-dimensional object When reversing near an overhanging object, the vehicle may hit the object even if the anticipated course line does not contact the object on the screen. The position of the object displayed on the screen is different from the actual position because the anticipated course lines on the screen are displayed based on a horizontal road surface.
Page 425: Parking Sensor System
When Driving Parking Sensor System Parking Sensor System ▼ Parking Sensor System The parking sensors use ultrasonic sensors which detect obstructions around the vehicle when the vehicle is driven at low speeds, such as during garage or parallel parking, and a buzzer sound and detection indicator notify the driver of the approximate distance from the vehicle to the surrounding obstruction.
Page 426 Always have the system inspected at an expert repairer (we recommend an  Authorised Mazda Repairer) if any shock is applied to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect obstructions. The system may have a malfunction if the indicator light does not turn on even ...
Page 427 When installing a trailer hitch, consult an expert repairer (we recommend an  Authorised Mazda Repairer). If a Mazda genuine trailer hitch is used, the rear side of the parking sensor system  is automatically turned off. ▼ Sensor Detection Range The sensors detect obstructions within the following range.
Page 428 When Driving Parking Sensor System Distance between vehicle and obstruc- Display tion Without 360° view monitor Rear ultrasonic sen- Front ultrasonic sor/Rear corner ul- Without front ul- With front ultra- With 360° view sensor /Front cor- trasonic sensor/ trasonic sensor sonic sensor and monitor ner ultrasonic sen-...
Page 429 When Driving Parking Sensor System Distance between vehicle and obstruc- Display tion Without 360° view monitor Rear ultrasonic sen- Front ultrasonic sor/Rear corner ul- Without front ul- With front ultra- With 360° view sensor /Front cor- trasonic sensor/ trasonic sensor sonic sensor and monitor ner ultrasonic sen-...
Page 430 1. Front ultrasonic sensor gauge between display and non-display. 2. Right front corner ultrasonic sensor Refer to the Settings section in the gauge Mazda Connect Owner's Manual. 3. Right rear corner ultrasonic sensor System problem notiﬁcation gauge/Right rear side ultrasonic sensor gauge The indication displays if the system 4.
Page 431 When Driving Parking Sensor System Without 360°view monitor With 360°view monitor Check the reason for the indication displaying on the centre display or multi-information display. Refer to If a Warning Light Turns On or Flashes on page 7-54. 4-273...
Page 432 When Driving Parking Sensor System ▼ Parking Sensor Warning Beep Informs the driver of the approximate distance from the vehicle to the obstruction using warning beeps depending on the distance. If multiple obstructions are detected at the same time, warning beeps are activated according to the distance to the nearest obstruction.
Page 433 When Driving Parking Sensor System Distance between vehicle and obstruction Distance De- Beeper sound tection area Front ultrasonic sensor Rear ultrasonic sensor Within approx. 35.0 cm (13.7 Within approx. 35.0 cm (13.7 Continuous Close distance sound The rate at which the intermittent sound beeps increases as the vehicle approaches the obstruction. Front corner ultrasonic sensor , Rear corner/Rear side ultrasonic sensor...
Page 434 The sound volume (each of front and rear) can be changed.  Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ When Warning Indicator/Beep is Activated The system notiﬁes the driver of an abnormality by activating the beep sound and the indicator light.
Page 435 Accessory Sockets....5-37 Fully Automatic Type....5-9 Cup Holder......5-38 Bottle Holder.......5-39 Assist Grips......5-39 Mazda Connect...... 5-14 Rear Coat Hooks....5-40 What is Mazda Connect ?..5-14 Storage Compartments..5-40 Mazda Connect Basic Removable Ashtray ..... 5-43 Operations......5-18 *Some models.
Page 436: Interior Features
 For details, consult an expert repairer The airﬂow amount may decrease (we recommend an Authorised slightly while the i-stop function is Mazda Repairer). operating. Clear all obstructions such as leaves,  snow and ice from the bonnet and the air inlet in the cowl grille to improve the system efficiency.
Page 437 Interior Features Air-Conditioning System Airﬂow direction adjustment Vent Operation ▼ Adjusting the Vents Directing airﬂow To adjust the direction of airﬂow, move the adjustment knob. NOTE When using the air conditioner  1. Knob under humid ambient temperature conditions, the system may blow fog from the vents.
Page 438 Interior Features Air-Conditioning System ▼ Selecting the Airﬂow Mode Rear Vents Air vent open/close Instrument panel Vents 1. Dial 2. Open 1. With rear vents 3. Close Instrument panel and Floor Vents Airﬂow direction adjustment 1. Knob 1. With rear vents Floor Vents 1.
Page 439 Interior Features Air-Conditioning System Defroster and Floor Vents Manual Type ▼ Manual Type 1. With rear vents 1. A/C switch 2. Mode selector switch Defroster Vents 3. Air intake selector switch 4. Fan control dial 5. Rear window defogger switch 6.
Page 440 Interior Features Air-Conditioning System A/C switch WARNING Press the A/C switch to turn the air conditioner on. The indicator light on Do not use the position (indicator the switch will illuminate when the fan light turns on) in cold or rainy control dial is in any position except weather: OFF.
Page 441 Interior Features Air-Conditioning System NOTE NOTE If the windscreen fogs up easily, press When maximum cooling is desired,   set the temperature control dial to switch. the extreme cold position and set If cooler air is desired at face level, ...
Page 442 Interior Features Air-Conditioning System ▼ Windscreen Defrosting and With the switch, the outside air  Defogging position is automatically selected to defrost the windscreen. The air 1. Press the switch. intake selector cannot be changed to 2. Set the temperature control dial to the recirculated air position.
Page 443 Interior Features Air-Conditioning System Fully Automatic Type ▼ Fully Automatic Type Air-conditioning system information is displayed on the display. 1. Driver temperature control dial 2. AUTO switch 3. Temperature setting display (driver’s side) 4. Air intake display 5. Airﬂow display 6.
Page 444 Interior Features Air-Conditioning System NOTE NOTE AUTO switch indicator light The air-conditioning system changes  When the AUTO switch indicator to the individual operation mode  light is on, it indicates auto (SYNC switch indicator light turns operation, and the system will off) by turning the front passenger function automatically.
Page 445 Interior Features Air-Conditioning System A/C switch WARNING Pressing the A/C switch while the AUTO switch is turned on will turn off Do not recirculate the air in the cabin the air conditioner (cooling/ during cold or rainy weather: dehumidifying functions). Recirculating the air in the cabin during The on/off of the air conditioner cold and rainy weather is dangerous as...
Page 446 Interior Features Air-Conditioning System ▼ Operation of Automatic Air ▼ Windscreen Defrosting and Conditioner Defogging 1. Press the AUTO switch. Selection of Press the windscreen defroster switch. the airﬂow mode, air intake In this position, the outside air position selector and amount of airﬂow will is automatically selected, and the air be automatically controlled.
Page 447 Interior Features Air-Conditioning System ▼ Sunlight/Temperature Sensor The air-conditioning system measures inside and outside temperatures, humidity and sunlight using the sunlight/temperature sensor. It sets temperatures inside the cabin accordingly. CAUTION Do not obstruct both sensors, otherwise the air-conditioning system will not operate properly. Sunlight sensor 1.
Page 448 What is Mazda Connect ? ▼ What is Mazda Connect ? This manual only indicates a part of the information for Mazda Connect. For details, check the Web owner's manual at the Mazda site for each country and region. 1. Radio ®...
Page 449 Bluetooth USB1 Audio/USB2 Audio USB1 Video/USB2 Video Disc /DVD Displays text messages received by the mobile device paired to Mazda Notiﬁcations Connect and notiﬁcations from the vehicle. By connecting your mobile device, such as a Smartphone, to Mazda ® Communication...
Page 450 Interior Features Mazda Connect Menu Explanation You can change the settings for the Mazda Connect screen, sound set- tings, and the vehicle functions. In-Vehicle Displays: Conﬁgures settings and content for all in-vehicle displays. Sound Settings: Conﬁgures the in-vehicle listening experience.
Page 451 NOTE Do not use Mazda Connect for a long time with the engine stopped. Otherwise,  the battery power could be depleted. If a mobile phone or CB radio is used in or near the vehicle, it could cause noise to ...
Page 452 Interior Features Mazda Connect Mazda Connect Basic Operations ▼ Mazda Connect Basic Operations NOTE The explanation of functions described in this manual may differ from the actual operation, and the shapes of screens and buttons and the letters and characters displayed may also differ from the actual appearance.
Page 453 Interior Features Mazda Connect The shape of the switches varies depending on the vehicle model. Item Explanation Commander knob (selection): Rotate or slide the commander knob to highlight/select the on-screen functions you want to use. Commander knob (select): Depress the commander knob to select the desired on-screen function...
Page 454 Press the volume knob to mute the audio. Press the knob again to cancel. Power off Press and hold the volume knob to turn the Mazda Connect power off. NOTE If you press the volume knob to mute an audio source which can be paused, such ®...
Page 455 Displays the Apple CarPlay or Android Auto™ home screen. (While Apple CarPlay or Android Auto™ is connected) Press and hold while the Mazda Connect screen is displayed to switch the screen from Mazda Connect to Apple CarPlay or Mazda Connect to Android Auto™.
Page 456 Interior Features Mazda Connect ▼ Audio Remote Control Switch Operation The audio remote control switch is on the left side of the steering wheel. You can operate basic audio functions, pick up/hang up the phone, or activate voice control using the switch.
Page 457 Interior Features Mazda Connect Item Explanation Press the ( ) to cue to the beginning of the next song and press the ( to cue to the beginning of the previous song. (The order of the songs is in the order of the selected ﬁle list.)
Page 458 While Apple CarPlay or Android Auto™ is connected, Siri or Android Auto™ voice recognition is activated. At this time Mazda Connect voice recognition is not activated. Commands usable at any time “Help” - Can be used to check for usable voice commands.
Page 459 When the Barge-In setting is on, voice commands can be made even while the  voice guidance is being announced. For details on Barge-In, refer to the Settings section in the Mazda Connect Owner's Manual. For details on voice commands which can be used on the navigation screen, refer ...
Page 460 Interior Features Mazda Connect It is not necessary to face the microphone or approach it. Speak the voice  commands while maintaining a safe driving position. Close the windows and the sunroof to reduce loud noises from outside the vehicle ...
Page 461 Interior Features Mazda Connect Radio Tune to {Frequency} AM  Tune to {Frequency} FM  Tune to DAB {DAB Station Name}  Source Change Source (You can also use “Change Source to USB” and “USB”  Audio OFF (You can also use “Change Source to Audio OFF”.) ...
Page 462 TECHNOLOGY OR GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS OBSOLETE AND/OR UNUSABLE. TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL MAZDA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY, OR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT...
Page 463 OTHER CONTENT PROVIDED BY GOOGLE, ITS AFFILIATES, OR THIRD PARTY PROVIDERS; MAZDA DOES NOT GUARANTEE AGAINST LOSS OF APPLICATION DATA, WHICH MAY BE LOST AT ANY TIME; MAZDA DOES NOT GUARANTEE THAT THE APPLICATION OR ANY SERVICES PROVIDED THROUGH THEM WILL BE PROVIDED AT ALL TIMES OR THAT ANY OR ALL SERVICES WILL BE AVAILABLE AT ANY PARTICULAR TIME OR LOCATION.
Page 464 TECHNOLOGY OR GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS OBSOLETE AND/OR UNUSABLE. TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL MAZDA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY, OR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT...
Page 465 Interior Features Mazda Connect iPhone 5c iPhone 5 iPhone 4s iPod touch (6th generation) iPod touch (5th generation) iPod nano (7th generation) Google, Android, Android Auto and other related marks are trademarks of Google  LLC. AudioPilot is a registered trademark of Bose Corporation.
Page 466 Interior Features Mazda Connect Gracenote, the Gracenote logo and logotype are either a registered trademark or a  trademark of Gracenote, Inc. in the United States and/or other countries. Regarding the license for the audio ampliﬁer (except vehicles with Bose audio)
Page 467 Interior Features Interior Equipment NOTE Sunvisors If a vanity mirror light is left on with the ignition switched OFF, the light is ▼ Sunvisors turned off automatically to prevent the battery from being discharged. When you need a sunvisor, lower it for use in front or swing it to the side.
Page 468 Interior Features Interior Equipment Interior Lights Switch Overhead Lights The door interlock can be switch- ▼ Interior Lights ed ON/OFF. When the door interlock is OFF, NOTE the indicator light in the switch Do not leave the lights on for long turns on.
Page 469 Interior Features Interior Equipment Rear Rear When the overhead light ON/OFF switch ( ) is off, press the switch to illuminate the rear map lights, and then press the switch again to turn them off. NOTE The rear overhead light also turn on and off when the front overhead light switch is operated.
Page 470 Luggage compartment light entry system can be changed. (Hatchback) Refer to the Settings section in the Mazda Connect Owner's Manual. The luggage compartment light is on The illuminated entry system does when the liftgate is open and off when ...
Page 471 ▼ Accessory Sockets which could cause the warning light Only use genuine Mazda accessories to illuminate. Disconnect the or the equivalent requiring no greater connected device and make sure than 120 W (DC 12 V, 10 A).
Page 472 Interior Features Interior Equipment Type B Cup Holder To use the cup holder, push the release ▼ Cup Holder button. WARNING Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous.
Page 473 Interior Features Interior Equipment Bottle Holder Assist Grips ▼ Bottle Holder ▼ Assist Grips Bottle holders are on the inside of the WARNING doors. Never hang heavy or sharp objects on the assist grips and coat hooks: Hanging heavy or sharp-ended objects such as a coat hanger from the assist grips or coat hooks is dangerous as they can ﬂy off and hit an occupant in...
Page 474 Interior Features Interior Equipment Rear Coat Hooks Storage Compartments ▼ Rear Coat Hooks ▼ Storage Compartments WARNING WARNING Never hang heavy or sharp objects on Keep storage boxes closed when the assist grips and coat hooks: driving: Hanging heavy or sharp-ended objects Driving with the storage boxes open is such as a coat hanger from the assist dangerous.
Page 475 Interior Features Interior Equipment ▼ Overhead Console ▼ Glove Compartment To open the glove compartment, pull This console box is designed to store the latch toward you. eyeglasses or other accessories. Push and release to open. To close the glove compartment, ﬁrmly press in the centre of the glove ▼...
Page 476 Interior Features Interior Equipment ▼ Luggage Compartment To open the lid, pull the knob, slide the lid rearward, and then lift up the Cargo Sub-Compartment lid. (Saloon) Lift the boot mat. CAUTION Do not put your hands or ﬁngers 1. Boot mat around the moving parts of the lid (Hatchback) when using the lid.
Page 477 Interior Features Interior Equipment NOTE Removable Ashtray Loading golf bags (Saloon) (Some golf bags may not ﬁt using the ▼ Removable Ashtray following methods depending on their The removable ashtray can be ﬁxed sizes.) and used in either of the front cup Up to two golf bags can be carried in holders.
Page 478 MEMO 5-44...
Page 479 Maintenance and Care How to keep your Mazda in top condition. Essential Information....6-2 Appearance Care....6-57 Introduction......6-2 Exterior Care....... 6-57 Interior Care......6-63 Scheduled Maintenance.... 6-3 Scheduled Maintenance..6-3 Owner Maintenance....6-17 Owner Maintenance Precautions......6-17 Bonnet........6-18 Engine Compartment Overview......6-20 Engine Oil......
Page 480: Maintenance And Care
(we recommend an Authorised Mazda Repairer). Authorised Mazda technicians and genuine Mazda parts are dedicated to your vehicle. Without this expertise and the parts that have been designed and made especially for your Mazda, inadequate, incomplete, and insufficient servicing may result in 1.
Page 481 Authorised Mazda Repairer). ▼ Europe Vehicles utilizing the vehicle status monitor feature (My Mazda Service): The vehicle status monitor feature alerts you of maintenance needs by turning on the wrench indicator light or displaying a message in the instrument panel, or both.
Page 482 Body condition (for rust, corrosion and per- foration) Cabin air ﬁlter (if installed) *12*13 Tyre inﬂation pressure and tyre wear Emergency ﬂat tyre repair kit (if installed) Self-test with Mazda Modu- lar Diagnostic System Ukraine *15*16 (M-MDS) SKYACTIV-G & SKYACTIV-X...
Page 483 Maintenance and Care Scheduled Maintenance Chart symbols: I: Inspect: Inspect and clean, repair, adjust, ﬁll up, or replace if necessary. C: Clean T: Tighten R: Replace Remarks: Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench indicator light display.
Page 484 Replace the tyre repair ﬂuid bottle with new one before the expiration date. 15 If DTC P1200 is stored, clean the fuel system by Mazda genuine deposit cleaner. If the required tool (M-MDS) is not available, clean the fuel system by Mazda genuine deposit cleaner without performing self-test.
Page 485 Manually set Next Service Distance of Vehicle Status Monitor to 10,000 km or short- er if the vehicle is driven primarily under any of the following conditions: Refer to the Information section in the Mazda Connect Owner's Manual about the manual setting procedure.
Page 486 Maintenance and Care Scheduled Maintenance Maintenance Item 1st 2nd 3rd 4th 5th 6th 7th 8th 9th 10th 11th 12th Steering operation and linkages Brake ﬂuid Cabin air ﬁlter (if installed) Hoses and tubes for emission Driveshaft dust boots Air ﬁlter Exhaust system and heat shields Manual transmission oil Replace every 100,000 km or 5 years.
Page 487 Manually set Next Service Distance and Date of Vehicle Status Monitor to 7,500 km and 6 months if the vehicle is driven primarily under any of the following conditions: Refer to the Information section in the Mazda Connect Owner's Manual about the manual setting procedure.
Page 488 Maintenance and Care Scheduled Maintenance 1. The vehicle is idled for long periods or driven at low speeds, such as with police cars, taxis, or driver's education school car. 2. Driving under dusty conditions. 3. Driving for long periods in cold temperatures or driving regularly for short distan- ces only.
Page 489 Maintenance and Care Scheduled Maintenance Maintenance item 1st 2nd 3rd 4th 5th 6th 7th 8th 9th 10th 11th 12th Except below Replace every 120,000 km. countries Fuel ﬁlter Azerbaijan/ Replace every 60,000 km. Armenia Replace at ﬁrst 195,000 km or 120 months; after that, Engine coolant every 90,000 km or 60 months.
Page 490 (50 % of maximum mileage is recommended) if the vehicle is driven primarily under any of the following conditions: Refer to the Information section in the Mazda Connect Owner's Manual about the manual setting proce- dure. 1. The vehicle is idled for long periods or driven at low speeds, such as with police cars, taxis, or driver's education school car.
Page 491 Maintenance and Care Scheduled Maintenance 3. Driving for long periods in cold temperatures or driving regularly for short distan- ces only. 4. Driving under extremely high temperature conditions. 5. Driving continuously in mountainous regions. Maintenance item 1st 2nd 3rd 4th 5th 6th 7th 8th 9th SKYACTIV-G 1.5, SKYACTIV-G 2.0, SKYACTIV-G 2.5, AND SKYACTIV-X 2.0 Engine oil &...
Page 492 Maintenance and Care Scheduled Maintenance Maintenance item 1st 2nd 3rd 4th 5th 6th 7th 8th 9th Brake lines, hoses and connec- tions Steering operation and linkages Front and rear suspension, ball joints and wheel bearing axial play Bolts and nuts on chassis and body Body condition (for rust, corro- sion and perforation)
Page 493 Using non-genuine deposit cleaner would cause an internal failure in the fuel system. 13 If the vehicle is driven primarily under any of the following conditions, perform "Self-test with Mazda Modular Diagnostic System (M-MDS)" at every 5,000 km.
Page 494 Maintenance and Care Scheduled Maintenance SKYACTIV-G: Algeria, Angola, Antigua, Aruba, Bahrain, Barbados, Bermuda, Bolivia, Botswana, Brunei, Burundi, Cambodia, Cameroon, Colombia, Common Wealth of Dominica, Curacao, Ecuador, El Salvador, Gabon, Ghana, Grenada, Haiti, Honduras, Indonesia, Iraq, Ivory coast, Jordan, Kenya, Kuwait, Laos, Lesotho, Libya, Macau, Madagascar, Malaysia, Marshall islands, Mongolia, Morocco, Myanmar, Namibia, Nicaragua, Nigeria, Oman, Peru, Qatar, Seychelles, South Africa, Srilanka, St.
Page 495 For details, read the before getting near the engine or separate Mazda Warranty statement cooling fan which may turn on provided with the vehicle. If you are unexpectedly:...
Page 496 Maintenance and Care Owner Maintenance Bonnet ▼ Bonnet Pull over to a safe location, then switch the ignition off and make sure the fan is not running before WARNING attempting to work near the cooling fan: Always check that the bonnet is Working near the cooling fan when it is closed and securely locked: running is dangerous.
Page 497 Maintenance and Care Owner Maintenance 3. Grasp the support rod in the 2. Lift the bonnet, grasp the padded padded area and secure it in the area on the support rod, and secure support rod hole indicated by the the support rod in the clip. Verify arrow to hold the bonnet open.
Page 498 Maintenance and Care Owner Maintenance Engine Compartment Overview ▼ Engine Compartment Overview SKYACTIV-G 1.5, SKYACTIV-G 2.0, and SKYACTIV-G 2.5 1. Engine coolant reservoir 2. Engine oil dipstick 3. Brake/Clutch ﬂuid reservoir 4. Battery 5. Fuse block 6. Cooling system cap 7.
Page 499 Maintenance and Care Owner Maintenance SKYACTIV-X 2.0 1. Engine oil dipstick 2. Engine oil-ﬁller cap 3. Engine cover 4. Brake/Clutch ﬂuid reservoir 5. Battery 6. Fuse block 7. Cooling system cap 8. Engine coolant reservoir 9. Windscreen washer ﬂuid reservoir 6-21...
Page 500 Maintenance and Care Owner Maintenance Opening the engine cover 4. Hook the strap onto the bonnet hook to secure the cover. 1. Turn the engine cover knob to unlock. Closing the engine cover 2. Lift up the engine cover. 1. Unhook the strap from the bonnet hook.
Page 501 Maintenance and Care Owner Maintenance 3. Close the engine cover, turn the 4. Make sure that the engine cover is knob, and then lock the cover. securely closed. 6-23...
Page 502 Maintenance and Care Owner Maintenance SKYACTIV-D 1.8 1. Engine oil-ﬁller cap 2. Engine oil dipstick 3. Brake/Clutch ﬂuid reservoir 4. Battery 5. Fuse block 6. Cooling system cap 7. Engine coolant reservoir 8. Windscreen washer ﬂuid reservoir 6-24...
Page 503 Do not use oils which do not meet the following speciﬁcations or requirements. Use of unsuitable oil may lead to engine damage which is not covered by the Mazda Warranty. SKYACTIV-G 1.5, SKYACTIV-G 2.0, and SKYACTIV-G 2.5...
Page 504 Temperature Range SAE Viscosity Numbers –40 –30 –20 –10 Grade –40 –20 Recommended oils Mazda Original Oil Supra DPF 0W-30 Mazda Original Oil Ultra DPF 5W-30 Alternative Oil Quality ACEA C3 (Except Europe) (Except Europe and Taiwan) Temperature Range SAE Viscosity Numbers –40...
Page 505 Maintenance and Care Owner Maintenance Engine oil viscosity, or thickness, has an effect on fuel economy and cold-weather operation (starting and oil ﬂow). Low-viscosity engine oils can provide improved fuel economy and cold-weather performance. When choosing an oil, consider the temperature range your vehicle will operate in before the next oil change.
Page 506 Otherwise the wrench indicator light or engine oil warning light may turn on. To reset the engine control unit, consult an expert repairer (we recommend an Authorised Mazda Repairer) or refer to the vehicle status monitor section in the Mazda Connect Owner's Manual.
Page 507 Maintenance and Care Owner Maintenance SKYACTIV-D 1.8 Engine Coolant ▼ Inspecting Coolant Level WARNING Do not use a match or live ﬂame in the engine compartment. DO NOT ADD COOLANT WHEN THE ENGINE IS HOT: A hot engine is dangerous. If the engine has been running, parts of the engine compartment can become very hot.
Page 508 Consult an expert If the “FL22” mark is shown on or repairer (we recommend an near the cooling system cap, use of Authorised Mazda Repairer) for FL-22 is recommended when details. replacing engine coolant. Using Inspect the antifreeze protection and...
Page 509 If it is excessively low, With M Hybrid have the brake/clutch system inspected by an expert repairer (we recommend an Authorised Mazda Repairer). Left-hand drive model Without M Hybrid 6-31...
Page 510 Maintenance and Care Owner Maintenance Window and Headlight Body Lubrication Washer Fluid ▼ Body Lubrication ▼ Inspecting Washer Fluid Level All moving points of the body, such as door and bonnet hinges and locks, should be lubricated each time the WARNING engine oil is changed.
Page 511 Maintenance and Care Owner Maintenance Contamination of either the Wiper Blades windscreen or the blades with foreign matter can reduce wiper effectiveness. ▼ Wiper Blades Common sources are insects, tree sap, and hot wax treatments used by some CAUTION commercial car washes. Hot waxes applied by automatic car If the blades are not wiping properly, washers have been known to affect...
Page 512  could damage the wiper arm and blades. If they are replaced with blade, and may scratch or crack the wiper blades other than a Mazda windscreen. genuine product, they may not wipe with the same efficiency as the Replace the wiper blades using the genuine product.
Page 513 Maintenance and Care Owner Maintenance 4. Pull the blade rubber in the 5. Pull the end of the blade rubber direction of the arrow and slide it from the blade holder groove in the to a position where the blade direction of the arrow and remove holder groove can be checked.
Page 514 Maintenance and Care Owner Maintenance 6. Insert the end of the new blade 7. After pulling the blade rubber in the rubber into the groove of the blade direction of the arrow and sliding holder until it contacts the end of the blade rubber to a position to the blade holder.
Page 515 Maintenance and Care Owner Maintenance 11.Move the wipers to their initial CAUTION positions using the following procedure. To prevent damage to the rear a) Make sure that the wipers are set window, do not let the wiper arm on the windscreen. fall on it.
Page 516 Maintenance and Care Owner Maintenance 4. Carefully insert the new blade Battery rubber. Then install the blade assembly in ▼ Battery the reverse order of removal. WARNING Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery:...
Page 517 Maintenance and Care Owner Maintenance NOTE Before performing battery Always keep batteries out of maintenance, remove the battery the reach of children: cover. Allowing children to play near batteries is dangerous. Battery ﬂuid could cause serious injuries if it gets in the eyes or on the skin.
Page 518 Examine the speciﬁc gravity of the ▼ Battery Replacement electrolyte with a hydrometer, Contact an expert repairer (we especially during cold weather. If it is recommend an Authorised Mazda low, recharge the battery. Repairer) for a battery replacement purchase. 6-40...
Page 519 Replace with a new battery before the Replacing the battery at an expert transmitter becomes unusable. repairer (we recommend an Authorised Mazda Repairer) is CAUTION recommended. If replacing the battery Make sure the battery is installed by yourself, follow the instruction.
Page 520 Maintenance and Care Owner Maintenance 3. Insert a tape-wrapped ﬂathead 7. Insert a new battery into the screwdriver into the gap and slide it transmitter so that the positive pole in the direction of the arrow. is facing up. 8. Install the cap. 4.
Page 521 WARNING Refer to Tyres on page 9-12. Use only a Mazda-genuine tyre valve Using Different Tyre Types: cap: Driving your vehicle with different Use of a non-genuine part is types of tyres is dangerous. It could dangerous as the correct tyre air cause poor handling and poor braking;...
Page 522 Have an expert repairer (we recommend an Authorised Mazda Repairer) perform tyre rotation. 1. Forward Do not include (TEMPORARY USE ONLY) spare tyre in rotation.
Page 523 Mazda strongly recommends that you replace all four tyres at the Refer to Tyre on page 9-12. same time.
Page 524  tyre and rim. (we recommend an Authorised The temporary spare tyre has a tread Mazda Repairer). life of less than 5,000 km (3,000 miles). The tread life may be shorter Proper tyre balancing provides the best depending on driving conditions.
Page 525 Maintenance and Care Owner Maintenance Rear Light Bulbs Saloon ▼ Light Bulbs Front Type A 1. Boot light 2. High-mount brake light 3. Rear overhead light 4. Brake lights/Tail lights 5. Rear direction indicator lights 1. Vanity mirror lights 6. Tail lights 2.
Page 526 The LED bulb has to be replaced with Front overhead lights/front map  the unit. If a replacement is necessary, lights, rear overhead light, and luggage compartment light consult an expert repairer (we Refer to Interior Lights on page recommend an Authorised Mazda 5-34. Repairer). 6-48...
Page 527 Maintenance and Care Owner Maintenance Bulb type 5. Turn the screw anticlockwise and remove it, and then partially peel Running lights/Position lights (Type B) back the mudguard. 1. Make sure the ignition is switched off, and the headlight switch is off. 2.
Page 528 If a replacement is necessary, using that system and consult an expert consult an expert repairer (we repairer (we recommend an recommend an Authorised Mazda Authorised Mazda Repairer) as soon as Repairer). possible. Bulb type ▼ Fuse Replacement...
Page 529 Always replace a fuse with a compartment. genuine Mazda fuse or equivalent of the same rating. Otherwise, you may damage the electric system. 6. Reinstall the cover and make sure that it is securely installed.
Page 530 Have an expert repairer electrical shock or a short circuit (we recommend an Authorised resulting in a ﬁre. Mazda Repairer) perform the 4. Reinstall the cover and make sure replacement: that it is securely installed. ▼ Fuse Panel Description...
Page 531 Maintenance and Care Owner Maintenance FUSE RAT- PROTECTED COMPONENT 20 A Windscreen wiper de-icer 30 A Engine control system 20 A Injector 20 A S-VT 40 A Engine control system 20 A S-VT 15 A Fuel warmer 20 A Fuel pump 15 A Engine control system 15 A...
Page 532 Maintenance and Care Owner Maintenance FUSE RAT- PROTECTED COMPONENT ― ― ― ― ― ― ABS, Dynamic stability control system ― ― 40 A Rear window defogger 50 A For protection of various circuits ― ― 40 A Air conditioner ―...
Page 533 Maintenance and Care Owner Maintenance Fuse block (Left side) FUSE RAT- PROTECTED COMPONENT ― ― ― ― ― ― 15 A Power door locks (Driver) 15 A Power door locks (Passenger) ― ― ― ― ― ― 30 A Power windows (Driver) 30 A Power windows (Passenger) 30 A...
Page 534 Maintenance and Care Owner Maintenance FUSE RAT- PROTECTED COMPONENT 15 A Illumination 10 A Brake lights 10 A Reverse lights 10 A Rear direction indicator lights 10 A Tail lights 10 A Tail lights 7.5 A Electric steering lock ― ―...
Page 535 Industrial pollutants and vehicle Prevention emissions drift into the air and mix It is necessary to have your Mazda with rain or dew to form acids. These washed and waxed to preserve its acids can settle on a vehicle's ﬁnish. As ﬁnish according to the instructions in...
Page 536 Maintenance and Care Appearance Care Water Marks Chipped paint can lead to rust  forming on your Mazda. Before this Occurrence happens, repair the damage by using Mazda touch-up paint according to Rain, fog, dew, and even tap water can the instructions in this section.
Page 537 If you are going to clean the windscreen, be sure the wipers are NOTE turned off completely (when it is Mazda is not responsible for  most likely that the engine is left scratches caused by automatic car running) this is particularly important washes or improper washing.
Page 538 Maintenance and Care Appearance Care WARNING CAUTION Do not use steel wool, abrasive Dry off brakes that have become wet cleaners, or strong detergents by driving slowly, releasing the containing highly alkaline or caustic accelerator pedal and lightly applying agents on chrome-plated or the brakes several times until the anodised aluminium parts.
Page 539 High water temperature and high stone chipping, damage during parking water pressure car washers are etc., by using Mazda touch-up paint available depending on the type of car before rust begins to form. First, wash machine. If the car washer nozzle...
Page 540 Should repairs be necessary, consult an exposed to any of these chemical expert repairer (we recommend an agents, ﬂush with water immediately. Authorised Mazda Repairer). They are If plastic parts such as the bumpers well informed on how repairs should ...
Page 541 Maintenance and Care Appearance Care High water temperature and high Interior Care  water pressure car washers are available depending on the type of ▼ Interior Care high pressure car washer device. If the car washer nozzle is put too WARNING close to the vehicle or aimed at one area for an extended period of time,...
Page 542 (we recommend an 1. Remove dust and sand using a Authorised Mazda Repairer): vacuum cleaner. If a seat belt is used under such a 2. Wipe off the soiled area with a soft...
Page 543 Maintenance and Care Appearance Care ▼ Active Driving Display If the leather upholstery gets wet,  promptly remove moisture with a dry Maintenance cloth. Remaining moisture on the The dust-proof sheet has a coating. surface may cause deterioration such When cleaning, do not use a hard or as hardening and shrinkage.
Page 544 Maintenance and Care Appearance Care CAUTION Do not scrape or scratch the inside of the window glass. It could damage the thermal ﬁlaments and the aerial lines. When washing the inside of the window glass, use a soft cloth dampened in lukewarm water, gently wiping the thermal ﬁlaments and the aerial lines.
Page 545 Emergency call system....7-2 Overheating......7-48 Overheating......7-48 Emergency call system ... 7-2 Emergency Towing....7-50 Mazda ERA-GLONASS..... 7-12 Towing Description....7-50 Mazda ERA-GLONASS ..7-12 Towing Hooks......7-51 Parking in an Emergency..7-23 Warning/Indicator Lights and Parking in an Emergency..7-23 Warning Sounds.....
Page 546: If Trouble Arises
If Trouble Arises Emergency call system Emergency call system ▼ Emergency call system When an emergency situation such as an accident or sudden illness occurs, the Emergency call system dials the call centre automatically or the user can make a call to the call centre manually to enable a voice call.
Page 547 Thereafter, if the indicator light remains turned on in red, the system will not operate normally in an emergency. Have the vehicle inspected at an Authorised Mazda Repairer as soon as possible. INFORMATION ON DATA PROCESSING Any processing of personal data through the 112-based Emergency call system ...
Page 548 (For Europe) Contact service responsible for handling access requests: Please contact your local Mazda Organisation for data protection requests. Contact details related thereto are listed in the Privacy Statement which you ﬁnd on your country-speciﬁc webpage.
Page 549 If Trouble Arises Emergency call system ▼ Flow of Emergency call system Call centre/ Emergency call system Police/ User status Emergency Automatic call Manual call services Emergency call switch Automatic call made Emergency situation arises due to vehicle such as collision or sudden receiving impact of Manual call made illness...
Page 550 (red) in the Emergency call switch turns on to notify the driver. Have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer). Refer to Indicator light/Beep sound on page 7-10.
Page 551 A voice call with an operator may not be possible if the speaker or microphone is  broken. If the speaker or microphone is broken, always have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer). The Emergency call system may not operate normally outside of the following ...
Page 552 If Trouble Arises Emergency call system 2. The indicator light (green) on the Emergency call switch ﬂashes slowly (0.5 second intervals) and the call is made to the call centre. 1. Green 3. When the connection is established with the call centre, the indicator light (green) ﬂashes somewhat quickly (0.3 second intervals) and the transmission of the vehicle information begins.
Page 553 If Trouble Arises Emergency call system NOTE Only make calls manually for conditions requiring urgent treatment such as illness  or serious injury. When making emergency calls manually, stop the vehicle in a safe location before  making the call. The call centre will end an emergency call.
Page 554 If Trouble Arises Emergency call system 6. If the connection fails, the indicator light (red) turns on and the indicator light (green) ﬂashes quickly (0.15 second intervals), and the beep sounds simultaneously. Make a manual emergency call again. 1. Red (Turns on) 2.
Page 555 If Trouble Arises Emergency call system Indicator light Beep sound Status On/ﬂashing conditions status Green Flash interval A system malfunction is  detected. The remaining power of  the built-in battery is low. CAUTION 3 beeps ― Malfunction Turns off Turns on (Slow intermit- If the indicator light (red) re-...
Page 556 ▼ Mazda ERA-GLONASS When an emergency situation such as an accident or sudden illness occurs, the Mazda ERA-GLONASS dials the call centre automatically or the user can make a call to the call centre manually to enable a voice call.
Page 557 If Trouble Arises Mazda ERA-GLONASS ▼ Component Parts of Mazda 2. Microphone, Speaker 3. Aerial ERA-GLONASS WARNING When using the Mazda ERA-GLONASS, keep medical devices such as an implanted heart pacemaker or deﬁbrillator about 22 cm (8.7 in) or more away from the...
Page 558 If Trouble Arises Mazda ERA-GLONASS ▼ Flow of Mazda ERA-GLONASS Call centre/ Mazda ERA-GLONASS Police/ User status Emergency Automatic call Manual call services Emergency call system switch Automatic call made Emergency situation arises due to vehicle such as collision or sudden...
Page 559 Do not disassemble the Mazda ERA-GLONASS. Otherwise, it could become damaged and may not function in an emergency. The Mazda ERA-GLONASS has a special built-in battery so that it can operate even if the power supply from the vehicle is cut such as in an accident.
Page 560 If Trouble Arises Mazda ERA-GLONASS If the Mazda ERA-GLONASS operates while you are making a call with your  ® mobile phone using Bluetooth Hands-Free, the call may be interrupted. ® It may not be possible to receive a call using the Bluetooth Hands-Free normally ...
Page 561 If Trouble Arises Mazda ERA-GLONASS 2. The indicator light (green) on the Emergency call switch ﬂashes slowly (0.5 second intervals) and the call is made to the call centre. 1. Green 3. When the connection is established with the call centre, the indicator light (green) ﬂashes somewhat quickly (0.3 second intervals) and the beep sounds...
Page 562 If Trouble Arises Mazda ERA-GLONASS NOTE Only make calls manually for conditions requiring urgent treatment such as illness  or serious injury. When making emergency calls manually, stop the vehicle in a safe location before  making the call. The call centre will end an emergency call. The user cannot end the emergency ...
Page 563 If Trouble Arises Mazda ERA-GLONASS 6. If the connection fails, the indicator light (red) turns on and the indicator light (green) ﬂashes quickly (0.15 second intervals), and the beep sounds simultaneously. Make a manual emergency call again. 1. Red (Turns on) 2.
Page 564 ▼ Test Mode The test mode function makes sure that the Mazda ERA-GLONASS can operate normally. Have your vehicle tested at an Authorised Mazda Repairer when performing the test mode. Method to start test mode Switch the ignition ON while the parking brake is applied, and wait 2 minutes with the vehicle stopped.
Page 565 If Trouble Arises Mazda ERA-GLONASS After that, perform the following procedure. Turn on the hazard warning lights. Within 5 seconds Within 1 second Return the signal lever to off Turn off the hazard warning lights. Within 5 seconds Move the signal lever up to right...
Page 566 If Trouble Arises Mazda ERA-GLONASS 3. Call is placed to call centre 4. Vehicle information is sent 5. Start of voice call 6. Voice guidance from the call centre is played NOTE Communication with the call centre may fail if the reception is poor. Perform the test mode in a location with good reception.
Page 567 If Trouble Arises Parking in an Emergency Parking in an Emergency Roadside Emergency Triangle Retaining Strap ▼ Parking in an Emergency ▼ Roadside Emergency Triangle The hazard warning lights should always be used when you stop on or Retaining Strap near a roadway in an emergency.
Page 568 Your vehicle may or may not be equipped with a spare tyre, jack, wheel brace, and tool bag. For details, consult an Authorised Mazda Repairer. Spare tyre and tools are stored in the locations illustrated in the diagram. 1. Towing eyelet Saloon 2.
Page 569 If Trouble Arises Flat Tyre Hatchback Type C Type A 1. Towing eyelet 2. Wrench 3. Spare tyre hold-down bolt 1. Emergency ﬂat tyre repair kit 4. Screwdriver 2. Towing eyelet 5. Jack lever 3. Jack lever 6. Jack 4. Wheel brace 7.
Page 570 If Trouble Arises Flat Tyre ▼ Jack Type E To remove the jack Saloon 1. Remove the boot mat. 1. Towing eyelet 2. Wrench 3. Spare tyre hold-down bolt 4. Screwdriver 5. Jack lever 2. Remove the cover. 6. Jack 7.
Page 571 If Trouble Arises Flat Tyre Hatchback To secure the jack 1. Remove the luggage mat. Saloon 1. Insert the wing bolt into the jack with the jack screw pointing to the front and turn the wing bolt clockwise to temporarily tighten it. 2.
Page 572 Flat Tyre ▼ Spare Tyre Avoid driving over obstacles. Also, do not drive through an automatic Your Mazda has a temporary spare car wash. This tyre's diameter is tyre. smaller than a conventional tyre, The temporary spare tyre is lighter and...
Page 573 If Trouble Arises Flat Tyre 3. (Vehicles with sub-woofer) NOTE If the spare tyre hold-down bolt Turn the spare tyre hold-down bolt cannot be loosened, hold the edge anticlockwise and remove the of the tyre and turn it anticlockwise sub-woofer and the spare tyre. until the spare tyre hold-down bolt rotates.
Page 574 ▼ Emergency Flat Tyre Repair Kit The emergency ﬂat tyre repair kit included with your Mazda is for a temporary repair of a slightly damaged ﬂat tyre resulting from running over nails or similar sharp objects on the road surface.
Page 575 The emergency ﬂat tyre repair kit  cannot be used in the following cases. Consult an expert repairer (we recommend an Authorised Mazda Repairer). The period of effective use for the  tyre sealant has expired. (The period of effectiveness is indicated on the bottle label.)
Page 576 If Trouble Arises Flat Tyre Type B 6. Remove the cap from the bottle. Screw on the injection hose with the bottle's inner cap left on to break the inner cap. 5. Shake the tyre sealant well. 1. Cap 2. Injection hose 3.
Page 577 The tyre sealant cannot be reused. Store the valve core in a place Purchase a new tyre sealant kit at where it will not get dirty. an Authorised Mazda Repairer. 9. Insert the injection hose into the 12.Reinsert the valve core into the valve.
Page 578 Return the Do not attach the vehicle speed empty tyre sealant bottle to an restriction sticker to the Authorised Mazda Repairer when instrument panel, as it would replacing the tyre. The empty tyre obstruct vision of areas such as...
Page 579 Contact an expert repairer (we switch is off. recommend an Authorised The compressor turns on and off Mazda Repairer). with the push-button switch. If the tyre has been over-inﬂated,  17.Turn the compressor switch on and loosen the screw cap on the inﬂate the tyre carefully to the...
Page 580 Have the tyre sealant replaced at an repeating steps 15 to 21, park the expert repairer (we recommend an vehicle on a level surface off the Authorised Mazda Repairer) before the right-of-way and contact an period of effective use has expired. expert repairer (we recommend an Authorised Mazda Repairer).
Page 581 If Trouble Arises Flat Tyre NOTE Changing a Flat Tyre Make sure the jack is well lubricated (With Spare Tyre) before using it. 1. Park on a hard, level surface off the ▼ Changing a Flat Tyre right-of-way and ﬁrmly set the parking brake.
Page 582 If Trouble Arises Flat Tyre ▼ Removing a Flat Tyre CAUTION Align the notch on the wheel cover WARNING with the valve stem when installing When jacking-up a vehicle, always shift the shift lever to 1st or R position (manual transmission vehicle) or shift the selector lever to P position (automatic transmission vehicle), apply the parking brake, and place...
Page 583 If Trouble Arises Flat Tyre 2. Loosen the wheel nuts by turning 5. Place the jack under the jack-up them anticlockwise one turn each, position closest to the tyre being but do not remove any wheel nuts changed with the jack head until the tyre has been raised off the squarely under the jack-up point.
Page 584 Before removing the wheel nuts, Use only the jack provided with make sure your Mazda is ﬁrmly in your Mazda: position and that it cannot slip or Using a jack that is not designed for move.
Page 585 If Trouble Arises Flat Tyre WARNING WARNING Do not jack up the vehicle higher Make sure the mounting surfaces than is necessary: of the wheel, hub and wheel nuts Jacking up the vehicle higher than is are clean before changing or necessary is dangerous as it could replacing tyres: destabilize the vehicle resulting in...
Page 586 Because the wheel studs and wheel nuts on your Mazda have metric threads, using a non-metric nut is dangerous. On a metric stud, it would not secure the wheel and...
Page 587 If Trouble Arises Battery Runs Out Jump-Starting ▼ Jump-Starting Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. WARNING Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 588 If Trouble Arises Battery Runs Out Route the jumper leads away from parts that will be moving: Connecting a jumper lead near or to moving parts (cooling fans, belts) is dangerous. The lead could get caught when the engine starts and cause serious injury. CAUTION Use only a 12 V booster system.
Page 589 7. Disconnect the jumper leads in the reverse order of their connection. 8. Install the battery cover. 9. Have your vehicle inspected by an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. 7-45...
Page 590 Emergency Starting Starting a Flooded Engine Push-Starting (SKYACTIV-G 1.5, ▼ Push-Starting SKYACTIV-G 2.0, Do not push-start your Mazda. SKYACTIV-X 2.0, and WARNING SKYACTIV-G 2.5) ▼ Starting a Flooded Engine Never tow a vehicle to start it: Towing a vehicle to start it is If the engine fails to start, it may be dangerous.
Page 591 If the engine does not start the ﬁrst time, try starting it several more times. If it still does not start, contact an expert repairer (we recommend an Authorised Mazda Repairer). 7-47...
Page 592 Stop the engine and call an expert When the engine and radiator are hot, repairer (we recommend an scalding coolant and steam may shoot Authorised Mazda Repairer). out under pressure and cause serious 6. Make sure the cooling fan is injury.
Page 593 Carefully add coolant as required (page 6-29). CAUTION If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an expert repairer (we recommend an Authorised Mazda Repairer). 7-49...
Page 594 Towing an AWD vehicle with either the only by an expert repairer (we front or rear wheels on the ground is recommend an Authorised Mazda dangerous as the drive train could be Repairer) or a commercial tow-truck damaged, or the vehicle could trail service.
Page 595 If Trouble Arises Emergency Towing If the parking brake cannot be Towing Hooks released when towing the vehicle, transport the vehicle with all front ▼ Towing Hooks and rear wheels raised off the ground as shown in the ﬁgure. If the vehicle CAUTION is towed without raising the wheels off the ground, the brake system...
Page 596 Remove the cap completely and store it so as not to lose it. 3. Securely install the towing eyelet using the wheel brace or equivalent. Consult an expert repairer (we recommend an Authorised Mazda Repairer). Front (Saloon) Rear (Saloon) 1. Wheel brace 2.
Page 597 If Trouble Arises Emergency Towing Rear CAUTION (Saloon) If the towing eyelet is not securely tightened, it may loosen or disengage from the bumper when towing the vehicle. Make sure that the towing eyelet is securely tightened to the bumper. Be careful not to damage the towing eyelet and towing hook, vehicle body, or transmission...
Page 598 1. Press the INFO switch on the warning light illuminated. Contact an steering switch to display the expert repairer (we recommend an warning indication screen. Authorised Mazda Repairer) to have Refer to Multi-information Display the brakes inspected as soon as on page 4-25. possible: Driving with the brake system warning light illuminated is dangerous.
Page 599 Have the vehicle more strongly than normal to stop towed to an expert repairer (we the vehicle. recommend an Authorised Mazda (With M Hybrid) Repairer) to have the brakes inspected When starting the engine, the brake as soon as possible:...
Page 600 4. Start the engine and check the warning light. If the light remains illuminated even though the oil level is normal or after adding oil, stop the engine immediately and have your vehicle towed to an expert repairer (we recommend an Authorised Mazda Repairer). 7-56...
Page 601 Should this happen, consult an expert when the engine is restarted after repairer (we recommend an some time has passed. If the indication Authorised Mazda Repairer) as soon as displays even after the engine is possible. restarted, contact an expert repairer...
Page 602 (we recommend an Authorised Mazda Repairer) as soon as possible. If the check engine light remains on, or it ﬂashes continuously , do not drive at high speeds and consult an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. 7-58...
Page 603 Have your warning light starts ﬂashing, have the vehicle inspected at an expert repairer vehicle inspected immediately at an (we recommend an Authorised Mazda expert repairer (we recommend an Repairer). Authorised Mazda Repairer). If the vehicle is not inspected and continues to be driven, the engine may malfunction.
Page 604 Authorised Mazda transmission has an electrical problem. Repairer). Continuing to drive your Mazda in this condition could cause damage to your transmission. Consult an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible.
Page 605 (we recommend an Authorised Mazda switched ON. If any of these occur, Repairer) as soon as possible. consult an expert repairer (we...
Page 606 Go to an Drive Only. Have the Vehicle expert repairer (we recommend an Inspected” is displayed/When the Authorised Mazda Repairer) and have light is turned on it checked. If the engine is shut off while the indicator light is ﬂashing, you The indication is displayed/the light will not be able to restart it.
Page 607 4 wheels. Contact an expert repairer (we recommend an If there is a problem with the TPMS or Authorised Mazda Repairer) if the the voltage of a tyre pressure sensor indication remains on or the warning decreases, the TPMS warning light light remains illuminated.
Page 608 Check the reason for the indication displaying on the centre display or vehicle inspected at an expert repairer multi-information display. (we recommend an Authorised Mazda Refer to If a Warning Light Turns On or Repairer). Flashes on page 7-54. ▼ Adaptive LED Headlights (ALH) ▼...
Page 609 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Engine Oil Level Warning CAUTION Indication/Warning Light Do not drive the vehicle while an exterior light has a malfunction. Poor visibility, and not being able to signal braking and turns may cause an accident.
Page 610 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Seat Belt Warning Indication/ Action to be taken Warning Light (Front seat) Fasten the seat belts. ▼ Seat Belt Warning Light (Rear seat) (Red) The seat belt warning light turns on if If the rear seat belts are not fastened the driver or front passenger's seat is while the ignition is switched ON , the...
Page 611 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Door-Ajar/Boot lid-Ajar/ WARNING Liftgate-Ajar Warning Indication/ Warning Light Do not drive the vehicle at high speeds if the TPMS warning light turns on or ﬂashes: Driving the vehicle at high speeds while the TPMS warning light is turned on or ﬂashing is dangerous because the brake performance and the...
Page 612 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ KEY Indicator Light (Green) CAUTION (Flashing) Adjust the tyre pressures while the tyres are cool. Because the air pressure in the tyres ﬂuctuates depending on the temperature, before adjusting the tyre pressures, let the vehicle sit for an hour or drive “Low Key Fob Battery.
Page 613 Brake Hold Disabled in a stop position by the AUTOHOLD er (we recommend an Authorised function. Mazda Repairer). This message indicates the possibility Steep Slope. Continue of the vehicle not being held in the Depress and hold your foot on the...
Page 614 Content Action to be taken Display This message is indicated when the Mazda Radar Cruise Control (MRCC), Mazda Radar Cruise Con- Mazda Radar Cruise Have your vehicle inspected by an ex- trol with Stop & Go function (MRCC Control Cancelled.
Page 615 If Trouble Arises Warning/Indicator Lights and Warning Sounds *1*2 Content Action to be taken Display This message is indicated when the When starting the engine, press the Depress Brake Pedal to push button start is pressed without push button start with the brake ped- Start Engine depressing the brake pedal.
Page 616 If Trouble Arises Warning/Indicator Lights and Warning Sounds *1*2 Content Action to be taken Display The engine speed will increase while the engine is running an internal cleaning cycle with the selector lever Fast Idle Warm Up For in the P or N position (automatic Engine Cleaning.
Page 617 ACC, a beep will Refer to the Settings section in the be heard 6 times in the cabin to notify Mazda Connect Owner's Manual. the driver that the ignition has not ▼ Seat Belt Warning Beep been switched OFF (STOP). Under this...
Page 618 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Key Removed from Vehicle ▼ Liftgate Door-lock Switch Warning Beep Inoperable Warning Beep Vehicles with advanced keyless When the door-lock switch on the function liftgate is pressed under any of the following conditions, a warning sound If the key is taken out of the vehicle is activated.
Page 619 Shift the selector lever to the place. After stopping the vehicle, P or N position, or close the driver's contact an expert repairer (we door. recommend an Authorised Mazda Repairer). 7-75...
Page 620 (we door is opened. recommend an Authorised Mazda (Automatic transmission)  Repairer). With the selector lever in the D or ▼...
Page 621 Blind Spot warning sound. Monitoring (BSM) warning light is NOTE illuminated. The volume of the Lane Departure Warning System (LDWS) warning sound can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. 7-77 *Some models.
Page 622 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Mazda Radar Cruise Control ▼ Mazda Radar Cruise Control with Stop & Go function (MRCC with (MRCC) System Warnings Stop & Go function) System The Mazda Radar Cruise Control Warnings (MRCC) system warnings notify the...
Page 623 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Speed Limiter Warning Beep If the vehicle speed exceeds the set speed by about 5 km/h (3 mph) or more, a warning beep operates continuously. The warning beep operates until the vehicle speed decreases to the set speed or less.
Page 624 If Trouble Arises When Liftgate/Boot Lid Cannot be Opened 2. Turn the lever to the right to unlock When Liftgate/Boot Lid the liftgate. Cannot be Opened ▼ When Liftgate/Boot Lid Cannot be Opened If the battery is dead, the liftgate/boot lid cannot be unlocked and opened.
Page 625 4. (With theft-prevention cover) After performing this emergency Remove the theft-prevention cover. measure, have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. 5. Move the lever to the left to fold the seatback. 7-81...
Page 626 If the active driving display does not operate, switch the ignition off and then restart the engine. If the active driving display does not operate even with the engine restarted, have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer). 7-82...
Page 627 If the windscreen wipers operate at high speed regardless of the wiper switch operation, have your vehicle inspected by an expert repairer (we recommend an Authorised Mazda Repairer). 7-83...
Page 628 MEMO 7-84...
Page 629 Customer Information Important consumer information including warranties and add- on equipment. Warranty........8-2 Electromagnetic Registering Your Vehicle in A Compatibility......8-63 Foreign Country..... 8-2 Electromagnetic Add-On Non-Genuine Parts and Compatibility...... 8-63 Accessories......8-2 Collection/Disposal of Old Cell Phones......8-4 Equipment/Used Battery..8-65 Cell Phones Warning....8-4 Information for Users on Collection and Disposal of Old...
Page 630: Customer Information
Registering your vehicle in a foreign Please note that technical alterations country may be problematic to the original state of your Mazda depending on whether it meets the vehicle can affect the safety of the speciﬁc emission and safety standards vehicle.
Page 631 Essential systems could be damaged, causing engine stalling, air-bag (SRS) activation, ABS/TCS/DSC inactivation, or a ﬁre in the vehicle. Mazda assumes no responsibility for death, injury, or expenses that may result from the installation of add-on non-genuine parts or accessories.
Page 632 Customer Information Cell Phones Cell Phones Warning ▼ Cell Phones Warning WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your country: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous.
Page 633 Customer Information Collection and Processing of Data in the Vehicle Personal references Collection and Every vehicle is identiﬁed by means of Processing of Data in the a unique vehicle identiﬁcation number. Vehicle This vehicle identiﬁcation number is traceable to the current and former ▼...
Page 634 Collection and Processing of Data in the Vehicle For more information on your legal environmental conditions (e.g.,  rights relating to Mazda (for example, temperature, rain sensor, distance your right to the deletion and sensor). correction of data), please refer to the...
Page 635 The data from the vehicle may be read Depending on the particular vehicle out by employees of the Mazda conﬁgurations, these may include: Network (e.g. authorised workshops, seat and steering wheel position ...
Page 636 Services provided by the manufacturer same time, speciﬁc information is For our online services, the respective transferred to your smartphone. functions are described by Mazda in Depending on the type of integration, an appropriate place (e.g., in the this may include location data,...
Page 637 (For Europe) Further information regarding data protection can be found on the Mazda website. Please visit “https:// www.mazdamotors.eu” to ﬁnd your country-speciﬁc webpage.
Page 638 Customer Information Declaration of Conformity Declaration of Conformity ▼ Keyless Entry System/Immobilizer System 8-10...
Page 639 Customer Information Declaration of Conformity 8-11...
Page 640 Customer Information Declaration of Conformity 8-12...
Page 641 Customer Information Declaration of Conformity ▼ Tyre Pressure Monitoring System 8-13...
Page 642 Customer Information Declaration of Conformity 8-14...
Page 643 Customer Information Declaration of Conformity 8-15...
Page 644 Customer Information Declaration of Conformity ▼ Mazda Radar Cruise Control (MRCC) 8-16...
Page 645 Customer Information Declaration of Conformity 8-17...
Page 646 Customer Information Declaration of Conformity 8-18...
Page 647 Customer Information Declaration of Conformity 8-19...
Page 648 Customer Information Declaration of Conformity 8-20...
Page 649 Customer Information Declaration of Conformity 8-21...
Page 650 Customer Information Declaration of Conformity 8-22...
Page 651 Customer Information Declaration of Conformity 8-23...
Page 652 Customer Information Declaration of Conformity 8-24...
Page 653 Customer Information Declaration of Conformity 8-25...
Page 654 Customer Information Declaration of Conformity ▼ Blind Spot Monitoring (BSM) System 8-26...
Page 655 Customer Information Declaration of Conformity 8-27...
Page 656 Customer Information Declaration of Conformity 8-28...
Page 657 Customer Information Declaration of Conformity 8-29...
Page 658 Customer Information Declaration of Conformity 8-30...
Page 659 Customer Information Declaration of Conformity 8-31...
Page 660 Customer Information Declaration of Conformity 8-32...
Page 661 Customer Information Declaration of Conformity 8-33...
Page 662 Customer Information Declaration of Conformity 8-34...
Page 663 Customer Information Declaration of Conformity 8-35...
Page 664 Customer Information Declaration of Conformity ▼ Audio System 8-36...
Page 665 Customer Information Declaration of Conformity 8-37...
Page 666 Customer Information Declaration of Conformity 8-38...
Page 667 Customer Information Declaration of Conformity 8-39...
Page 668 Customer Information Declaration of Conformity 8-40...
Page 669 Customer Information Declaration of Conformity 8-41...
Page 670 Customer Information Declaration of Conformity 8-42...
Page 671 Customer Information Declaration of Conformity 8-43...
Page 672 Customer Information Declaration of Conformity ▼ Radio System 8-44...
Page 673 Customer Information Declaration of Conformity With DAB radio 8-45...
Page 674 Customer Information Declaration of Conformity 8-46...
Page 675 Customer Information Declaration of Conformity 8-47...
Page 676 Customer Information Declaration of Conformity Without DAB radio 8-48...
Page 677 Customer Information Declaration of Conformity 8-49...
Page 678 Customer Information Declaration of Conformity 8-50...
Page 679 Customer Information Declaration of Conformity ▼ Emergency call system 8-51...
Page 680 Customer Information Declaration of Conformity 8-52...
Page 681 Customer Information Declaration of Conformity 8-53...
Page 682 Customer Information Declaration of Conformity 8-54...
Page 683 Customer Information Declaration of Conformity 8-55...
Page 684 Customer Information Declaration of Conformity 8-56...
Page 685 Customer Information Declaration of Conformity 8-57...
Page 686 Customer Information Declaration of Conformity 8-58...
Page 687 Customer Information Declaration of Conformity 8-59...
Page 688 Customer Information Declaration of Conformity 8-60...
Page 689 Customer Information Declaration of Conformity 8-61...
Page 690 Customer Information Declaration of Conformity ▼ Mazda ERA-GLONASS 8-62...
Page 691 1. Front right of roof transmitters, etc.) may only be ﬁtted to 2. Both sides of liftgate your Mazda if they comply with the 3. Centre of roof parameters shown in the table below. 4. Front left of roof 1 UN-R stands for United Nations Regulation.
Page 692 Customer Information Electromagnetic Compatibility NOTE After the installation of RF transmitters, check for disturbances from and to all electrical equipment in the vehicle, both in the standby and transmit modes. Check all electrical equipment: with the ignition ON  with the engine running ...
Page 693 Customer Information Collection/Disposal of Old Equipment/Used Battery By disposing of these products and Information for Users on batteries correctly, you will help to save Collection and Disposal valuable resources and prevent any potential negative effects on human of Old Equipment and health and the environment which Used Batteries could otherwise arise from...
Page 694 MEMO 8-66...
Page 695: Specifications
Speciﬁcations Technical information about your Mazda. Identiﬁcation Numbers....9-2 Speciﬁcations......9-4 Vehicle Information Labels... Speciﬁcations......9-4 ..........9-2...
Page 696 Speciﬁcations Identiﬁcation Numbers ▼ Chassis Number/Vehicle Vehicle Information Identiﬁcation Number (Ireland, Labels UK, Swaziland, Namibia, Botswana, Lesotho, Russian ▼ Vehicle Identiﬁcation Number Federation) (South Africa, Arab Gulf Chassis Number Cooperation Council, Iraq) Open the cover shown in the ﬁgure to check the chassis number.
Page 697 Speciﬁcations Identiﬁcation Numbers ▼ Tyre Pressure Label SKYACTIV-X 2.0 Left-hand drive model 1. Forward Right-hand drive model SKYACTIV-D 1.8 ▼ Engine Number 1. Forward SKYACTIV-G 1.5, SKYACTIV-G 2.0, SKYACTIV-G 2.5 ▼ Conformity Plate (Arab Gulf Cooperation Council, Iraq) Production year and month are shown on this plate.
Page 698 Speciﬁcations Speciﬁcations Speciﬁcations ▼ Engine Petrol engine Speciﬁcation Item SKYACTIV-G 1.5 SKYACTIV-G 2.0 SKYACTIV-G 2.5 SKYACTIV-X 2.0 Type DOHC-16V in-line, 4-cylinder 74.5 × 85.8 mm 83.5 × 91.2 mm 89.0 × 100 mm 83.5 × 91.2 mm Bore × Stroke (2.93 ×...
Page 699 Because the SKYACTIV-X 2.0 is a high compression ratio engine, the piston and plugs are close to each other. If the replacement is not done using the correct procedure or a non-genuine plug is used, the engine could be damaged. Consult an expert repairer (we recommend an Authorised Mazda Repairer) for details.
Page 700 Mazda Original Oils are specially designed/tested for the respective engine. For optimum performance we recommend to use Mazda Original Oils at all times. If you are unable to ﬁnd a Mazda Original Oil, alternative oils meeting the listed speciﬁcation may also be used.
Page 701 Without M Hybrid SAE J1703 or FMVSS116 DOT-3 or DOT-4 Mazda Long Life Gear Oil G7 is superior oil for low fuel cost and optimum shift-feel. Using Mazda Long Life Gear Oil G7 is recommended. If Mazda Long Life Gear Oil G7 cannot be obtained, use standard oil (API Service GL-4 (SAE 75W-80)).
Page 702 Speciﬁcations Speciﬁcations ▼ Capacities (Approximate Quantities) Item Capacity With oil ﬁlter replacement 4.2 L (4.4 US qt, 3.7 Imp qt) SKYACTIV-G Without oil ﬁlter replacement 3.9 L (4.1 US qt, 3.4 Imp qt) With oil ﬁlter replacement 4.2 L (4.4 US qt, 3.7 Imp qt) SKYACTIV-G Without oil ﬁlter replacement 4.0 L (4.2 US qt, 3.5 Imp qt)
Page 703 Speciﬁcations Speciﬁcations Item Capacity Manual Left-hand drive model 5.7 L (6.0 US qt, 5.0 Imp qt) transmis- Right-hand drive model 5.6 L (5.9 US qt, 4.9 Imp qt) sion SKYACTIV-G Automatic Left-hand drive model 6.0 L (6.3 US qt, 5.3 Imp qt) transmis- Right-hand drive model 5.9 L (6.2 US qt, 5.2 Imp qt)
Page 704 Speciﬁcations Speciﬁcations Item Capacity SKYACTIV-G 1.5 7.2 L (7.6 US qt, 6.3 Imp qt) Automatic SKYACTIV-G With Cylinder Deactivation 7.9 L (8.3 US qt, 7.0 Imp qt) transmission 2.0, SKYAC- Without Cylinder Deactivation 7.6 L (8.0 US qt, 6.7 Imp qt) ﬂuid TIV-G 2.5 SKYACTIV-X 2.0, SKYACTIV-D 1.8...
Page 705 Speciﬁcations Speciﬁcations Item Vehicle speciﬁcation Rear tread 1,580 mm (62.2 in) Wheelbase 2,725 mm (107.3 in) ▼ Light Bulbs Exterior light Category Light bulb Wattage UN-R (SAE) ― (―) Headlights ― (―) LED type Running lights /Position lights Bulb type 21/5 W21/5W (7444) Front direction indicator lights...
Page 706 Speciﬁcations Speciﬁcations ▼ Tyres Sample tyre mark and its meaning 1. Nominal section width 2. Nominal aspect ratio in % 3. Construction code 4. Nominal rim diameter in inches 5. Load index (not on ZR tyres) 6. Speed symbol 7. Mud and snow Tyre mark information Choose the proper tyres for your vehicle using the following tyre mark information.
Page 707 NOTE The tyres have been optimally matched with the chassis of your vehicle. When replacing tyres, Mazda recommends that you replace tyres of the same type originally ﬁtted to your vehicle. For details, contact an expert repairer (we recommend an Authorised Mazda Repairer).
Page 708 Refer to Fuses on page 6-50. ▼ Brakes If you require information regarding the wear limit speciﬁcation for the brake disc plates and the measurement method, please contact an expert repairer (we recommend an Authorised Mazda Repairer). The information is made freely available. 9-14...
Page 709: Index
Index 10-1...
Page 710 Index Manual shift mode....4-51 Shift-lock system....4-49 Accessory Socket....... 5-37 Transmission ranges....4-50 Active Driving Display....4-42 Adaptive LED Headlights (ALH)............4-108 Battery........6-38 Add-On Non-Genuine Parts and Inspecting electrolyte level..6-40 Accessories......... 8-2 Maintenance......6-39 Adjustable Speed Limiter (ASL) ..Recharging......
Page 711 Index Centre Console......5-41 Display........4-23 Child Restraint Distance & Speed Alert (DSA).. 4-126 Categories of child-restraint Indication on display...4-127 systems........ 2-34 Door Locks....... 3-12 Child-restraint precautions..2-30 Door-ajar Warning Beep....7-79 Child-restraint system installation Driver Attention Alert (DAA)..4-127 position....... 2-34 Driver Monitoring Camera..
Page 712 Index Starting a ﬂooded engine Mounting the spare tyre..7-41 (SKYACTIV-G 1.5, SKYACTIV-G Removing a ﬂat tyre....7-38 2.0, SKYACTIV-X 2.0, and Floor Mat......... 3-55 SKYACTIV-G 2.5)....7-46 Fluids Emergency Stop Signal System..4-84 Brake/Clutch......6-31 Emergency Towing Classiﬁcation......9-6 Towing description....7-50 Washer........ 6-32 Towing hooks.......
Page 713 Index Coming home light....4-62 Engine coolant temperature Flashing........4-62 gauge........4-28 High-low beam....4-62 Fuel gauge......4-28 Leaving home light....4-63 Indication/indicator lights..4-37 Levelling.......4-63 Instrument panel Running lights...... 4-63 illumination......4-29 Washer........ 4-71 i-ACTIVSENSE display... 4-33 Headlight Washer......4-71 Message Display....4-33 Head Restraint......2-17 Message indicated on multi- High Beam Control System information display....7-69...
Page 714 (LDWS)......4-110 Interior Lights......5-34 Lane-keep Assist System Luggage compartment light... 5-34 (LAS)........4-173 Map lights......5-34 Mazda Radar Cruise Control with Overhead lights....5-34 Stop & Go function (MRCC with i-ACTIVSENSE......4-101 Stop & Go function)... 4-147 Active safety technology..4-101...
Page 715 Manual Transmission Shift Pattern........4-45 Map Lights........5-34 Label Information Mazda ERA-GLONASS....7-12 Chassis number......9-2 Mazda Radar Cruise Control with Conformity plate....9-3 Stop & Go function (MRCC with Stop Engine number....... 9-3 & Go function)......4-147 Model plate......9-2 Close proximity warning..4-151 Tyre pressure label....
Page 716 Index Meters........4-23 Rear Coat Hooks.......5-40 Mirrors Rear Cross Traffic Alert (RCTA) ... Outside mirrors....3-36 ..........4-134 Rearview mirror....3-39 Rear Cross Traffic Alert (RCTA) Mirror Defogger......4-72 Warning Beep......7-77 Multi-information Display..4-25 Rear Door Child Safety Locks..3-21 MZD Connect......5-14 Rear Fog Light......
Page 717 Index Brakes........9-14 Capacities......9-8 Saving Fuel and Protection of the Cleaner........9-7 Environment......3-53 Dimensions......9-10 Scheduled Maintenance....6-3 Electrical system..... 9-5 Seats Engine........9-4 Driver's seat......2-5 Light bulbs......9-11 Driving position memory..2-11 Lubricant quality.....9-6 Front passenger's seat...2-13 Tyres........9-12 Front seat.......2-5 Speed Limiter Warning Beep..
Page 718 Index Touch Sensor Inoperable Warning Beep (With the advanced keyless Vanity Mirrors......5-33 function)........7-74 Vehicle Information Labels Towing Chassis number......9-2 Hook........7-51 Conformity plate....9-3 Towing Caravans and Trailers Engine number....... 9-3 (Europe/Russia/Turkey/Israel/ Model plate......9-2 South Africa)......3-60 Tyre pressure label....9-3 Towing Description....
Page 719 Inoperable Warning Beep..7-74 Winter Driving......3-56 Lights-on reminder....7-73 Wiper Low fuel warning beep..7-75 Replacing Rear Window Wiper Mazda Radar Cruise Control with Blade........6-37 Stop & Go function (MRCC with Replacing windscreen wiper Stop & Go function) system blades........6-33 warnings......7-78 Mazda Radar Cruise Control (MRCC) system warnings..
Page 720 10-12...

Mazda 3 2020 Owner's Manual

Table of Contents

Table of Contents

I-ACTIV AWD

Power Steering

I-ACTIVSENSE

Cruise Control

Tyre Pressure Monitoring System

(Tpms)

Petrol Particulate Filter

Diesel Particulate Filter

Rear View Monitor

Parking Sensor System

Quick Links

Chapters

Related Manuals for Mazda 3 2020

Summary of Contents for Mazda 3 2020

Table of Contents
