4.2

Extension Slots

The conga-HPC/EVAL-Server provides the following extension slots:
• eight PCIe slots
– two PCIe x16 slots (lanes 16-31 on X10 and lanes 32-47 on X11)
– two PCIe x8 slots (lanes 0-7 on X7 and lanes 48-55 on X12)
– three PCIe x4 slots (lanes 12-15 on X8, lanes 56-59 on X13 and lanes 60-63 on X14)
– one M.2 key M, socket 3, type 2230/2242/2260/2280/22110 (PCIe lanes 8-11 on X6)
• one KR connector for Ethernet Mezzanine cards
Jumpers for PCIe Clock Requests
To permanently enable the clock request for the PCIe slots, use the jumpers described in the table below.
Table 14 JP12 - PCIe Clock Request Configuration
Jumper Connector
JP12 X7
JP13 X8
JP13 X6
JP14 X13
JP14 X14
JP14 X12
Copyright © 2022 congatec AG
Socket
PCIe x8
PCIe x4
M.2
PCIe x4
PCIe x4
PCIe x8
